Bently Nevada 136188-01 – Ethernet Communication Module | 3500 Series Platform
Engineering Background
The Bently Nevada 3500 Series is the industry-standard machinery protection and condition monitoring platform deployed across power generation, oil & gas, petrochemical, and rotating equipment facilities worldwide. The 136188-01 Ethernet Communication Module provides the critical network interface layer that enables real-time data exchange between the 3500 rack and plant-level DCS, SCADA, or historian systems via standard Ethernet protocols.
Product Positioning
Designed for procurement engineers and reliability teams requiring a verified, drop-in replacement or expansion module for existing 3500 Series installations. The 136188-01 eliminates serial communication bottlenecks by delivering high-speed Ethernet connectivity without requiring rack reconfiguration, making it the preferred upgrade path for modernization projects.
Complete Technical Specifications
- Part Number: 136188-01
- Manufacturer: Bently Nevada (Baker Hughes)
- Platform: 3500 Series Machinery Protection System
- Module Type: Ethernet Communication Module
- Communication Interface: Ethernet (10/100 Base-T)
- Protocol Support: Modbus TCP/IP, OPC (via gateway), proprietary Bently Nevada network protocol
- Connector Type: RJ-45
- Power Supply: Supplied via 3500 rack backplane
- Operating Temperature: 0°C to +60°C (32°F to 140°F)
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Weight: 380 g
- Country of Origin: United States
- Compliance: CE, UL, CSA (refer to OEM documentation for full certification list)
Proven Application Environments
- Gas turbine and steam turbine protection systems
- Compressor train monitoring in LNG and refinery facilities
- Pump and motor condition monitoring networks
- Power plant DCS integration projects
- Offshore platform machinery protection racks
- Modernization of legacy serial-based 3500 installations to Ethernet backbone
Engineering Advantages
- Seamless Rack Integration: Installs directly into the 3500 rack without firmware changes or rack reconfiguration
- High-Speed Data Transfer: 10/100 Mbps Ethernet eliminates serial communication latency for time-critical alarm and trip data
- Protocol Flexibility: Supports Modbus TCP/IP for broad DCS/SCADA compatibility
- Redundancy Ready: Compatible with redundant network architectures for SIL-rated installations
- Reduced Wiring Complexity: Single Ethernet cable replaces multiple serial runs, lowering installation and maintenance costs
- Long Service Life: Industrial-grade components rated for continuous 24/7 operation in harsh environments
System Architecture & Signal Flow
The 136188-01 module occupies a dedicated communication slot within the 3500 rack. Vibration, position, and process data collected by transducer input modules are aggregated on the rack backplane and transmitted via the Ethernet module to the plant network. The module supports simultaneous connections to multiple clients (DCS, historian, HMI), enabling parallel data access without impacting protection system scan rates. Network configuration is performed through Bently Nevada’s System 1 or rack configuration software.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified industrial surplus channels
- Each module undergoes visual inspection, label verification, and functional pre-shipment check
- Original OEM packaging preserved where available; securely repackaged for international transit where not
- Traceability documentation (serial number, revision level) provided upon request
- Counterfeit-risk mitigation: part markings, PCB revision, and connector integrity verified against OEM reference
Procurement Process
- Confirm part number 136188-01 matches your rack slot and firmware revision requirements
- Contact Konmask for real-time stock confirmation and lead time: support@konmask.com | +0086 19859288691
- Receive formal quotation with unit price, quantity, and shipping terms (EXW / DDP available)
- Submit PO; payment via T/T, PayPal, or trade finance terms for qualified accounts
- Shipment with tracking; export documentation (commercial invoice, packing list, COO) included
- Post-delivery technical support available for installation and commissioning queries
Technical FAQ
Q: Is the 136188-01 compatible with all 3500 rack configurations?
A: The module is designed for the standard 3500 Series rack. Verify your rack’s firmware version and available communication slots before ordering. Contact us for compatibility confirmation.
Q: What network protocols does this module support?
A: The 136188-01 supports Modbus TCP/IP natively. OPC connectivity is achievable via a gateway server running Bently Nevada’s System 1 software.
Q: Can this module be used in a redundant network setup?
A: Yes. The module supports dual-network configurations when paired with appropriate rack and switch infrastructure for high-availability installations.
Q: What is the warranty on this unit?
A: Konmask provides a 90-day functional warranty on all verified modules. Extended warranty options are available — contact our sales team for details.
Q: Do you provide export documentation for customs clearance?
A: Yes. Full export documentation including commercial invoice, packing list, and certificate of origin is provided with every international shipment.
