Bently Nevada 32000-28-05-15-080-03-02 – Proximity Probe Housing Assembly | 3300 XL Series Platform
Engineering Background
The Bently Nevada 3300 XL Series represents the industry benchmark for eddy-current proximity sensing in rotating machinery protection systems. Designed to meet API 670 requirements, these assemblies are deployed globally in turbines, compressors, pumps, and generators where continuous shaft vibration and position monitoring is mission-critical.
Product Positioning
Part number 32000-28-05-15-080-03-02 is a fully configured proximity probe housing assembly engineered for direct integration into Bently Nevada 3300 XL monitoring racks. It delivers reliable non-contact displacement measurement with high signal fidelity, making it the preferred choice for procurement engineers sourcing OEM-equivalent replacement components for critical rotating equipment.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 32000-28-05-15-080-03-02 |
| Series / Platform | Bently Nevada 3300 XL |
| Component Type | Proximity Probe Housing Assembly |
| Sensing Technology | Eddy-Current (Non-Contact) |
| Probe Tip Diameter | 8 mm (nominal) |
| Cable Length | 5 m (standard configuration) |
| Extension Cable | Included per assembly code |
| Operating Temperature | -35°C to +177°C (probe tip) |
| Target Material | Steel / Stainless Steel (AISI 4140 reference) |
| Output Signal | -24 VDC bias, linear voltage output |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 0.25 mm – 2.54 mm (10–100 mil) |
| Connector Type | BNC / Per Bently Nevada standard |
| Housing Material | Stainless Steel |
| IP Rating | IP67 (sealed assembly) |
| Compliance | API 670, CE |
| Weight | Approx. 300 g (complete assembly) |
| Country of Origin | United States |
Proven Application Environments
- Steam & Gas Turbines – Shaft radial vibration and axial position monitoring per API 670
- Centrifugal Compressors – Continuous rotor orbit and gap measurement in high-pressure service
- Pumps & Fans – Bearing housing displacement monitoring for predictive maintenance programs
- Generators & Motors – Shaft eccentricity and differential expansion measurement
- Gearboxes – Gear mesh frequency analysis and shaft runout detection
- Marine & Offshore Machinery – Vibration protection in harsh, high-humidity environments
Engineering Advantages
- OEM-Equivalent Performance – Maintains full signal chain compatibility with Bently Nevada 3300 XL monitors and drivers
- High-Temperature Stability – Calibrated output remains linear across the full operating temperature range
- Sealed Housing – IP67-rated stainless steel construction resists oil mist, process fluids, and mechanical vibration
- Plug-and-Play Integration – Pre-assembled and factory-calibrated; no field calibration required on installation
- Long Service Life – Non-contact sensing eliminates mechanical wear; designed for continuous 24/7 operation
- API 670 Compliant – Meets the international standard for machinery protection systems
System Architecture & Signal Flow
The 32000-28-05-15-080-03-02 assembly operates as part of a three-component eddy-current system:
- Proximity Probe (this assembly) – Generates a high-frequency electromagnetic field; detects shaft surface displacement via eddy-current effect
- Extension Cable – Transmits the raw oscillator signal from probe tip to driver with minimal signal loss
- Proximitor® Driver / Oscillator-Demodulator – Converts the raw signal to a calibrated DC voltage proportional to gap distance, fed to the 3300 XL monitor
The monitor then processes the signal for vibration amplitude, phase, and DC gap, triggering alarms or shutdowns per configured setpoints.
Sourcing & Quality Verification
- All units sourced through verified industrial automation supply channels
- Each assembly inspected for housing integrity, connector condition, and cable continuity prior to dispatch
- Original manufacturer markings, labels, and date codes preserved and documented
- Traceability documentation available upon request for regulated industries
- Packaging: anti-static, moisture-barrier bag with rigid outer carton
Procurement Process
- Confirm Part Number – Verify 32000-28-05-15-080-03-02 against your BOM or existing installation tag
- Request Quote – Contact [email protected] or call +0086 19859288691 for volume pricing and lead time
- Order Confirmation – Purchase order accepted; stock availability confirmed within 24 hours
- Dispatch & Tracking – Ships with full tracking; express options available for urgent plant shutdowns
- After-Sales Support – Technical assistance available for installation verification and signal commissioning
Technical FAQ
Q: Is this assembly compatible with the Bently Nevada 3300 XL monitor?
A: Yes. The 32000-28-05-15-080-03-02 is designed for direct use within the 3300 XL system architecture, maintaining full signal chain compatibility.
Q: Does this require a separate Proximitor driver?
A: Yes. The probe assembly requires a compatible Bently Nevada Proximitor® oscillator-demodulator (sold separately) to produce the calibrated output voltage.
Q: Can this probe be used on non-ferrous target materials?
A: The standard calibration is optimized for AISI 4140 steel. Use on non-ferrous targets (aluminum, titanium) requires recalibration — contact our technical team for guidance.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For out-of-stock items, lead time is typically 2–4 weeks. Contact us for current availability.
Q: Do you provide a warranty?
A: Yes. All units carry a 90-day functional warranty covering manufacturing defects. Extended warranty options are available on request.
