Applied Materials 0150-19536 RF Filter Box Assembly – Centura/Producer Series
When an RF filter box fails mid-process in a CVD or PVD chamber, the consequences are immediate and costly: plasma ignition becomes unstable, process uniformity collapses, and the entire wafer batch is at risk of rejection. Unplanned downtime in a semiconductor fab can cost tens of thousands of dollars per hour. The RF Filter Box Assembly is not a peripheral accessory — it is a critical impedance-matching and noise-isolation component that protects both the RF generator and the process chamber from destructive interference, making it irreplaceable in high-frequency plasma process environments.
The Applied Materials part number 0150-19536 (cross-references: 45100422, 945Y2NC/NCFSFFFA, P500, 7KG7500-0AA02-0AA0/CC) is engineered for the Centura and Producer platform process chambers. Within the Applied Materials RF power delivery ecosystem, this assembly occupies the critical junction between the RF match network and the chamber electrode, filtering harmonics and transient spikes that would otherwise degrade thin-film deposition quality. Applied Materials remains the world’s largest supplier of semiconductor equipment, and components like this one underpin the yield performance of fabs producing logic, memory, and advanced packaging devices globally.
Technical Specifications
- Part Number: 0150-19536
- Cross Reference: 45100422 / 945Y2NC / NCFSFFFA / P500 / 7KG7500-0AA02-0AA0/CC
- Description: RF Filter Box Assembly
- OEM Brand: Applied Materials (AMAT)
- Compatible Platform: Centura, Producer Series Process Chambers
- Function: RF harmonic filtering, noise isolation, impedance protection
- Weight: 2,600 g (approx. 2.6 kg)
- Condition: New / Refurbished / Used — specify on inquiry
Key Features & Benefits
- OEM-Grade Filtering Performance: Maintains RF signal integrity between the match network and chamber electrode, ensuring stable plasma ignition and consistent process results.
- Multi-PN Compatibility: Verified cross-reference across multiple Applied Materials internal part numbers (45100422, 945Y2NC, NCFSFFFA, P500, 7KG7500-0AA02-0AA0/CC), reducing sourcing confusion.
- Protects Upstream Equipment: Shields RF generators and match networks from reflected power and harmonic distortion, extending the service life of high-value capital equipment.
- Drop-In Replacement: Designed to OEM mechanical and electrical specifications for direct installation without modification.
- Reduces Unplanned Downtime: Stocking this assembly as a critical spare eliminates multi-week lead times from OEM channels during emergency breakdowns.
Industry & Equipment Applications
- Semiconductor Fabrication: CVD (Chemical Vapor Deposition), PVD (Physical Vapor Deposition), and Etch process chambers requiring stable RF power delivery.
- Logic & Memory Device Manufacturing: Advanced node fabs (28nm and below) where process uniformity is critical to yield.
- Advanced Packaging: Fan-out wafer-level packaging (FOWLP) and 3D IC integration processes.
- Flat Panel Display (FPD) Production: Large-area PECVD systems with similar RF filter requirements.
- Research & Development Labs: University and corporate R&D facilities operating Applied Materials Centura or Producer platforms.
System Integration & Compatible Parts
This RF Filter Box Assembly is designed to integrate within the Applied Materials RF power delivery chain. Commonly paired or replaced alongside:
- RF Match Network / Auto-Tuner (AMAT Centura series)
- RF Generator (13.56 MHz / 2 MHz dual-frequency configurations)
- Chamber Electrode Assembly
- RF Cable Harness and Coaxial Connectors
- Process Kit Components (liners, rings, shields)
Contact our technical team to verify compatibility with your specific chamber configuration and software revision.
Our Quality Assurance Process
- Source Verification: All parts are sourced from traceable supply chains including OEM surplus, certified refurbishers, and decommissioned fab equipment.
- Visual & Dimensional Inspection: Each unit is inspected for physical damage, connector integrity, and label/PN verification before listing.
- Functional Testing (where applicable): Refurbished units undergo electrical continuity and RF isolation testing prior to shipment.
- Secure Packaging: ESD-safe packaging with anti-static foam inserts and moisture barrier bags for international shipping.
- Documentation: Certificate of conformance and inspection report available upon request.
How to Order
- Submit an inquiry via the Contact Us page or email support@konmask.com.
- Provide your part number, required quantity, and preferred condition (new/refurbished/used).
- Our team will respond with availability, lead time, and a formal quotation within 24 hours.
- Upon PO confirmation, we arrange secure packaging and international freight (DHL / FedEx / UPS / sea freight).
- Shipping documents including commercial invoice, packing list, and COC are provided for customs clearance.
Why Choose Konmask.com?
- Specialized in Industrial Automation & Semiconductor Spare Parts: We focus exclusively on hard-to-find OEM components for global fabs and automation facilities.
- Global Sourcing Network: Access to surplus inventory from decommissioned fabs across Asia, North America, and Europe.
- Fast Response: Dedicated B2B inquiry team with <24-hour quote turnaround.
- Competitive Pricing: Direct sourcing eliminates unnecessary intermediary markups.
- Export Compliance: Experienced in international trade documentation, export licensing, and customs requirements for semiconductor equipment parts.
- Long-Term Partnership: We support procurement teams, maintenance engineers, and equipment brokers with ongoing supply agreements.
Frequently Asked Questions
- Q: Is part number 0150-19536 the same as 45100422 or 945Y2NC?
- A: Yes. These are all cross-reference part numbers for the same Applied Materials RF Filter Box Assembly used on Centura and Producer platform chambers. Always verify with your chamber BOM before ordering.
- Q: Do you offer new or refurbished units?
- A: We can supply new (OEM surplus), certified refurbished, and used/tested units depending on availability. Please specify your preference in your inquiry.
- Q: What is the lead time for this part?
- A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. Out-of-stock items may require 2–6 weeks for sourcing. Contact us for current availability.
- Q: Can you provide a certificate of conformance (COC)?
- A: Yes. A COC and inspection report are available upon request for all units.
- Q: Do you ship internationally?
- A: Yes. We ship worldwide via DHL, FedEx, UPS, and sea freight. We handle all export documentation including commercial invoice, packing list, and customs declarations.
- Q: What warranty do you offer?
- A: Warranty terms depend on the condition of the unit supplied. Please discuss warranty requirements with our sales team at the time of inquiry.
