Turbine Vibration Monitoring Solution – Bently Nevada 330903-00-06-10-02-05/CN | 3300 NSv Series
Where This Product Is Used
The Bently Nevada 330903-00-06-10-02-05/CN is an 8 mm eddy-current proximity probe engineered for continuous, non-contact vibration and shaft position measurement in critical rotating machinery. Proven deployment environments include:
- Steam & Gas Turbines – radial shaft vibration monitoring on power generation units rated from 10 MW to 1 GW
- Centrifugal Compressors – real-time rotor displacement in petrochemical, LNG, and refinery trains
- Pumps & Fans – bearing journal orbit analysis in water treatment, HVAC, and process industries
- Gearboxes – axial thrust position monitoring to detect misalignment and progressive wear
- Marine Propulsion Systems – shaft monitoring in shipboard machinery and offshore platforms
- Paper & Steel Mills – roll and spindle vibration measurement in high-humidity environments
This probe is a direct-fit replacement for existing 3300 NSv and 3300 XL 8 mm installations and is fully compatible with Bently Nevada 3300 series monitors and Proximitor® drivers.
Technical Specifications
| Part Number | 330903-00-06-10-02-05/CN |
| Series | 3300 NSv Proximity Probe System |
| Probe Length | 6 in (152.4 mm) |
| Cable Length | 10 ft (3.05 m) |
| Connector Type | 02 – Standard |
| Tip Diameter | 8 mm |
| Sensing Range | 0.25 – 2.25 mm (10 – 90 mil) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linearity Error | ±0.5% of full scale |
| Operating Temperature | −35 °C to +177 °C (−31 °F to +351 °F) |
| Supply Voltage | −24 VDC (nominal) |
| Output Voltage | −1 to −21 VDC |
| Target Material | AISI 4140 steel (or equivalent) |
| Ingress Protection | IP67 |
| Weight | ~40 g |
| Country of Origin | China (CN variant) |
Why Engineers Specify This Model
- NSv Eddy-Current Technology – Non-contacting, non-intrusive sensing eliminates mechanical wear and maximises MTBF in high-speed rotating equipment.
- High Linearity ±0.5% – Ensures accurate shaft position data for API 670-compliant machinery protection systems.
- Robust Stainless-Steel Housing – Hermetically sealed tip withstands aggressive process fluids, steam, and high-pressure environments up to IP67.
- Drop-in Compatibility – Fully interchangeable with 3300 XL 8 mm probe systems; no monitor recalibration required.
- Wide Temperature Range – Qualified from cryogenic to high-temperature applications in a single SKU, reducing spare-parts complexity.
- Factory-Calibrated Pair – Probe and Proximitor® driver are matched at the factory, ensuring loop accuracy from day one.
Complete System Bill of Materials
A complete 3300 NSv proximity probe measurement loop requires:
- Proximity Probe: 330903-00-06-10-02-05/CN (this item)
- Extension Cable: Bently Nevada 330130 series (matched length)
- Proximitor® Driver: Bently Nevada 330180 or 330185 series
- Monitor Module: Bently Nevada 3500/40M or 3500/42M
- Mounting Hardware: Bently Nevada 02-262xxx probe holder (application-specific)
Contact support@konmask.com for complete loop pricing and compatibility verification.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation of machines
- IEC 61511 – Functional Safety (SIL-capable loop configurations)
- ATEX / IECEx – Consult factory for zone-rated variants
- CE Marking – Compliant with applicable EU directives
Quality Assurance & Sourcing
All Bently Nevada components supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes:
- Visual and dimensional inspection upon receipt
- Functional verification against OEM datasheet parameters
- Secure anti-static packaging with tamper-evident sealing
- Full traceability documentation available on request
We supply only authentic, new-in-box stock. Certificates of conformance and test reports are available for OEM-sourced inventory.
How to Source This Part
- Click Add to Cart or contact us directly for volume and project pricing.
- Provide your application details (machine type, shaft material, nominal gap voltage) for compatibility confirmation.
- Request a formal quotation at support@konmask.com or call +0086 19859288691.
- Lead time: In-stock units ship within 1–3 business days; special configurations within 7–14 business days.
Application-Specific FAQ
Q: What does the /CN suffix mean?
A: The /CN suffix designates China as the country of manufacture. The probe is functionally identical to the standard 330903-00-06-10-02-05 in all performance specifications.
Q: Can this probe connect directly to a 3500 series monitor?
A: No. A Proximitor® driver (e.g., 330180 or 330185) is required between the probe and the 3500 monitor input card.
Q: What is the maximum shaft speed this probe can monitor?
A: The 3300 NSv system is rated for shaft speeds up to 100,000 RPM, making it suitable for high-speed turbomachinery including gas turbines and turboexpanders.
Q: Is calibration required after installation?
A: Gap setting (typically 1.0–1.5 mm / 40–60 mil) must be verified during installation. The probe-driver pair is factory-calibrated and does not require electronic recalibration when replacing a matched system.
Q: Do you ship internationally?
A: Yes. We ship globally via DHL, FedEx, and UPS Express. Contact us for a freight quote to your destination.
Q: Can I order a complete loop kit (probe + cable + driver)?
A: Yes. Contact support@konmask.com with your application details and we will quote a matched, tested loop assembly.
