Allen-Bradley 2711P-RP1 PanelView Plus 64MB Flash RAM DC Logic Module

HMI Runtime & Visualization Solution – Allen-Bradley 2711P-RP1 | PanelView Plus Series

The Allen-Bradley 2711P-RP1 is the 64MB Flash RAM DC Logic Module designed for the PanelView Plus terminal family. It serves as the computational core of the HMI unit — storing application runtime, managing screen logic, and executing operator interface programs in real time. When this module fails or becomes unavailable, the entire HMI terminal goes dark: operators lose visibility into process status, alarm acknowledgment becomes impossible, and production lines must halt until the module is replaced. In high-throughput manufacturing environments, every minute of HMI downtime translates directly into lost output and potential safety risk.

The 2711P-RP1 is the entry-level logic module in the PanelView Plus 2711P platform — a platform that Rockwell Automation has deployed across hundreds of thousands of industrial installations worldwide. Its 64MB Flash RAM capacity supports a wide range of FactoryTalk View ME applications, making it the standard replacement module for PanelView Plus 6 and PanelView Plus terminals in the 400–1500 series. Whether you are maintaining an existing installation or building a new panel, the 2711P-RP1 remains one of the most widely specified HMI logic modules in global discrete and process manufacturing.

Where This Product Is Used

• Automotive Assembly Lines — Operator interface terminals on robotic welding cells, paint booths, and final assembly conveyors running FactoryTalk View ME applications.
• Food & Beverage Processing — HMI panels on filling lines, pasteurizers, and CIP (Clean-in-Place) systems where continuous uptime is critical.
• Water & Wastewater Treatment — SCADA-connected PanelView Plus terminals monitoring pump stations, filtration stages, and chemical dosing systems.
• Oil & Gas Upstream/Midstream — Remote wellhead and pipeline HMI stations requiring reliable DC-powered logic modules in harsh environments.
• Pharmaceutical Manufacturing — GMP-compliant production lines where validated HMI applications must run without interruption.
• Material Handling & Logistics — Conveyor control panels, sortation systems, and warehouse automation terminals.
• Power Generation & Utilities — Substation and generator control room HMI panels integrated with Allen-Bradley PLCs via EtherNet/IP.

Technical Specifications

Part Number	2711P-RP1
Manufacturer	Allen-Bradley / Rockwell Automation
Series	PanelView Plus / PanelView Plus 6
Module Type	Logic Module (Replaceable)
Flash Memory	64 MB
Power Input	DC Logic
Compatible Terminals	PanelView Plus 400, 600, 700, 1000, 1250, 1500 (2711P series)
Software Platform	FactoryTalk View Machine Edition (ME)
Communication	Via terminal base unit (EtherNet/IP, DH-485, DF1, DeviceNet depending on comm module)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% non-condensing
Approvals	UL, CE, cUL (refer to Rockwell publication 2711P-TD001 for full certification list)
Weight	Approx. 660 g

Note: Specifications are based on Rockwell Automation published data. Always verify against the official product bulletin before engineering design-in.

Why Engineers Specify This Model

• Field-Replaceable Design — The logic module separates from the display and communication modules, allowing targeted replacement without disturbing the entire terminal assembly or panel wiring.
• Broad Terminal Compatibility — A single 2711P-RP1 supports the full range of PanelView Plus 2711P display sizes, simplifying spare parts inventory management across multi-terminal facilities.
• FactoryTalk View ME Native — Runs Rockwell’s standard HMI runtime environment, ensuring seamless integration with existing ControlLogix, CompactLogix, and MicroLogix PLC architectures.
• DC Power Architecture — DC logic input suits panel designs powered from 24VDC control power supplies, the dominant standard in modern industrial control panels.
• Proven Global Installed Base — With millions of PanelView Plus terminals deployed worldwide, the 2711P-RP1 benefits from extensive field validation and a mature support ecosystem.
• Rapid Application Restore — Application files stored on CompactFlash or USB can be reloaded to a replacement module quickly, minimizing mean time to repair (MTTR).

Complete System Bill of Materials

The 2711P-RP1 logic module operates within the modular PanelView Plus architecture. A complete terminal typically includes:

• 2711P-RP1 — Logic Module (this item)
• 2711P-T7C4D8 / T10C4D8 / T12W4D8 — Display Module (7″, 10″, 12″ options)
• 2711P-RN15S / RN6 — EtherNet/IP or DH-485 Communication Module
• 2711P-B7C4D8 / B10C4D8 — Terminal Base Unit (integrates all modules)
• 2711P-RY2032 — Replacement Battery for real-time clock
• 2711P-RC1 — CompactFlash Card (application backup storage)
• 1606-XLP50E — 24VDC Power Supply (recommended Rockwell power source)

Contact Konmask.com to source any of the above companion parts with a single inquiry.

Compliance & Industry Standards

• UL Listed (UL 508)
• CE Marked (EMC Directive, Low Voltage Directive)
• cUL Listed (Canadian market)
• RoHS Compliant
• ATEX / Class I Div 2 — consult Rockwell documentation for hazardous location ratings applicable to specific terminal configurations
• Designed to meet IEC 61131-2 environmental requirements for industrial control equipment

Quality Assurance & Sourcing

At Konmask.com, every Allen-Bradley module we supply goes through a structured quality process before shipment:

• Visual Inspection — Connector pins, housing integrity, and label verification against manufacturer part number.
• Functional Verification — Where applicable, modules are bench-tested for power-on response and communication handshake.
• Authentic Sourcing — We source from authorized distributors and verified industrial surplus channels. Counterfeit parts are rejected at intake.
• Secure Packaging — ESD-safe packaging with moisture barrier bags and foam cushioning for international shipment.
• Documentation — Certificate of conformance and packing list provided with every order.

How to Source This Part

1. Submit an Inquiry — Use the contact form or email support@konmask.com with your required quantity and delivery timeline.
2. Receive a Quote — Our team responds within 1 business day with pricing, lead time, and availability confirmation.
3. Order Confirmation — Confirm your purchase order. We accept T/T bank transfer, PayPal, and other B2B payment methods.
4. Shipment & Tracking — Parts are shipped via DHL, FedEx, or UPS Express with full tracking provided.
5. After-Sales Support — Our technical team is available to assist with installation questions and compatibility verification post-delivery.

Application-Specific FAQ

Q: Can the 2711P-RP1 be used in a PanelView Plus 6 terminal?
A: Yes. The 2711P-RP1 is compatible with both the original PanelView Plus and PanelView Plus 6 terminal families within the 2711P platform. Always verify the specific terminal catalog number against Rockwell’s compatibility matrix (publication 2711P-TD001).

Q: Will my existing FactoryTalk View ME application run on a replacement 2711P-RP1?
A: Yes, provided the application was developed within the memory constraints of the 64MB Flash RAM. Applications stored on CompactFlash or USB can be reloaded directly after module replacement.

Q: What is the difference between 2711P-RP1 and 2711P-RP2?
A: The 2711P-RP2 offers 128MB Flash RAM, doubling the application storage capacity. The 2711P-RP1 (64MB) is sufficient for the majority of standard HMI applications. Choose RP2 only if your application file size exceeds the RP1 capacity.

Q: Is this module available for immediate shipment?
A: Stock availability varies. Contact Konmask.com directly for real-time inventory status and lead time confirmation.

Q: Do you provide a warranty on this module?
A: Yes. Konmask.com provides a standard warranty on all supplied parts. Contact us for warranty terms applicable to your order.

Q: Can you supply the full PanelView Plus terminal assembly, not just the logic module?
A: Yes. We can source complete terminal assemblies as well as individual replacement modules. Submit your full BOM for a consolidated quote.

---
