Rotating Machinery Vibration Monitoring Solution – Bently Nevada 330903-00-24-05-02-00 | 3300 NSv Series
Where This Product Is Used
The Bently Nevada 330903-00-24-05-02-00 is a high-precision eddy-current proximity probe engineered for continuous, non-contact vibration and position measurement on rotating machinery. It is routinely specified in the following industrial environments:
- Steam & Gas Turbines – shaft radial vibration and axial position monitoring per API 670
- Centrifugal & Axial Compressors – real-time rotor orbit analysis in petrochemical and LNG plants
- Pumps & Fans – bearing housing displacement measurement in power generation and water treatment
- Gearboxes – gear mesh frequency and shaft eccentricity detection
- Marine Propulsion Systems – shaft alignment verification and thrust position monitoring
- Paper & Steel Mills – roll position and vibration surveillance on high-speed rotating rolls
Technical Specifications
| Part Number | 330903-00-24-05-02-00 |
| Series | 3300 NSv (Non-Standard voltage) |
| Probe Type | Eddy-Current Proximity Probe |
| Sensing Technology | Non-contact, electromagnetic eddy-current |
| Extension Cable Length | 24 inches (610 mm) |
| Probe Tip Diameter | 5 mm |
| Thread Size | M8 × 1.0 |
| Connector Type | 02-series (standard BN connector) |
| Cable Jacket | Armored, oil-resistant |
| Operating Temperature | −35 °C to +177 °C (probe tip) |
| Linear Range | Approx. 0.25 mm to 2.54 mm (target-dependent) |
| Supply Voltage | −24 VDC (nominal, via Proximitor® driver) |
| Output | −4 VDC to −20 VDC (linear range) |
| Sensitivity | 7.87 V/mm (200 mV/mil) nominal |
| Target Material | AISI 4140 steel (or equivalent ferromagnetic alloy) |
| Weight | Approx. 40 g |
| Manufacturer | Bently Nevada (Baker Hughes) |
Why Engineers Specify This Model
- Proven 3300 NSv Platform – backward-compatible with existing 3300 Proximitor® drivers and 3500 rack systems, minimizing retrofit cost
- 5 mm Tip for Tight Clearances – ideal for small-bore bearing housings where standard 8 mm probes cannot be installed
- 24-Inch Extension – pre-terminated extension eliminates field splicing, reducing installation error and signal noise
- Armored Cable – withstands high-vibration, high-temperature, and chemically aggressive environments without signal degradation
- API 670 Compliant – meets the machinery protection standard required by EPC contractors and end-users in oil & gas
- Direct OEM Replacement – drop-in substitute for legacy 330903 series probes with no recalibration required
Complete System Bill of Materials
For a fully functional proximity measurement loop, the following components are required alongside the 330903-00-24-05-02-00:
- Proximitor® Driver / Oscillator-Demodulator – e.g., Bently Nevada 3300 XL 8mm or 3300 NSv Proximitor (matched to probe series)
- Interconnect Cable – field wiring from Proximitor output to monitoring rack (typically 3-conductor shielded)
- 3500 Monitoring Rack – e.g., Bently Nevada 3500/42M Proximitor® Monitor for API 670 protection
- Mounting Hardware – M8 probe holder, lock nut, and bracket (stainless steel recommended)
- Target Surface Preparation – smooth, concentric shaft surface per BN installation guidelines (Ra ≤ 0.8 µm)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 60068-2 – Environmental Testing (vibration, temperature, humidity)
- CE Marking – EMC Directive 2014/30/EU
- RoHS Compliant – Restriction of Hazardous Substances
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation guidelines
Quality Assurance & Sourcing
Every Bently Nevada 330903-00-24-05-02-00 unit supplied by Konmask.com undergoes the following verification process:
- Visual and dimensional inspection against OEM datasheet tolerances
- Functional continuity and impedance check prior to dispatch
- Traceable documentation: test report, country of origin certificate available on request
- Secure anti-static packaging with humidity indicator card
- Sourced from authorized distributors or verified surplus channels with full traceability
How to Source This Part
To place an order or request a quotation for the Bently Nevada 330903-00-24-05-02-00:
- Online: Add to cart directly on this page for standard lead times
- Email RFQ: support@konmask.com – include quantity, required delivery date, and project name
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Bulk / OEM Orders: Volume pricing available for 5+ units; contact us for a formal quotation
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders typically 7–15 business days
Application-Specific FAQ
Q: Is the 330903-00-24-05-02-00 compatible with the Bently Nevada 3500 rack?
A: Yes. When paired with a compatible 3300 NSv Proximitor® driver, the output signal is fully compatible with 3500 series monitors including the 3500/42M and 3500/40M.
Q: What is the difference between the 330903 and 330730 series?
A: The 330903 uses a 5 mm tip diameter (vs. 8 mm for 330730), making it suitable for smaller shaft diameters and tighter installation envelopes. Sensitivity and output range are equivalent when used with the correct Proximitor.
Q: Can this probe be used on non-ferrous shafts (e.g., titanium or Inconel)?
A: Eddy-current probes are sensitive to target material conductivity and permeability. Non-standard target materials require a system calibration using the actual shaft material. Contact Konmask for application-specific guidance.
Q: What is the maximum continuous operating temperature?
A: The probe tip is rated to +177 °C. The extension cable and connector are rated to +121 °C. For higher ambient temperatures, consult Bently Nevada’s high-temperature probe options.
Q: Do you provide calibration certificates?
A: Factory calibration data is available for new OEM units. For surplus units, functional test reports are provided. Third-party NIST-traceable calibration can be arranged on request.
