Motion Control Solution – AMKASYN AMK KU14 | AMKASYN Series
The AMKASYN AMK KU14 is a compact, high-performance servo drive axis module from AMK’s AMKASYN decentralized drive system. Designed for multi-axis synchronization in demanding industrial environments, the KU14 delivers precise torque and speed control with minimal cabinet footprint — making it the preferred choice for machine builders and system integrators across Europe and Asia.
Where This Product Is Used
The AMK KU14 axis module is specified in applications where synchronized multi-axis motion, compact installation, and deterministic control are non-negotiable:
- CNC Machining Centers – Coordinated axis control for milling, turning, and grinding operations requiring sub-millisecond synchronization.
- Packaging Machinery – High-speed pick-and-place, form-fill-seal, and cartoning lines where axis timing directly impacts throughput.
- Textile & Printing Machines – Tension-controlled winding/unwinding and register control in web-handling systems.
- Robotics & Handling Systems – Articulated arm and gantry robot axes requiring smooth velocity profiles and fast fault response.
- Plastics & Extrusion Lines – Extruder speed synchronization and downstream haul-off control.
- Assembly Automation – Servo-driven press, torque, and positioning stations in automotive and electronics manufacturing.
Technical Specifications
- Manufacturer: AMKASYN (AMK Arnold Müller GmbH & Co. KG)
- Part Number / SKU: AMK KU14
- Series: AMKASYN Decentralized Drive System
- Module Type: Axis Module (Servo Drive)
- Form Factor: Modular, rail-mounted (decentralized installation)
- Control Interface: Compatible with AMK AMANET / SERCOS / fieldbus-based AMK controller systems
- Feedback: Resolver / encoder interface (application-dependent)
- Weight: 4.8 kg
- Cooling: Integrated / forced-air (refer to AMK KU14 datasheet for thermal derating)
- Protection Class: IP20 (cabinet installation)
- Standards: CE marked; designed to EN 61800-5-1, EN 61800-3
Note: Full electrical parameters (DC bus voltage, continuous/peak current, power rating) are available upon request or in the official AMK KU14 technical datasheet.
Why Engineers Specify This Model
- Decentralized Architecture: The AMKASYN system places drive intelligence close to the motor, reducing cabinet size and wiring complexity on large multi-axis machines.
- Deterministic Synchronization: Isochronous communication ensures all axes execute motion commands within the same control cycle — critical for electronic gearing and cam profiles.
- Compact Footprint: The KU14 module’s slim profile allows dense axis packing without sacrificing thermal performance.
- Proven Reliability: AMK AMKASYN drives are field-proven in European OEM machinery with documented MTBF in high-cycle applications.
- Scalable System: Easily expand from 2 to 20+ axes using the same AMKASYN platform without redesigning the control architecture.
Complete System Bill of Materials
The AMK KU14 axis module typically operates as part of a complete AMKASYN drive system. A standard multi-axis installation includes:
- AMK KU14 Axis Module (this item) — one per controlled axis
- AMK Power Supply Module (e.g., AMK KE / KW series) — shared DC bus supply
- AMK Controller (e.g., AMK AMKASYN iSA / iDT series) — motion controller
- AMK Servo Motor (e.g., AMK DT / DS series) — matched to KU14 current rating
- Feedback cable & power cable — AMK pre-assembled or custom-length
- SERCOS / AMANET fiber-optic ring cable — inter-module communication
- 24 VDC control power supply — logic supply for drive electronics
Contact support@konmask.com for complete BOM assistance and compatible part cross-references.
Compliance & Industry Standards
- CE Marking: Compliant with EU Machinery Directive and Low Voltage Directive
- EMC: EN 61800-3 (Category C2/C3 environment)
- Safety: EN 61800-5-1 (electrical safety of adjustable speed drive systems)
- RoHS: Compliant (confirm revision with Konmask for specific production batch)
- HS Code: 8504.40 (Static converters)
Quality Assurance & Sourcing
Konmask.com sources the AMK KU14 through established industrial surplus and authorized distribution channels. Every unit offered undergoes the following before shipment:
- Visual inspection for physical damage, corrosion, and connector integrity
- Label and serial number verification against AMK production records where available
- Functional power-on test (where test bench infrastructure permits)
- Anti-static packaging with humidity indicator card
- Documented condition grading: New Surplus / Refurbished / Used-Tested
Condition and warranty terms are confirmed at time of quotation. We stand behind every shipment with a clear return and dispute resolution policy.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Confirm Compatibility: Share your existing AMK system configuration (controller model, power supply, motor series) so we can verify the KU14 is the correct axis module revision.
- Receive Proforma Invoice: We issue a PI within 1 business day including unit price, shipping cost, lead time, and payment terms.
- Payment & Dispatch: We accept T/T bank transfer and major payment platforms. Units are dispatched with full tracking and export documentation.
- After-Sales Support: Our technical team is available to assist with installation questions and commissioning guidance post-delivery.
Application-Specific FAQ
Q: Is the AMK KU14 compatible with third-party servo motors?
A: The KU14 is optimized for AMK servo motors within the AMKASYN ecosystem. Use with third-party motors requires careful matching of feedback type, pole count, and current rating — contact us for engineering review.
Q: Can the KU14 be used as a standalone drive without an AMK controller?
A: No. The KU14 is a dependent axis module requiring an AMK master controller (e.g., iSA series) for motion commands via the AMANET/SERCOS ring. It is not a standalone drive.
Q: What is the DC bus voltage range for the KU14?
A: The KU14 operates from the shared DC bus supplied by the AMK power supply module. Typical bus voltage is in the 560–750 VDC range depending on the supply module. Confirm with the AMK KU14 datasheet for your specific revision.
Q: Do you provide the AMK KU14 with a warranty?
A: Yes. Warranty period and terms depend on the unit condition grade (new surplus vs. refurbished). Details are stated on the proforma invoice. Contact us for specifics.
Q: Can you supply multiple KU14 units for a production line retrofit?
A: Yes. We regularly fulfill multi-unit orders for OEM retrofit and spare parts programs. Volume pricing is available — request a quote for quantities of 3 or more.
