Genuine Applied Materials 0190-21067 ASSY Filter/Diffuser Loadlock | ALD Series – Verified Source
The Applied Materials 0190-21067 is an OEM-grade Assembly Filter/Diffuser for Loadlock chambers, cross-referenced under part numbers ALD1244, PTC0200, and 3520784. Sourced through verified supply channels and quality-inspected before shipment, this component is engineered to maintain cleanroom-grade gas flow integrity in advanced semiconductor fabrication equipment.
Technical Specifications
- Manufacturer: Applied Materials (AMAT)
- Primary Part Number: 0190-21067
- Cross-Reference SKUs: ALD1244 | PTC0200 | 3520784
- Description: ASSY Filter/Diffuser – Loadlock Chamber
- Series: ALD (Atomic Layer Deposition) Platform
- Component Type: Filter/Diffuser Assembly
- Application Zone: Loadlock Chamber
- Weight: ~800 g
- Condition: New / Refurbished (specify on inquiry)
- Origin: United States
Our 4-Step Quality Verification Process
- Step 1 – Source Authentication: All Applied Materials parts are procured from authorized distributors, OEM surplus channels, or certified refurbishers with traceable documentation.
- Step 2 – Physical Inspection: Each unit undergoes dimensional and visual inspection against OEM specifications — checking filter media integrity, diffuser uniformity, and assembly completeness.
- Step 3 – Functional Validation: Where applicable, components are bench-tested or cross-checked against known-good reference units to confirm operational readiness.
- Step 4 – Secure Packaging: Parts are cleaned, anti-static bagged, and packed in rigid protective packaging with part number labeling to prevent transit damage and misidentification.
Key Features & Benefits
- OEM-matched filter/diffuser geometry for precise loadlock gas distribution
- Maintains cleanroom compatibility — suitable for Class 1–100 environments
- Reduces particle contamination risk during wafer transfer sequences
- Drop-in replacement — no modification required for compatible AMAT platforms
- Traceable part numbers across multiple AMAT internal SKU systems (ALD1244 / PTC0200 / 3520784)
- Available with documentation support (COC, inspection report) upon request
Typical Applications
- ALD (Atomic Layer Deposition) Systems: Loadlock chamber gas purge and pressure equalization cycles
- CVD / PVD Platforms: Wafer transfer environment isolation and contamination control
- Cluster Tool Integration: Inter-chamber atmospheric isolation in multi-process AMAT mainframes
- Fab Maintenance & Overhaul: Scheduled PM replacement for loadlock filter/diffuser assemblies
- Spare Parts Inventory: Critical spare for fabs running AMAT ALD or related deposition platforms
Compatible System Components
- Applied Materials ALD mainframe loadlock chambers
- AMAT PTC-series process tool configurations
- Compatible with systems referencing 3520784 / ALD1244 / PTC0200 in BOM documentation
- Consult your AMAT system manual or contact us with your tool model for fit confirmation
Global Sourcing & Shipping Capabilities
- Stock Location: China (Fujian) — with global export capability
- Lead Time: In-stock items ship within 3–5 business days; sourced items 7–21 days
- Shipping Methods: DHL Express, FedEx International Priority, sea freight for bulk orders
- Export Compliance: All shipments comply with applicable export control regulations (EAR/ECCN review conducted per destination)
- Customs Documentation: Commercial invoice, packing list, and COO provided as standard
- Regions Served: Asia-Pacific, Europe, North America, Middle East, Southeast Asia
Certifications & Compliance Statement
- Parts sourced from ISO 9001-certified supply chain partners where applicable
- RoHS compliance status available upon request
- All refurbished units cleaned and inspected per semiconductor industry handling standards
- Konmask.com operates as an independent distributor — not an authorized AMAT reseller; OEM trademarks are referenced for identification purposes only
How to Order
- Submit Inquiry: Email support@konmask.com with your required quantity, destination, and any urgency requirements.
- Receive Quote: We respond within 1 business day with pricing, lead time, and availability confirmation.
- Confirm & Pay: Secure payment via T/T (bank transfer), PayPal, or other agreed methods.
- Ship & Track: Parts dispatched with full tracking; shipping documents provided electronically.
Authenticity & Trust FAQ
Q: Are these genuine Applied Materials parts?
A: Yes. We source from verified OEM surplus, authorized distributors, and certified refurbishers. Documentation is available upon request.
Q: Can you provide a Certificate of Conformance (COC)?
A: Yes, COC and inspection reports are available for most items. Please specify your requirement at the time of inquiry.
Q: What if the part doesn’t fit my system?
A: We offer a return/exchange policy for incorrectly supplied parts. Please verify the part number against your system BOM before ordering.
Q: Do you ship to restricted countries?
A: All exports are subject to applicable trade compliance review. We will advise if any restrictions apply to your destination.
Q: How do I confirm this part is compatible with my AMAT tool?
A: Provide your tool model and serial number via email — our technical team will cross-reference against AMAT BOM records.
