Turbine & Rotating Machinery Vibration Monitoring Solution – Bently Nevada 330171-00-20-90-02-00 | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330171-00-20-90-02-00 is a high-precision eddy-current proximity transducer engineered for continuous vibration and position monitoring of rotating machinery in mission-critical industrial environments. Typical deployment sites include:
- Steam & Gas Turbines – shaft radial vibration and axial position measurement in power generation plants
- Centrifugal Compressors – real-time rotor orbit monitoring in petrochemical and LNG facilities
- Pumps & Blowers – bearing journal displacement tracking in water treatment and HVAC systems
- Gearboxes & Expanders – differential expansion and eccentricity monitoring in refinery trains
- Marine Propulsion Systems – shaft vibration surveillance on vessel drive trains
Technical Specifications
- Part Number: 330171-00-20-90-02-00
- Series: Bently Nevada 3300 XL
- Sensor Type: Eddy-Current Proximity Transducer
- Cable Length: 5 m (standard extension cable)
- Probe Tip Diameter: 8 mm
- Measurement Range: 0.25 mm – 2.25 mm (linear range)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Supply Voltage: –24 VDC (nominal)
- Operating Temperature: –35 °C to +177 °C (probe); –35 °C to +85 °C (driver)
- Target Material: AISI 4140 steel or equivalent
- Connector: 2-pin MIL-C-5015 style
- Weight: 180 g (approx.)
- Approvals: CE, ATEX, FM (see compliance section)
Why Engineers Specify This Model
- Drop-in 3300 XL Compatibility – fully interchangeable with existing Bently Nevada 3300 XL monitor racks without recalibration
- High-Temperature Probe Body – rated to 177 °C, suitable for hot-section turbine bearing pedestals
- Tight Scale-Factor Tolerance – ±1% linearity ensures accurate orbit plots and alarm setpoints
- Armored Extension Cable – stainless-steel conduit protects signal integrity in high-vibration, high-EMI environments
- Long Field Service Life – non-contact measurement eliminates wear, reducing maintenance intervals
Complete System Bill of Materials
For a fully functional 3300 XL radial vibration channel, the following components are typically required:
- Probe: 330171-00-20-90-02-00 (this item)
- Extension Cable: Bently Nevada 330130-045-00-00 (5 m, included in this assembly)
- Proximitor Driver: Bently Nevada 330180-X1-05 (sold separately)
- Monitor Module: Bently Nevada 3300/16 or 3500/40M (sold separately)
- I/O Terminal Block: Bently Nevada 3300/05 (sold separately)
Contact us for bundle pricing on complete channel assemblies.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61511 – Functional Safety for Process Industry
- ATEX Directive 2014/34/EU – Zone 1 & Zone 2 rated
- FM Approved – Class I, Division 1 & 2
- CE Marking – EMC Directive 2014/30/EU
- ISO 10816 / ISO 20816 – Mechanical Vibration Evaluation
Quality Assurance & Sourcing
All Bently Nevada components supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes incoming inspection including:
- Visual and dimensional verification against OEM datasheet
- Scale-factor bench test (output voltage vs. gap)
- Insulation resistance check on cable assembly
- Original manufacturer labeling and date-code confirmation
Traceability documentation available upon request for regulated industries.
How to Source This Part
- In Stock: Add to cart for immediate dispatch
- Lead Time Orders: Contact us for volume pricing and scheduled delivery
- Expedited Shipping: DHL Express / FedEx International Priority available
- Export Compliance: EAR99 – no export license required for most destinations
- Payment: T/T, PayPal, credit card accepted
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the 330171-00-20-90-02-00 compatible with the Bently Nevada 3500 system?
A: Yes, when paired with the appropriate 3500-series Proximitor and monitor card. Verify the driver input impedance matches your 3500/40M channel configuration.
Q: What is the maximum shaft speed this transducer can monitor?
A: The eddy-current technology is frequency-independent up to the bandwidth of the paired Proximitor driver (typically DC to 10 kHz), making it suitable for machinery operating from 0 to 60,000 RPM.
Q: Can this probe be used on non-ferrous shafts?
A: Performance is optimized for AISI 4140 steel targets. For non-ferrous or exotic alloy shafts, a calibration correction factor must be applied. Contact our engineering team for target material assessment.
Q: What is the difference between the -90-02-00 and -90-00-00 suffix?
A: The suffix encodes connector type and cable jacket material. The -02-00 variant features a stainless-steel armored jacket suitable for harsh environments. Confirm your installation requirements before substituting suffixes.
Q: Do you provide calibration certificates?
A: Factory calibration data is available. Third-party NIST-traceable calibration certificates can be arranged upon request at additional cost.
