Turbomachinery Vibration Monitoring Solution – Bently Nevada 31000-27-05-15-040-03-02 | 3300 Series
Where This Product Is Used
The Bently Nevada 31000-27-05-15-040-03-02 Proximity Probe Housing Assembly is engineered for continuous, non-contact shaft vibration and position measurement in rotating machinery. Typical deployment environments include:
- Steam and gas turbines in power generation plants
- Centrifugal and axial compressors in oil & gas processing
- Boiler feed pumps and large industrial pumps
- Gearboxes and expanders in petrochemical facilities
- Marine propulsion shafting systems
- High-speed spindles in precision manufacturing
This housing assembly secures and aligns the proximity probe tip at the precise radial or axial gap required by API 670 machinery protection standards, ensuring measurement integrity under high-temperature, high-vibration plant conditions.
Technical Specifications
- Part Number: 31000-27-05-15-040-03-02
- Series: Bently Nevada 3300 Series
- Assembly Type: Proximity Probe Housing Assembly
- Measurement Principle: Eddy-current non-contact displacement
- Compatible Probe Tip Diameter: 8 mm (standard 3300 XL series)
- Thread / Mounting: Per OEM specification (refer to installation drawing)
- Cable Length / Extension: Per part number suffix configuration
- Operating Temperature: –40 °C to +177 °C (probe tip)
- Weight: Approx. 1,500 g (complete assembly)
- Country of Origin: USA (Baker Hughes / Bently Nevada)
Why Engineers Specify This Model
- Drop-in OEM replacement – exact dimensional match to original Bently Nevada 3300 Series installations; no re-machining of bearing housings required.
- API 670 compliant geometry – housing maintains the critical probe-to-shaft gap tolerance (±0.025 mm) demanded by machinery protection standards.
- Corrosion-resistant construction – stainless steel body withstands lube-oil, process gas, and steam environments.
- Plug-and-play with 3300 XL monitors – direct compatibility with Bently Nevada 3300/16 and 3500 series monitoring racks without signal conditioning changes.
- Reduced downtime risk – pre-assembled and factory-tested; ready for installation without field calibration of the housing itself.
Complete System Bill of Materials
For a fully functional Bently Nevada eddy-current measurement loop, the following components are typically required alongside this housing assembly:
- Proximity Probe (e.g., 330103-00-06-10-02-00)
- Extension Cable (e.g., 330130-080-00-00)
- Proximitor® Sensor / Signal Conditioner (e.g., 3300 XL 8 mm)
- Bently Nevada 3500 or 3300 Monitor Rack
- Keyphasor® Transducer (for phase reference, if required)
- Mounting hardware: locknut, jam nut, and anti-rotation bracket
Contact support@konmask.com for complete loop quotations.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems
- API 670 Annex D – Eddy-Current Transducer Systems
- ISO 10816 / ISO 20816 – Mechanical Vibration Evaluation
- IEC 61511 – Functional Safety (SIL-rated system integration)
- CE Marking (where applicable per regional import requirements)
Quality Assurance & Sourcing
Konmask.com sources the Bently Nevada 31000-27-05-15-040-03-02 through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual and dimensional inspection against OEM drawings
- Part number and label verification
- Packaging integrity check (anti-static, moisture-barrier where required)
- Documentation review: datasheet, certificate of conformance (CoC) available on request
New, surplus-new, and reconditioned stock options may be available. Condition is clearly stated at time of quotation.
How to Source This Part
- Add to cart and proceed to checkout for in-stock units.
- Request a quote for bulk orders (>3 units), expedited delivery, or specific condition requirements.
- Email us at support@konmask.com with your plant tag number, required delivery date, and any interchangeability questions.
- Call / WhatsApp: +0086 19859288691 for urgent plant shutdowns or turnaround (TAR) support.
Global shipping available. Export documentation (commercial invoice, packing list, COO) provided for all international orders.
Application-Specific FAQ
Q: Is the 31000-27-05-15-040-03-02 compatible with the Bently Nevada 3500 monitoring system?
A: Yes. The 3300 Series probe and housing assemblies are fully compatible with the 3500 rack when used with the appropriate Proximitor sensor. Verify the gap voltage range matches your monitor card input specification.
Q: Can this housing be used for axial position measurement as well as radial vibration?
A: The housing configuration (radial vs. axial) is determined by the suffix digits in the part number. The -03-02 suffix in this model indicates a specific orientation — confirm against your OEM installation drawing before ordering for axial duty.
Q: What is the recommended probe gap for this assembly?
A: Standard Bently Nevada 8 mm probes are gapped to approximately 1.0 mm (–10 VDC output at mid-range). Always verify against the specific Proximitor sensor calibration sheet supplied with your system.
Q: Do you provide a Certificate of Conformance?
A: Yes. A CoC is available upon request for all orders. Traceability documentation can be provided for critical service applications.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, typical lead time is 2–6 weeks depending on source availability. Contact us for real-time stock status.
