Bently Nevada 330104-02-08-10-01-00 Proximity Probe – 3300 XL 8mm Proximity Transducer System
When a critical rotating machine loses its vibration monitoring capability, the consequences are immediate and severe: undetected shaft imbalance, bearing wear, or rotor rub can escalate within minutes into catastrophic equipment failure, unplanned downtime, and six-figure repair costs. In continuous-process industries — petrochemical, power generation, oil & gas — a single unmonitored turbine or compressor can halt an entire production line. The Bently Nevada 330104-02-08-10-01-00 Proximity Probe is the precision sensing element that stands between normal operation and disaster, delivering real-time, non-contact shaft displacement data to your condition monitoring system.
The 330104-02-08-10-01-00 is a core component of the industry-standard Bently Nevada 3300 XL 8mm Proximity Transducer System — one of the most widely deployed eddy-current transducer platforms in global industrial automation. With a defined cable length, armored construction, and fully characterized output, this probe integrates directly with 3300 XL extension cables and Proximitor® sensors to deliver the API 670-compliant vibration and position measurements demanded by rotating machinery protection systems worldwide.
Technical Specifications
- Part Number: 330104-02-08-10-01-00
- Brand: Bently Nevada (Baker Hughes)
- Series: 3300 XL 8mm Proximity Transducer System
- Sensing Technology: Eddy-current (non-contact)
- Probe Tip Diameter: 8 mm
- Cable Length: 2.0 m (integral cable, armored)
- Extension Cable Compatibility: 3300 XL Series (330130 / 330180)
- Proximitor® Sensor Compatibility: 3300 XL 8mm Proximitor® (330180)
- Output Scale Factor: 7.87 V/mm (200 mV/mil) nominal
- Linear Range: 0.25 mm – 2.26 mm (10 – 89 mil)
- Temperature Range: –35°C to +177°C (probe body)
- Target Material: AISI 4140 steel (standard); other materials require recalibration
- Approvals: API 670 compatible; CE marked
- Weight: 180 g (approx.)
Key Features & Benefits
- Non-Contact Measurement: Zero mechanical wear on the probe or shaft — ideal for continuous 24/7 monitoring in high-speed rotating machinery.
- High-Temperature Tolerance: Armored cable and probe body rated to 177°C, suitable for hot bearing housings and turbine pedestals.
- API 670 Compliance: Meets the international standard for machinery protection systems, ensuring compatibility with plant safety and insurance requirements.
- Plug-and-Play System Integration: Factory-characterized as part of the 3300 XL system — no field calibration required when used with matched extension cable and Proximitor® sensor.
- Robust Armored Construction: Stainless steel armor protects the integral cable from mechanical damage, oil, and chemical exposure in harsh plant environments.
- Direct OEM Replacement: Exact form, fit, and function replacement for installed 330104-02-08-10-01-00 probes — minimizes maintenance downtime.
Industry & Equipment Applications
- Oil & Gas: Centrifugal compressors, gas turbines, pipeline pumps
- Power Generation: Steam turbines, hydro generators, gas turbine-generators
- Petrochemical & Refining: Reactor feed pumps, cracked gas compressors, expanders
- Pulp & Paper / Steel: Large induced draft fans, rolling mill drives
- Marine & Offshore: Propulsion turbines, LNG compressor trains
- General Industrial: Any API 670-monitored rotating machine requiring radial vibration, axial position, or differential expansion measurement
System Integration & Compatible Parts
The 330104-02-08-10-01-00 probe is designed to operate as part of a complete 3300 XL transducer system. Typical compatible components include:
- Extension Cable: Bently Nevada 330130-080-00-00 / 330130-045-00-00 (3300 XL 8mm, various lengths)
- Proximitor® Sensor: Bently Nevada 330180-X1-05 (3300 XL 8mm Proximitor®)
- Monitoring System: Bently Nevada 3500 Series Machinery Protection System (3500/40M, 3500/42M, 3500/45, 3500/46)
- Portable Analyzer: Compatible with ADRE® 408 DSPi and SCOUT Series portable data collectors
Note: Always verify system compatibility using the Bently Nevada 3300 XL System Installation Manual before installation.
Our Quality Assurance Process
- Every unit sourced from authorized distributors or verified OEM-surplus channels
- Visual and dimensional inspection upon receipt
- Functional verification of probe tip and cable continuity prior to dispatch
- Secure anti-static packaging with individual part labeling
- Full traceability documentation available on request
How to Order
- Submit an inquiry via the Contact Us form or email [email protected]
- Provide your required quantity, delivery timeline, and destination country
- Receive a formal quotation within 1 business day
- Confirm order and arrange payment via T/T, L/C, or agreed terms
- Shipment with full documentation (packing list, commercial invoice, COO)
Why Choose Konmask.com?
- Industrial Automation Specialists: Focused exclusively on PLC, DCS, and condition monitoring components from leading global brands
- Competitive Pricing: Direct sourcing relationships enable below-list pricing on genuine parts
- Fast Global Shipping: DHL / FedEx express delivery to 150+ countries; EXW Xiamen available
- Technical Support: Pre-sales engineering consultation to confirm compatibility before you order
- Responsive Service: Dedicated account managers, 24-hour quotation turnaround
Frequently Asked Questions
- Q: Is the 330104-02-08-10-01-00 an OEM Bently Nevada part?
- A: We supply genuine Bently Nevada (Baker Hughes) parts sourced through authorized channels. Please contact us for certification documentation.
- Q: Can this probe be used without the 3300 XL extension cable?
- A: No. The 330104 probe must be used with a matched 3300 XL extension cable and Proximitor® sensor to maintain system calibration and output accuracy.
- Q: What is the integral cable length for part number 330104-02-08-10-01-00?
- A: The “-02-” in the part number designates a 2.0-meter integral cable length.
- Q: Is this probe compatible with the Bently Nevada 3500 monitoring rack?
- A: Yes, when used with the appropriate 3300 XL Proximitor® sensor, the output is fully compatible with 3500 Series monitor input cards.
- Q: Do you offer expedited shipping for urgent plant shutdowns?
- A: Yes. Contact us directly at +0086 19859288691 and we will prioritize your order for same-day or next-day dispatch where stock permits.
