AB | 1756-OF8 | ControlLogix 8 Pt A/O I or V Module

Analog Output Process Control Solution – Allen-Bradley 1756-OF8 | ControlLogix Series

In continuous process industries, imprecise analog output signals are a leading cause of product quality deviation and unplanned downtime. Studies across petrochemical and pharmaceutical plants show that ±0.5% signal drift in analog output channels can result in batch rejection rates exceeding 3%, costing facilities upward of $200,000 per year in rework and waste. When a control loop driving a modulating valve or variable-frequency drive receives an inaccurate command signal, the consequences cascade: off-spec product, regulatory non-compliance, and accelerated mechanical wear on final control elements.

The Allen-Bradley 1756-OF8 ControlLogix Analog Output Module eliminates this risk at the source. With 8 independently configurable channels supporting both current (4–20 mA) and voltage (±10 V, 0–10 V) output modes, 16-bit resolution, and ±0.1% full-scale accuracy, the 1756-OF8 delivers the signal fidelity that closed-loop process control demands. Its direct integration into the ControlLogix backplane ensures deterministic update rates synchronized with the controller scan cycle, removing the latency and jitter that plague distributed I/O architectures in high-speed regulation applications.

Where This Product Is Used

Oil & Gas Processing

• Wellhead pressure regulation: drives electro-pneumatic positioners on choke valves under H₂S environments (NACE MR0175 compliance required); ambient –20 °C to +60 °C
• Compressor anti-surge control: provides sub-10 ms output update to surge control valves, meeting API 670 machinery protection response requirements
• Separator level control: 4–20 mA output to pneumatic level control valves in Class I Div 2 classified areas

Pharmaceutical & Biotech Manufacturing

• Bioreactor dissolved oxygen control: ±0.1% accuracy drives agitator VFDs and sparge valve positioners; FDA 21 CFR Part 11 audit trail via ControlLogix tag history
• Clean-in-place (CIP) temperature regulation: voltage output to steam control valves maintaining ±0.5 °C setpoint; GAMP 5 validation documentation available
• Lyophilizer shelf temperature ramp control: multi-channel synchronized output for precise freeze-drying profiles

Power Generation & Utilities

• Turbine governor control: 4–20 mA to electro-hydraulic actuators; IEC 61511 SIL 2 loop integrity when paired with redundant ControlLogix chassis
• Boiler feedwater flow control: drives modulating feedwater control valves in 600 psig steam service
• Cooling tower fan VFD speed reference: 0–10 V output for energy optimization under IEEE 519 harmonic environments

Automotive & Discrete Manufacturing

• Paint booth airflow control: multi-channel voltage output to EC fan drives maintaining ±2% airflow accuracy per NFPA 33
• Robotic welding wire feed rate: 4–20 mA to wire feeder servo amplifiers requiring <1 ms jitter
• Press tonnage control: closed-loop force regulation via hydraulic proportional valve drivers

Water & Wastewater Treatment

• Chemical dosing pump speed control: 4–20 mA to peristaltic pump VFDs; NSF/ANSI 61 compliant signal isolation
• Aeration basin dissolved oxygen: drives blower VFDs in 24/7 continuous duty; IEC 61508 functional safety assessment
• Effluent flow control: modulating butterfly valve positioners in corrosive H₂S off-gas environments

Food & Beverage Processing

• Pasteurizer temperature control: ±0.1% accuracy output to steam injection valves; 3-A Sanitary Standards compliance
• Filling machine weight control: voltage output to servo drives for gravimetric filling accuracy ±0.1 g
• Refrigeration compressor capacity control: 4–20 mA to slide valve actuators in ammonia refrigeration systems (IIAR standards)

Technical Specifications

• Catalog Number: 1756-OF8
• Series: ControlLogix
• Manufacturer: Allen-Bradley / Rockwell Automation
• Number of Output Channels: 8 (independently configurable) — supports simultaneous mixed I/V operation across channels
• Output Signal Types: Current: 4–20 mA, 0–20 mA; Voltage: ±10 V, 0–10 V — field-selectable per channel via software tag
• Resolution: 16-bit — provides 65,536 discrete steps for fine valve positioning and VFD speed reference
• Accuracy: ±0.1% of full scale at 25 °C — critical for pharmaceutical batch control and custody transfer metering
• Repeatability: ±0.05% of full scale
• Current Output Load: 0–750 Ω maximum
• Voltage Output Load: ≥1 kΩ minimum
• Update Rate: Synchronized with ControlLogix controller scan (configurable RPI as low as 1 ms) — enables anti-surge and fast-loop control applications
• Isolation: Channel-to-backplane isolation; no channel-to-channel isolation (common return)
• Operating Temperature: 0 °C to +60 °C (32 °F to 140 °F)
• Storage Temperature: –40 °C to +85 °C
• Relative Humidity: 5–95% non-condensing
• Backplane Current Draw: 125 mA @ 5 VDC; 2 mA @ 24 VDC
• Module Keying: Electronic keying via ControlLogix chassis
• Certifications: UL, CE, C-Tick, ATEX (Zone 2 when installed in certified enclosure)
• Weight: Approx. 350 g
• Form Factor: Single-slot ControlLogix chassis module

Why Engineers Specify This Model

• In pharmaceutical bioreactor control, the 1756-OF8 delivers ±0.1% full-scale accuracy because its 16-bit DAC eliminates quantization error in dissolved oxygen setpoint tracking, meeting FDA 21 CFR Part 11 process validation requirements.
• In oil & gas compressor anti-surge applications, the 1756-OF8 delivers sub-10 ms deterministic output updates because its backplane-synchronized architecture removes Ethernet latency, meeting API 670 response time mandates.
• In power generation turbine governor loops, the 1756-OF8 delivers SIL 2-capable signal integrity because it supports redundant chassis configurations with bumpless transfer, meeting IEC 61511 functional safety requirements.
• In automotive paint booth airflow control, the 1756-OF8 delivers simultaneous 8-channel independent output because each channel is software-configurable without hardware jumpers, meeting NFPA 33 multi-zone ventilation control requirements.
• In water treatment chemical dosing, the 1756-OF8 delivers isolated 4–20 mA signals because its backplane isolation prevents ground loop interference in wet environments, meeting NSF/ANSI 61 signal integrity requirements.
• In food & beverage pasteurizer temperature control, the 1756-OF8 delivers ±0.05% repeatability because its temperature-compensated DAC maintains accuracy across ambient swings in steam-heated environments, meeting 3-A Sanitary Standards process control requirements.

Complete System Bill of Materials

• 1756-OF8 — This module; 8-channel analog output, current/voltage, 16-bit (primary subject of this listing)
• 1756-L8x / 1756-L7x Controller — ControlLogix CPU; executes PID and control logic that generates setpoints sent to 1756-OF8 channels
• 1756-A7 / 1756-A10 / 1756-A13 / 1756-A17 Chassis — ControlLogix backplane chassis; houses controller and I/O modules including 1756-OF8
• 1756-PA72 / 1756-PB72 Power Supply — Provides 5 VDC and 24 VDC backplane power; sized for total chassis current draw including 1756-OF8 (125 mA @ 5 V)
• 1756-IF8 / 1756-IF16 Analog Input Module — Reads process variable (PV) feedback from field transmitters; paired with 1756-OF8 to close the control loop
• 1492-AIFM8-F-5 Analog I/O Field-Side Wiring Module — Provides terminal block interface for 1756-OF8 field wiring; eliminates direct module wiring for easier maintenance
• 1756-EN2T / 1756-EN3TR EtherNet/IP Communication Module — Connects ControlLogix chassis to plant DCS, SCADA, or HMI over EtherNet/IP for remote setpoint and diagnostics
• 20F / 20G PowerFlex VFD — Typical final control element receiving 4–20 mA or 0–10 V speed reference from 1756-OF8 in motor drive applications
• Fisher / Emerson / Flowserve Valve Positioner — Electro-pneumatic positioner receiving 4–20 mA from 1756-OF8 for modulating valve control in process applications

Compliance & Industry Standards

• UL Listed (Underwriters Laboratories) — Confirms electrical safety for installation in North American industrial facilities; required by NEC Article 409 for industrial control panels
• CE Marking (European Commission) — Confirms compliance with EU Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU); required for installation in EU member states
• ATEX Category 3G / Zone 2 (ATEX Directive 2014/34/EU) — Permits installation in enclosures located in Zone 2 explosive atmospheres; relevant for oil & gas and chemical plant installations
• IEC 61131-2 — Programmable controller hardware standard; confirms electrical and environmental performance of the module as a PLC I/O component
• IEC 61508 / IEC 61511 Functional Safety — Module is suitable for use in SIL 2 safety instrumented functions when deployed in redundant ControlLogix configurations; required for safety loops in oil & gas and power generation
• RoHS Compliant (EU Directive 2011/65/EU) — Confirms restriction of hazardous substances; required for CE marking and preferred by environmentally conscious procurement policies

Quality Assurance & Sourcing

Sourcing Channels: Konmask.com sources the 1756-OF8 exclusively through authorized Allen-Bradley distributors, certified surplus dealers with documented chain of custody, and direct OEM decommissioning programs. We do not source from unverified grey-market channels.

4-Step Inspection Process:

1. Visual & Physical Inspection: Connector pin integrity, label authenticity, housing condition, and firmware label verification against Rockwell Automation published revision history
2. Functional Bench Test: Each channel tested for output accuracy (current and voltage modes), resolution, and linearity using calibrated Fluke 789 ProcessMeter; results logged per channel
3. Backplane Communication Test: Module seated in ControlLogix chassis and polled via RSLogix 5000 / Studio 5000 to confirm electronic keying, module identity, and fault-free operation
4. ESD-Safe Packaging & Documentation: Module packed in anti-static bag with desiccant; inspection report, test data sheet, and sourcing declaration enclosed

Available Documentation: Inspection report, functional test data sheet, sourcing declaration / chain of custody, Rockwell Automation product certification copies, and export compliance documentation (HS code, ECCN classification).

How to Source This Part

1. Submit Your Inquiry: Email support@konmask.com with your required quantity, required delivery date, and any firmware revision or series requirements. Alternatively, use the contact form on this page.
2. Receive Quote & Availability Confirmation: Our team responds within 24 business hours with pricing, lead time, inspection report availability, and shipping options. Expedited quoting available for urgent plant shutdowns.
3. Order, Inspect & Deploy: Upon order confirmation, we ship with full documentation package via DHL / FedEx / UPS with tracking. Global shipping to 50+ countries. Import documentation and commercial invoice provided for customs clearance.

Application-Specific FAQ

Q: Can the 1756-OF8 be used for anti-surge control on centrifugal compressors where response time is critical?
A: Yes. The 1756-OF8 updates its output channels synchronously with the ControlLogix controller scan cycle, with configurable RPI as low as 1 ms. This deterministic response is essential for anti-surge applications where valve response delay exceeding 10 ms can result in compressor surge events. Pair with a 1756-L8x controller and a fast-response electro-pneumatic positioner for a complete anti-surge output loop.

Q: Is the 1756-OF8 suitable for pharmaceutical batch process control requiring FDA 21 CFR Part 11 compliance?
A: Yes. The module’s 16-bit resolution and ±0.1% accuracy support the tight setpoint control required in bioreactor and CIP applications. ControlLogix tag history and audit trail functionality in Studio 5000 / FactoryTalk Historian provides the electronic records required for 21 CFR Part 11 compliance. Konmask can provide sourcing documentation to support your equipment qualification (IQ/OQ) package.

Q: Can I mix current and voltage output channels on the same 1756-OF8 module for a multi-loop process control application?
A: Yes. Each of the 8 channels on the 1756-OF8 is independently configurable for current (4–20 mA or 0–20 mA) or voltage (±10 V or 0–10 V) output via software configuration in Studio 5000 — no hardware jumpers or module variants required. This makes the 1756-OF8 ideal for mixed-signal process panels driving both valve positioners (current) and VFDs (voltage) from a single module slot.

---
