Bently Nevada 330104-00-07-10-01-CN Proximity Probe – 3300 XL 8mm Series
When a critical rotating machine loses its vibration monitoring capability, the consequences are immediate and severe: undetected shaft displacement, catastrophic bearing failure, unplanned downtime, and in worst cases, complete turbomachinery destruction. The Bently Nevada 330104-00-07-10-01-CN proximity probe is the front-line sensor that prevents this scenario — continuously measuring radial shaft vibration, axial position, and differential expansion with micron-level precision, 24 hours a day, 365 days a year.
Within the 3300 XL 8mm proximity probe series — Bently Nevada’s most widely deployed eddy-current sensing platform — the 330104-00-07-10-01-CN occupies a well-defined technical niche: a 7-metre (22.9 ft) armored extension cable configuration with CN-standard connector termination, designed for installations where the monitor rack is located at a distance from the machine casing. This part number is specified on tens of thousands of turbines, compressors, pumps, and gearboxes across global petrochemical, power generation, and heavy-industry facilities, making it one of the most sourced replacement probes in the industrial automation aftermarket.
Technical Specifications
- Part Number: 330104-00-07-10-01-CN
- Series: 3300 XL 8mm Proximity Probe System
- Probe Tip Diameter: 8 mm
- Sensing Technology: Eddy-current (non-contact)
- Extension Cable Length: 7.0 m (22.9 ft)
- Connector Type: CN (standard Bently Nevada coaxial)
- Armor: Stainless steel armored cable
- Temperature Range (Probe): -35°C to +177°C (-31°F to +351°F)
- Compatible Driver/Monitor: 3300 XL series (e.g., 3300/16, 3300/20, 3300/25, 3300/55)
- Measurement Range: 0.25 mm to 2.26 mm (10 mil to 90 mil) linear range
- Scale Factor: 7.87 V/mm (200 mV/mil) nominal
- Target Material: AISI 4140 steel (or equivalent ferromagnetic alloy)
- Weight: Approx. 480 g (assembled with cable)
- Compliance: API 670 5th Edition compatible
Key Features & Benefits
- API 670 Compliance: Meets the machinery protection standard required by most EPC contractors and end-users in oil & gas and power generation.
- 7-Metre Armored Cable: Provides installation flexibility for remote monitor-rack configurations without signal degradation.
- CN Connector Termination: Direct plug-in replacement for existing 3300 XL installations — zero rewiring required.
- High-Temperature Tolerance: Rated to +177°C, suitable for hot-section installations near steam turbines and gas compressors.
- Non-Contact Measurement: Eddy-current technology eliminates mechanical wear, ensuring sensor longevity exceeding 10 years in continuous service.
- Stainless Steel Armor: Protects the extension cable from mechanical damage, oil, and chemical exposure in harsh plant environments.
- Drop-In Replacement: Fully interchangeable with other 330104 series probes when paired with the correct extension cable and driver.
Industry & Equipment Applications
- Oil & Gas: Centrifugal compressors, gas turbines, pipeline booster stations, LNG trains
- Power Generation: Steam turbines, gas turbines, hydro generators, combined-cycle plants
- Petrochemical & Refining: Reactor charge pumps, cracked gas compressors, ethylene plant machinery
- Pulp & Paper / Steel: High-speed gearboxes, induced draft fans, rolling mill drives
- Marine & Offshore: Propulsion turbines, FPSO rotating equipment
- General Industry: Any API 670-specified rotating machinery requiring continuous vibration monitoring
System Integration & Compatible Parts
The 330104-00-07-10-01-CN is a component of the complete Bently Nevada 3300 XL proximity probe system. For a fully functional measurement chain, the following companion parts are required:
- Driver (Proximitor): 3300 XL 8mm Proximitor — e.g., 330180-X1-05 or 330180-X1-00
- Monitor Cards: 3300/16, 3300/20, 3300/25, 3300/55 (radial vibration or axial position)
- Interconnect Cable: Matched to driver input — verify connector type before ordering
- Mounting Hardware: Probe holder, lock nut, and bracket per OEM machine drawing
Konmask.com stocks a broad range of 3300 XL series components. Contact us to source a complete replacement kit.
Our Quality Assurance Process
- Source Verification: All units are sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Visual & Dimensional Inspection: Probe tip, cable armor, and connector are inspected for physical integrity before dispatch.
- Label & Date Code Verification: Part number, revision, and manufacture date code are cross-checked against Bently Nevada records.
- Packaging: Anti-static, moisture-barrier packaging with individual part labeling for safe international transit.
- Documentation: Certificate of conformance and packing list provided with every shipment.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond with availability, lead time, and a formal quotation within 24 hours (business days).
- Upon PO confirmation, we arrange export documentation, packaging, and shipment via your preferred freight method.
Why Choose Konmask.com?
- ✅ Specialist Focus: We exclusively handle industrial automation and control system components — no generalist catalog noise.
- ✅ Global Export Experience: Serving buyers in Europe, Southeast Asia, the Middle East, and the Americas with compliant export documentation.
- ✅ Fast Response: RFQ responses within 24 hours; urgent requirements accommodated.
- ✅ Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing on hard-to-find parts.
- ✅ Technical Support: Our team includes engineers with hands-on experience in Bently Nevada systems — we can advise on compatibility and installation.
Frequently Asked Questions
Q: Is the 330104-00-07-10-01-CN a new or refurbished part?
A: We supply both new (OEM) and certified-surplus units depending on availability. The condition is clearly stated in our quotation. All surplus units pass our QA inspection process.
Q: Can I use this probe with a 3300/16 monitor?
A: Yes. The 330104-00-07-10-01-CN is compatible with all standard 3300 XL series monitors when paired with the correct 3300 XL 8mm Proximitor driver. Verify your driver part number before ordering.
Q: What does the “-CN” suffix mean in the part number?
A: The “-CN” suffix designates the connector type — a standard Bently Nevada coaxial connector used on the majority of 3300 XL installations. It is not a country-of-origin designation.
Q: What is the lead time for this part?
A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. For out-of-stock items, lead time is quoted individually — typically 2–6 weeks depending on sourcing channel.
Q: Do you provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of conformance, and can assist with any additional documentation required by your country’s import authority.
Q: What is the difference between 330104-00-07-10-01-CN and 330104-00-07-10-02-CN?
A: The last digit typically designates a minor configuration variant (e.g., connector orientation or cable jacket material). Please confirm your exact OEM part number from the machine documentation before placing an order.
