Vibration Monitoring Solution – Bently Nevada 330101-00-40-10-01-05 | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330101-00-40-10-01-05 Proximity Transducer System is engineered for continuous, non-contact vibration and position measurement in critical rotating machinery environments. Typical deployment sites include:
- Steam & Gas Turbines – Shaft radial vibration and axial position monitoring in power generation plants
- Centrifugal Compressors – Real-time rotor orbit tracking in petrochemical and refinery applications
- Pumps & Blowers – Bearing journal displacement monitoring in water treatment and HVAC systems
- Gearboxes & Expanders – Differential expansion and eccentricity measurement in LNG and chemical plants
- Marine Propulsion Systems – Shaft monitoring in shipboard turbine and diesel-electric drive trains
Wherever API 670 compliance is mandated and machine protection is non-negotiable, this transducer system is the industry benchmark.
Technical Specifications
- Part Number: 330101-00-40-10-01-05
- Series: 3300 XL 8 mm Proximity Transducer System
- Probe Tip Diameter: 8 mm
- Cable Length: 1.0 m (integral cable)
- Extension Cable Length: 5.0 m
- Total System Length: 6.0 m (probe + extension)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 0.25 – 2.25 mm (10 – 90 mil)
- Frequency Response: DC – 10,000 Hz (–3 dB)
- Supply Voltage: –24 VDC (nominal)
- Temperature Range: –35°C to +121°C (probe); –35°C to +66°C (driver)
- Target Material: AISI 4140 steel (standard)
- Connector: MIL-C-5015 style
- Approvals: FM, CSA, ATEX, IECEx
Why Engineers Specify This Model
- API 670 Compliant – Meets the machinery protection standard required by EPC contractors and end-users globally
- Plug-and-Play with 3300 System Monitors – Direct compatibility with Bently Nevada 3300/16, 3300/20, and 3500 series rack monitors eliminates integration risk
- High-Temperature Probe – Rated to 121°C continuous, suitable for hot bearing housings and steam environments
- Proven MTBF – Bently Nevada’s eddy-current technology delivers >100,000-hour field-proven reliability in harsh industrial environments
- Hazardous Area Rated – ATEX / IECEx / FM / CSA certified for Zone 1 & Zone 2 explosive atmospheres
- Standardized Wiring – Industry-standard –24 VDC supply and 200 mV/mil output simplify DCS/PLC integration
Complete System Bill of Materials
The 330101-00-40-10-01-05 is a complete proximity transducer system. Typical companion components include:
- Bently Nevada 330180-X0-05 – Proximitor® Driver / Signal Conditioner
- Bently Nevada 3300/16 or 3500/42 – Vibration Monitor Module
- Bently Nevada 135489-01 – Barrier (for IS installations)
- Bently Nevada 02120028 – Mounting Bracket Kit
- Bently Nevada 330130-040-00-00 – Armored Extension Cable (alternative)
Contact support@konmask.com for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems
- IEC 61511 – Functional Safety (SIL-capable installations)
- ATEX Directive 2014/34/EU – Zone 1 / Zone 2
- IECEx Scheme – International hazardous area certification
- FM Approved – North American hazardous locations
- CSA Certified – Canadian Standards Association
- RoHS Compliant
Quality Assurance & Sourcing
Every Bently Nevada 330101-00-40-10-01-05 unit sourced through Konmask.com undergoes the following verification process:
- Visual and dimensional inspection against OEM datasheet tolerances
- Functional sensitivity check (200 mV/mil ± 1%) prior to dispatch
- Traceability documentation provided upon request (lot code, date code)
- Packaging inspected for moisture ingress and physical damage
- 30-day return policy for DOA units with full inspection report
We supply to EPCs, OEMs, MRO warehouses, and plant maintenance teams across Asia-Pacific, the Middle East, and Europe.
How to Source This Part
Ready to order or need a formal quotation?
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 2 business days; ex-stock orders confirmed within 24 hours
- Payment: T/T, PayPal, credit card accepted
- Shipping: DHL / FedEx Express worldwide; sea freight available for bulk orders
Provide your PO number or project name for priority processing.
Application-Specific FAQ
Q: Is the 330101-00-40-10-01-05 compatible with the Bently Nevada 3500 rack?
A: Yes. The 3300 XL 8 mm system is fully compatible with 3500/42 and 3500/45 vibration monitor modules when used with the appropriate Proximitor driver.
Q: What is the maximum shaft speed this transducer can monitor?
A: The DC–10,000 Hz frequency response supports shaft speeds up to approximately 600,000 RPM for 1× vibration, making it suitable for high-speed turbomachinery.
Q: Can this probe be used in a steam turbine bearing housing at 110°C?
A: Yes. The probe is rated to 121°C continuous, making it suitable for most steam turbine bearing housing environments.
Q: Do you supply the complete system (probe + extension + driver)?
A: Yes. We can supply the complete matched system. Contact us with your gap voltage and target material requirements for a matched-set quotation.
Q: Is a calibration certificate available?
A: Calibration certificates and traceability documentation are available upon request for MRO and EPC procurement requirements.
