Bently Nevada 330101-00-14-10-10-02-05 Extension Cable | Replacement, Equivalent & Selection Guide
The Bently Nevada 330101-00-14-10-10-02-05 is a precision extension cable designed for use in the 3300 Series Proximity Transducer System. It serves as the signal-carrying link between the proximity probe and the Proximitor® sensor, maintaining signal integrity in demanding industrial environments. This guide covers technical specifications, compatible replacements, and selection criteria to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: 330101-00-14-10-10-02-05
- Series: 3300 XL / 3300 NSv Proximity Transducer System
- Cable Type: Extension Cable (Proximitor® Extension)
- Cable Length: 14 ft (4.27 m)
- Connector (Probe End): 10-32 UNF coaxial connector
- Connector (Proximitor End): 10-32 UNF coaxial connector
- Temperature Range: -40°C to +121°C (-40°F to +250°F)
- System Compatibility: 3300 XL, 3300 NSv, 3300 RAM
- Weight: Approx. 240 g
- Manufacturer: Bently Nevada (Baker Hughes)
Specifications based on standard Bently Nevada 3300 series documentation. Always verify with the official datasheet for your specific installation.
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents. Compatibility depends on probe gap, system configuration, and target material — always verify before substitution.
- 330101-00-14-10-02-02-05 — Same length, different armor/jacket option; verify connector compatibility
- 330101-00-14-10-10-00-05 — Standard jacket variant; suitable for non-armored installations
- 330130-080-00-00 — 3300 NSv series extension cable, 8 m; verify system pairing
- 330180-X-XX — 3300 RAM series extension; confirm Proximitor model before use
- Third-party equivalents: Metrix, Wilcoxon, and other OEM-compatible cables — contact Konmask for cross-reference validation
⚠️ Important: The total cable length (probe + extension) must equal the calibrated system length (typically 5 m or 9 m). Mixing lengths without recalibration will affect output accuracy.
Why Choose the Original Model
- Factory calibration: Matched to Bently Nevada Proximitor® sensors for guaranteed linearity and gap voltage accuracy
- Signal integrity: Precision coaxial construction minimizes noise and signal loss
- Durability: Rated for high-vibration, high-temperature industrial environments
- Compliance: Meets API 670 requirements for machinery protection systems
- Traceability: Full OEM documentation and calibration certificates available
Typical Applications
- Radial vibration monitoring on rotating machinery (turbines, compressors, pumps)
- Axial position / thrust measurement on centrifugal compressors
- Differential expansion monitoring on steam turbines
- Speed and phase reference measurement (Keyphasor®)
- Eccentricity monitoring on large slow-speed machines
System Compatibility
The 330101-00-14-10-10-02-05 is designed for the following Bently Nevada system configurations:
- 3300 XL Proximity Transducer System — Standard industrial machinery protection
- 3300 NSv Proximity Transducer System — Low-power, intrinsically safe variant
- 3300 RAM Proximity Transducer System — High-temperature applications
- System 1® / System 1 Evolution — Compatible when used with matched Proximitor® sensors
Not compatible with 7200 series or 9000 series proximity systems without adapter verification.
Selection Guide
Use the part number structure to select the correct extension cable:
- 330101 — Base model: 3300 series extension cable
- -00- — Standard configuration
- -14- — Cable length: 14 ft (4.27 m)
- -10- — Connector type: 10-32 UNF (probe end)
- -10- — Connector type: 10-32 UNF (Proximitor end)
- -02- — Armor/jacket option
- -05 — Temperature/environmental rating
Common length options: 5 ft, 10 ft, 14 ft, 25 ft, 50 ft. Total system cable length (probe + extension) must match the calibrated gap range of your Proximitor® sensor.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Pre-shipment inspection: visual, dimensional, and connector integrity checks
- Original OEM packaging preserved where available
- Calibration certificates and material traceability documents available on request
- Export compliance: ECCN classification and customs documentation provided for international orders
How to Order
- Confirm your current system: probe model, Proximitor® model, and existing cable length
- Verify total system cable length requirement (5 m or 9 m standard)
- Select this listing or contact us for volume pricing and lead time
- Provide your PO number, shipping address, and any required documentation (COC, MSDS)
- Orders typically ship within 1–3 business days; expedited options available
📧 Contact: support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I use a third-party extension cable with my Bently Nevada Proximitor®?
A: Technically possible, but not recommended without recalibration. Non-OEM cables may shift the gap voltage curve and trigger false alarms or missed trips.
Q: What happens if I use a different cable length?
A: The total cable length (probe + extension) must equal the system’s calibrated length. Using a mismatched length will result in measurement error.
Q: Is the 330101-00-14-10-10-02-05 interchangeable with 330101-00-14-10-02-02-05?
A: The two models differ in jacket/armor configuration. Electrically equivalent, but physical installation constraints may differ. Verify before substituting.
Q: Do you provide calibration certificates?
A: Yes. OEM calibration documentation is available for new units. Inspection reports provided for surplus stock. Contact us for details.
Q: Can Konmask help identify the correct replacement for my system?
A: Absolutely. Send us your existing part number, Proximitor® model, and probe model, and our technical team will confirm compatibility or recommend the correct alternative.
