Rotating Machinery Vibration Monitoring Solution — Bently Nevada 330903-00-23-10-01-00 | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330903-00-23-10-01-00 Proximity Transducer System is purpose-built for continuous, real-time shaft vibration and position monitoring in rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines — radial vibration and axial position measurement on high-speed shafts in power generation plants
- Centrifugal Compressors — shaft orbit and eccentricity monitoring in petrochemical and LNG facilities
- Pumps & Fans — bearing journal monitoring in water treatment, HVAC, and process industries
- Gearboxes — differential expansion and thrust position measurement in heavy industrial drives
- Marine Propulsion Systems — shaft displacement monitoring in shipboard turbine and diesel-electric drives
This transducer system integrates directly with Bently Nevada 3500 Series rack-based machinery protection systems and System 1 condition monitoring software, making it the standard choice for API 670-compliant installations worldwide.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 330903-00-23-10-01-00 |
| Series | Bently Nevada 3300 XL |
| Probe Length | 23 mm (tip-to-shoulder) |
| Cable Length | 10 m (extension cable) |
| Output Sensitivity | 200 mV/mil (7.87 V/mm) |
| Linear Range | 25–325 mil (0.635–8.255 mm) |
| Frequency Response | DC to 10,000 Hz (–3 dB) |
| Supply Voltage | –24 VDC (nominal) |
| Temperature Range | –35°C to +177°C (probe); –35°C to +85°C (driver) |
| Target Material | AISI 4140 steel (standard); other alloys with calibration |
| Connector Type | Integral armored cable with MIL-spec connector |
| Approvals | FM, CSA, ATEX, IECEx |
| Weight | Approx. 300 g (complete system) |
Why Engineers Specify This Model
- API 670 Compliance — meets the 5th Edition standard for machinery protection instrumentation, required for critical rotating equipment in oil & gas
- 3300 XL Eddy-Current Technology — superior immunity to electrical runout and target material variation compared to earlier 3300 series probes
- Plug-and-Play with 3500 Rack — pre-calibrated to work directly with Bently Nevada 3500/40M, 3500/42M, and 3500/45 monitor modules without field calibration
- Hazardous Area Rated — FM/CSA Division 1 and ATEX Zone 1 certified for use in explosive atmospheres common in refineries and offshore platforms
- Long-Term Stability — armored cable construction and hermetically sealed probe tip ensure reliable performance in high-vibration, high-temperature environments
- Dual-Use Capability — measures both radial vibration (dynamic) and shaft centerline position (static DC gap) simultaneously from a single installation point
Complete System Bill of Materials
The 330903-00-23-10-01-00 is a complete proximity transducer system. Typical companion components for a full API 670 loop include:
- Bently Nevada 3500/40M or 3500/42M Proximitor Monitor Module
- Bently Nevada 3500/20 Rack Interface Module (RIM)
- Bently Nevada 3500/92 Communication Gateway (for System 1 integration)
- Bently Nevada 330130 or 330180 Proximitor Sensor (driver, if ordered separately)
- Mounting hardware: probe holder, lock nut, and bracket per API 670 Annex D
- Shielded twisted-pair signal cable (Belden 9501 or equivalent)
Compliance & Industry Standards
- API 670 — Machinery Protection Systems, 5th Edition
- IEC 61511 — Functional Safety for SIS applications
- ATEX Directive 2014/34/EU — Zone 1, Group IIC, T4
- IECEx — International certification for explosive atmospheres
- FM & CSA — North American hazardous location approvals, Class I Division 1
- RoHS Compliant — restriction of hazardous substances in manufacturing
Quality Assurance & Sourcing
Konmask.com sources the Bently Nevada 330903-00-23-10-01-00 through verified industrial automation distributors and authorized surplus channels. Every unit undergoes the following before dispatch:
- Visual inspection for probe tip integrity, cable armor condition, and connector seating
- Continuity and insulation resistance check on extension cable
- Verification of part number label and date code against Bently Nevada documentation
- Anti-static packaging with desiccant for long-term storage protection
Certificates of conformance and original manufacturer documentation are available upon request for critical plant installations.
How to Source This Part
Ready to order or need a formal quotation for your procurement team? Contact Konmask.com through any of the following channels:
- Online: Add to cart directly on this page for standard orders
- Email RFQ: support@konmask.com — include quantity, required delivery date, and plant/project name
- Phone/WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders quoted within 24 hours
- Export: We ship globally with DHL, FedEx, and UPS Express; export documentation (CO, packing list, commercial invoice) included
Application-Specific FAQ
Q: Is the 330903-00-23-10-01-00 compatible with older Bently Nevada 3300 series monitors?
A: The 3300 XL probe is backward-compatible with most 3300 series Proximitor monitors. However, for new installations, Bently Nevada recommends pairing with the 3500 series rack for full API 670 compliance and System 1 integration.
Q: Can this transducer be used on non-steel targets such as titanium or Inconel shafts?
A: Yes, but a target-material-specific calibration curve must be applied. Contact Bently Nevada or Konmask.com for application-specific calibration data sheets.
Q: What is the maximum shaft speed this system can monitor?
A: The 3300 XL system supports frequency response up to 10,000 Hz (–3 dB), suitable for shaft speeds up to approximately 600,000 RPM in keyphasor applications, and standard vibration monitoring up to 60,000 RPM.
Q: Does the 330903-00-23-10-01-00 include the Proximitor driver/oscillator?
A: Yes. The 330903 part number designates a complete proximity transducer system including probe, extension cable, and integral Proximitor driver. No separate driver module is required.
Q: Is this part suitable for use in a SIL-rated safety instrumented function?
A: The 3300 XL series has been assessed for use in SIL 1 and SIL 2 loops per IEC 61511 when installed per Bently Nevada’s functional safety manual. Contact us for the relevant SIL data package.
