Bently Nevada 330130-080-01-00 – 3300 XL Extension Cable | 3300 XL Proximity Transducer System
Engineering Background
The Bently Nevada 3300 XL Proximity Transducer System is the industry benchmark for non-contact vibration and position measurement in rotating machinery. Deployed across gas turbines, steam turbines, compressors, and pumps worldwide, the 3300 XL platform demands precision-matched cabling to maintain signal integrity across the full measurement chain.
Product Positioning
The 330130-080-01-00 is an 8.0-meter extension cable engineered specifically for the 3300 XL series. It bridges the proximity probe (330100/330101 series) to the Proximitor® sensor, ensuring low-loss signal transmission in harsh industrial environments. This part is the OEM-specified drop-in replacement for maintenance, retrofit, and new installation projects.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330130-080-01-00 |
| Series | Bently Nevada 3300 XL |
| Cable Length | 8.0 m (26.2 ft) |
| Cable Type | Extension Cable (Probe-to-Proximitor) |
| Connector (Probe End) | 3-pin MIL-spec coaxial, male |
| Connector (Proximitor End) | 3-pin MIL-spec coaxial, female |
| Impedance | 50 Ω nominal |
| Operating Temperature | -40°C to +85°C |
| Jacket Material | Armored stainless steel braid / PTFE inner |
| Compatibility | 3300 XL 8mm, 11mm, 14mm, 25mm probe systems |
| Approvals | CE, CSA, FM (per system certification) |
| Weight | ~500 g |
| Country of Origin | USA |
Proven Application Environments
- Gas & Steam Turbines – Radial vibration and axial position monitoring on high-speed shafts
- Centrifugal Compressors – Continuous shaft orbit and gap voltage measurement
- Pumps & Motors – Bearing health monitoring in API 670-compliant installations
- Gearboxes – Differential expansion and eccentricity measurement
- Power Generation – OEM-specified cabling for GE, Siemens, MHI, and Mitsubishi turbine trains
Engineering Advantages
- Signal Integrity – Precision 50 Ω impedance matching eliminates reflection errors across the 8.0 m run
- EMI Shielding – Double-shielded construction rejects electrical noise in VFD-dense environments
- Mechanical Durability – Stainless steel armor withstands vibration, abrasion, and chemical exposure
- OEM Compatibility – Direct replacement; no recalibration of Proximitor® sensor required
- Temperature Stability – PTFE dielectric maintains consistent electrical characteristics from -40°C to +85°C
- API 670 Compliant – Meets machinery protection standard for critical rotating equipment
System Architecture & Signal Flow
The 3300 XL measurement chain follows a three-component topology:
- Proximity Probe (330100/330101 series) → generates eddy-current field at shaft surface
- Extension Cable 330130-080-01-00 → transmits raw probe signal with minimal attenuation
- Proximitor® Sensor (330180 series) → conditions signal to –24 VDC output for monitor input
The 8.0 m cable length is factory-calibrated as part of the system. Substituting non-OEM cables alters the total system inductance and capacitance, causing scale factor errors and false alarms. Always specify the correct length code (-080-) when ordering.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified surplus channels with full traceability
- Each cable inspected for connector integrity, jacket continuity, and impedance conformance before shipment
- Serialized packaging with part number, revision, and date code visible for incoming QC
- Certificate of Conformance (CoC) available upon request for regulated installations
Procurement Process
- Confirm part number 330130-080-01-00 matches your probe length and system configuration
- Submit inquiry via support@konmask.com or add to cart directly
- Lead time: In-stock units ship within 1–3 business days; ETA confirmed at order
- Export documentation (commercial invoice, packing list, CoC) provided for international shipments
- Payment: T/T, PayPal, credit card accepted; net terms available for qualified accounts
Technical FAQ
Q: Can I use a different cable length with my existing Proximitor® sensor?
A: No. The Proximitor® sensor is factory-calibrated for a specific probe + cable length combination. Changing the cable length requires recalibration or a new matched system.
Q: What is the difference between 330130-080-01-00 and 330130-080-00-00?
A: The last two digits denote the armor/jacket option. -01-00 includes stainless steel armor; -00-00 is unarmored. Specify -01-00 for installations with mechanical exposure risk.
Q: Is this cable compatible with 3300 NSv or 3500 series monitors?
A: The 330130 series is designed for 3300 XL Proximitor® sensors. Compatibility with 3300 NSv requires verification of the Proximitor® model. It is not interchangeable with 3500 series transducer cables.
Q: Do you provide ATEX/IECEx certified versions?
A: Hazardous-area certified variants are available. Contact us with your area classification (Zone/Division) and we will confirm the correct suffix.
Q: What is the minimum order quantity?
A: Single-unit orders accepted. Volume pricing available for 5+ units.
