Motor Speed Control Solution – Allen-Bradley 25B-D013N104 | PowerFlex 525
Where This Product Is Used
The Allen-Bradley 25B-D013N104 PowerFlex 525 AC Drive is engineered for demanding industrial motor control applications where precise speed regulation, energy efficiency, and compact footprint are critical. Typical deployment environments include:
- Conveyor & Material Handling Systems – Smooth acceleration/deceleration control reduces mechanical stress and product damage on packaging lines and distribution centers.
- HVAC & Building Automation – Fan and pump speed modulation delivers measurable energy savings in commercial and industrial HVAC installations.
- Water & Wastewater Treatment – Precise flow control for pumping stations, aeration blowers, and filtration systems operating under variable load conditions.
- Food & Beverage Processing – Hygienic-compatible drive control for mixers, fillers, and conveyors requiring repeatable speed profiles.
- Machine Tool & OEM Equipment – Embedded EtherNet/IP connectivity enables seamless integration into Rockwell Automation ControlLogix and CompactLogix PLC architectures.
Technical Specifications
- Part Number / SKU: 25B-D013N104
- Series: PowerFlex 525
- Brand: Allen-Bradley (Rockwell Automation)
- Output Power: 7.5 HP (5.5 kW)
- Input Voltage: 480V AC, 3-Phase
- Output Current: 13.0 A (Normal Duty)
- Input Frequency: 50/60 Hz
- Enclosure Rating: IP20 / Open Type
- Control Method: V/Hz, Sensorless Vector Control (SVC)
- Communication: Embedded EtherNet/IP + DSI port
- Safety: Safe Torque Off (STO) – SIL 2 / PLd Cat. 3
- Certifications: UL, CE, RCM, RoHS
- Weight: 1.6 kg (approx.)
Why Engineers Specify This Model
- Embedded EtherNet/IP eliminates the need for a separate communication module, reducing panel space and BOM cost.
- Safe Torque Off (STO) meets SIL 2 / PLd Cat. 3 safety requirements without external safety relays in many topologies.
- AppView & CustomView keypads allow parameter grouping tailored to specific machine functions, accelerating commissioning.
- Energy savings mode automatically optimizes V/Hz ratio under light-load conditions, reducing operating costs.
- Compact DIN-rail or panel-mount design fits space-constrained control cabinets without sacrificing performance.
Complete System Bill of Materials
- 25B-D013N104 – PowerFlex 525 AC Drive (this unit)
- 25-COMM-E2P – Dual-port EtherNet/IP communication adapter (optional redundant network)
- 25-RF010-AL – EMC line filter for CE compliance
- 25-PM1-D013 – Dynamic braking resistor kit (for high-inertia loads)
- 1203-USB – USB-to-DSI programming cable
- Connected Components Workbench (CCW) – Free Rockwell programming software
Compliance & Industry Standards
- UL 508C – Power Conversion Equipment
- IEC 61800-5-1 – Adjustable Speed Electrical Power Drive Systems Safety
- IEC 61800-3 – EMC Requirements (Category C2)
- ISO 13849-1 / IEC 62061 – Functional Safety (STO function)
- RoHS Directive 2011/65/EU compliant
Quality Assurance & Sourcing
Every unit supplied by Konmask.com undergoes a structured verification process:
- Visual inspection against Rockwell Automation OEM packaging standards
- Label and date-code authentication
- Functional power-on test where applicable
- Traceability documentation available on request
We source exclusively from authorized distributors and verified industrial surplus channels. Counterfeit-risk screening is applied to all Allen-Bradley PowerFlex inventory.
How to Source This Part
- In Stock: Add to cart and proceed to checkout – typical dispatch within 1–3 business days.
- Bulk / Project Quantity: Contact us for volume pricing and lead-time commitment.
- Urgent Requirement: Email support@konmask.com or call +0086 19859288691 for expedited sourcing.
- Cross-Reference / Replacement: Our engineers can confirm compatibility with your existing system before purchase.
Application-Specific FAQ
Q: Is the 25B-D013N104 compatible with ControlLogix and CompactLogix PLCs?
A: Yes. The embedded EtherNet/IP port supports direct Add-On Profile (AOP) integration with Studio 5000 Logix Designer for seamless tag-based control.
Q: Can this drive be used for single-phase input applications?
A: No. The 25B-D013N104 requires 3-phase 480V AC input. For single-phase applications, refer to the PowerFlex 523 or 525 120V/240V single-phase variants.
Q: What is the maximum cable length between the drive and motor?
A: Rockwell recommends a maximum of 100 m (328 ft) shielded cable without an output filter. Longer runs require an output reactor or dV/dt filter.
Q: Does this model include a built-in brake chopper?
A: Yes, a dynamic braking transistor is built in. An external braking resistor (e.g., 25-PM1-D013) must be added for regenerative braking applications.
Q: What firmware version is pre-installed?
A: Units are supplied with the factory-default firmware. Firmware upgrades are available free of charge via Rockwell’s Product Compatibility and Download Center (PCDC).
