Applied Materials 0041-09684 Inner Shield – CVD/PVD Process Chamber Component
When an Inner Shield fails or reaches end-of-life inside a CVD or PVD process chamber, the consequences cascade quickly: uncontrolled particle contamination, wafer yield loss, unplanned downtime, and costly chamber reconditioning. In high-volume semiconductor fabs running 24/7, every hour of unscheduled maintenance translates directly into lost revenue and missed delivery commitments. The Applied Materials Inner Shield (P/N 0041-09684, cross-ref: 4022.261.8378 / 3842503590) is the precision-engineered barrier that stands between your process integrity and these failures.
Within the Applied Materials CVD/PVD chamber ecosystem, this Inner Shield occupies a critical position: it lines the interior chamber wall to intercept stray deposition flux and plasma byproducts, protecting the chamber body from erosion and contamination buildup. Applied Materials is the world’s largest supplier of semiconductor equipment, and its chamber consumables—including this Inner Shield—are manufactured to exacting tolerances that third-party alternatives rarely match. Sourcing the correct OEM-spec part is not optional in advanced node fabs; it is a process qualification requirement.
Technical Specifications
- Manufacturer: Applied Materials (AMAT)
- Part Number: 0041-09684
- Cross-Reference: 4022.261.8378 | 3842503590 | TXZ 0041-09684
- Component Type: Inner Shield / Chamber Liner
- Compatible Process: CVD / PVD Process Chambers
- Material: High-purity aluminum alloy (anodized or coated per OEM spec)
- Weight: 2,600 g (approx.)
- Condition: New / Refurbished OEM-spec (specify on inquiry)
- Compliance: OEM-equivalent specification
Key Features & Benefits
- OEM-Equivalent Precision: Manufactured or sourced to Applied Materials dimensional and surface-finish specifications, ensuring drop-in fit without chamber re-qualification delays.
- Contamination Barrier: Intercepts deposition byproducts and plasma species before they reach the chamber body, extending chamber service intervals.
- Yield Protection: Reduces particle-induced wafer defects by maintaining a clean, controlled deposition environment throughout the PM cycle.
- Rapid PM Turnaround: Designed for straightforward swap-out during scheduled preventive maintenance, minimizing chamber downtime.
- Multi-PN Compatibility: Verified cross-reference to 4022.261.8378 and 3842503590, simplifying procurement across different fab ERP systems.
- Global Supply Availability: Stocked and shipped internationally from Konmask.com with full traceability documentation available on request.
Industry & Equipment Applications
- Semiconductor wafer fabrication (logic, memory, foundry)
- Applied Materials CVD systems (e.g., Centura, Producer platform chambers)
- Applied Materials PVD systems (e.g., Endura platform)
- Flat panel display (FPD) deposition equipment
- Advanced packaging and MEMS process chambers
- R&D and pilot-line semiconductor tools requiring OEM-spec consumables
System Integration & Compatible Parts
The Inner Shield (0041-09684) is typically replaced as part of a broader chamber PM kit. Compatible and commonly co-ordered parts include:
- Outer Shield / Chamber Liner
- Shadow Ring / Edge Ring
- Showerhead / Gas Distribution Plate
- Electrostatic Chuck (ESC) components
- Slit Valve Door Seal
- Foreline Trap and Pump components
Contact our technical team to build a complete PM kit quotation for your specific chamber configuration.
Our Quality Assurance Process
- Source Verification: All parts are sourced from authorized distributors or directly from OEM-certified supply chains.
- Incoming Inspection: Physical inspection for dimensional conformance, surface integrity, and packaging condition upon receipt.
- Documentation: Certificate of Conformance (CoC) and traceability records available upon request.
- Packaging: Anti-static, cleanroom-compatible packaging to prevent contamination during transit.
- Export Compliance: All shipments processed in accordance with applicable export control regulations.
How to Order
- Submit an Inquiry: Use the contact form or email [email protected] with your part number, required quantity, and destination country.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and shipping options.
- Confirm & Pay: Approve the proforma invoice and complete payment via T/T, PayPal, or other agreed method.
- Shipment & Tracking: Parts are dispatched with full tracking; shipping documents provided for customs clearance.
Why Choose Konmask.com?
- Specialized in industrial automation and semiconductor equipment spare parts
- Global B2B supply with experience serving fabs across Asia, Europe, and the Americas
- Technical team with hands-on knowledge of AMAT chamber systems
- Competitive pricing with full documentation and traceability
- Responsive inquiry handling — most RFQs answered within 24 hours
Frequently Asked Questions
Q: Is this an OEM Applied Materials part or an aftermarket replacement?
A: We supply both OEM-original and OEM-equivalent parts depending on availability and customer preference. Please specify your requirement when submitting an inquiry.
Q: What is the lead time for P/N 0041-09684?
A: Lead time varies by stock status. In-stock items typically ship within 3–5 business days. Please contact us for current availability.
Q: Can you supply a Certificate of Conformance?
A: Yes. CoC and traceability documentation are available upon request for all parts.
Q: Do you ship internationally?
A: Yes. We ship globally. Please provide your destination country when requesting a quote so we can advise on shipping options and estimated transit times.
Q: Can I order multiple part numbers in one shipment?
A: Absolutely. We encourage consolidated orders to reduce shipping costs. Contact us to build a complete PM kit quotation.
