Bently Nevada 190501-09-00-00 Keyphasor Module | Replacement, Equivalent & Selection Guide
The Bently Nevada 190501-09-00-00 is a Keyphasor Module designed for use within the Bently Nevada 3500 Series machinery protection system. It provides precise once-per-revolution reference signals essential for phase measurement, dynamic balancing, and torsional vibration analysis in rotating machinery.
Technical Specifications
- Part Number: 190501-09-00-00
- Brand: Bently Nevada (Baker Hughes)
- Series: 3500 Machinery Protection System
- Module Type: Keyphasor Module
- Function: Once-per-revolution phase reference signal generation
- Output: Keyphasor signal compatible with 3500 rack monitors
- Power Supply: Supplied via 3500 rack backplane
- Mounting: 3500 Series rack-mount slot
- Weight: 380 g (approx.)
- Operating Temperature: 0°C to +65°C
- Certifications: CE, SIL, FM (per Bently Nevada 3500 system approvals)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the 190501-09-00-00. Always verify electrical and mechanical compatibility before substitution:
- Bently Nevada 190501-01-00-00 — Standard Keyphasor Module, earlier revision; verify firmware compatibility
- Bently Nevada 190501-02-00-00 — Alternate configuration variant; confirm rack slot assignment
- Bently Nevada 3500/25 — Keyphasor I/O Module (newer platform); requires 3500/25 rack support
- Emerson 190501-09-00-00 — OEM-equivalent under Emerson/Baker Hughes branding
- Third-party compatible modules — Contact Konmask for vetted cross-reference options
Note: Cross-brand substitution requires full system validation. Konmask engineers can assist with compatibility assessment.
Why Choose the Original Model
- ✅ Guaranteed system compatibility with Bently Nevada 3500 rack architecture
- ✅ Factory-calibrated for precise Keyphasor signal timing
- ✅ SIL-rated for safety-critical rotating machinery applications
- ✅ Firmware-matched to existing 3500 system configurations
- ✅ Full OEM traceability and documentation support
- ✅ Minimizes re-commissioning risk versus third-party alternatives
Typical Applications
- Steam and gas turbine phase reference monitoring
- Compressor and pump torsional vibration analysis
- Dynamic balancing of rotating shafts
- Synchronous speed tracking in power generation
- Machinery protection systems in oil & gas, petrochemical, and power plants
System Compatibility
- Primary Platform: Bently Nevada 3500 Machinery Protection System
- Rack Compatibility: 3500/05 Power Supply Rack and standard 3500 racks
- Monitor Compatibility: 3500/40M, 3500/42M, 3500/44M, 3500/46M, 3500/50M, 3500/60M, 3500/72M
- Software: System 1 Condition Monitoring Software (Emerson)
- Communication: Compatible with 3500 rack Modbus and Ethernet gateway modules
Selection Guide
Use the following criteria to confirm the correct Keyphasor module for your application:
- Step 1 — Identify rack type: Confirm your 3500 rack model and available slot positions
- Step 2 — Check revision: Match the -09-00-00 suffix to your existing system BOM or as-built drawings
- Step 3 — Verify sensor type: Confirm proximity probe or magnetic pickup input compatibility
- Step 4 — Confirm output requirements: Ensure Keyphasor output voltage and signal format match downstream monitors
- Step 5 — Consult Konmask: For multi-channel or redundant Keyphasor configurations, contact our engineering team
Quality Assurance & Sourcing
- 🔍 Source: Authorized distribution channels and verified surplus inventory
- 🔍 Inspection: Each unit inspected for physical integrity and label authenticity
- 🔍 Warranty: 12-month replacement warranty against manufacturing defects
- 🔍 Documentation: Certificate of conformance and test reports available on request
- 🔍 Anti-counterfeit: Konmask sources only from traceable supply chains
How to Order
- Add 190501-09-00-00 to cart or contact us directly for bulk/project pricing
- Provide your rack model and system configuration for compatibility confirmation
- Receive quotation within 1 business day
- Worldwide shipping available — DHL, FedEx, UPS express options
- Lead time: In-stock units ship within 3–5 business days
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can 190501-09-00-00 replace 190501-01-00-00?
A: Potentially yes, but firmware and rack slot compatibility must be verified. Contact Konmask for a compatibility check.
Q: Is this module compatible with the Bently Nevada 3300 system?
A: No. The 190501-09-00-00 is designed exclusively for the 3500 Series rack architecture.
Q: Can I use a third-party Keyphasor module in a 3500 rack?
A: Third-party modules may function but are not recommended for SIL-rated or safety-critical applications without full validation.
Q: What is the difference between 190501-09-00-00 and 3500/25?
A: The 3500/25 is a newer I/O module platform with enhanced diagnostics; the 190501-09-00-00 is the legacy dedicated Keyphasor module. Both serve the same function but are not directly interchangeable.
Q: Do you offer repair or exchange service?
A: Yes. Konmask offers repair evaluation and exchange programs. Contact us for details.
