Bently Nevada 330904-00-23-05-01-00 3300 XL NSv Proximity Transducer System | Replacement, Equivalent & Selection Guide
The Bently Nevada 330904-00-23-05-01-00 is a high-precision proximity transducer system from the 3300 XL NSv series, engineered for continuous vibration and position monitoring of rotating machinery in critical industrial environments. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: 330904-00-23-05-01-00
- Series: Bently Nevada 3300 XL NSv
- Type: Eddy-Current Proximity Transducer System
- Probe Tip Diameter: 8 mm
- Cable Length: 5 m (standard)
- Extension Cable: Included (matched system)
- Measurement Range: 0–2.36 mm (0–93 mil)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: DC to 10,000 Hz
- Operating Temperature: −35°C to +121°C (probe); −35°C to +66°C (driver)
- Supply Voltage: −24 VDC (nominal)
- Output: −2 to −18 VDC linear range
- Approvals: CE, ATEX, IECEx (intrinsically safe options available)
- Weight: Approx. 220 g
- Manufacturer: Bently Nevada (Baker Hughes)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents for the 330904-00-23-05-01-00. Always verify electrical and mechanical compatibility before substitution:
- Bently Nevada 330903-00-23-05-01-00 — Standard NSv probe, shorter cable variant; same driver compatibility
- Bently Nevada 330905-00-23-05-01-00 — Extended-range NSv probe; verify gap voltage requirements
- Bently Nevada 330780-50-00 — 3300 XL 8 mm standard probe; widely stocked alternative
- Epro PR6423/010-040 — Third-party 8 mm eddy-current probe; compatible with 3300 series drivers in many installations
- Metrix ST5484E — Equivalent proximity transducer for non-OEM replacement programs
Note: Replacement compatibility depends on target material, gap distance, and driver pairing. Contact Konmask for application-specific verification.
Why Choose the Original Model
- Factory-Calibrated System: Probe, extension cable, and driver are matched and calibrated as a system — ensuring accuracy without field adjustment.
- API 670 Compliance: Designed to meet API 670 machinery protection standards required in oil & gas, power generation, and petrochemical plants.
- Long-Term Availability: Bently Nevada maintains backward compatibility across 3300 XL platform generations.
- Proven Reliability: Millions of installed units globally with documented MTBF exceeding 10 years in continuous operation.
- OEM Warranty Support: Original parts qualify for Baker Hughes service contracts and predictive maintenance programs.
Typical Applications
- Steam and gas turbine shaft vibration monitoring
- Centrifugal compressor radial and axial position measurement
- Pump and motor bearing displacement monitoring
- Gearbox and expander rotor dynamics analysis
- Critical rotating machinery in oil & gas, power, and chemical industries
System Compatibility
The 330904-00-23-05-01-00 is designed to operate within the Bently Nevada 3300 XL platform and is compatible with:
- 3300 XL 16-channel monitor racks
- 3500 series monitoring system (with appropriate driver)
- System 1 Condition Monitoring Software (via 3300/3500 hardware)
- Bently Nevada TDXnet and Keyphasor modules
- Third-party DCS/PLC systems via 4–20 mA or voltage output conditioning
Selection Guide
Use the following criteria to confirm the correct model for your application:
- Target Material: Optimized for AISI 4140 steel; correction factors required for other alloys (Inconel, titanium, aluminum)
- Gap Range: Nominal installation gap 1.0–1.5 mm; verify with driver output curve
- Cable Length: This model includes 5 m probe cable + 5 m extension = 10 m total system length
- Environment: Confirm temperature class and hazardous area certification (ATEX Zone 1/2 available)
- Driver Pairing: Must use matched 3300 XL NSv driver (e.g., 330180-91-00) — do not mix with standard 3300 drivers
- Mounting: Standard M10 × 1 thread; confirm bracket and guard clearance
Quality Assurance & Sourcing
Konmask.com sources the 330904-00-23-05-01-00 through verified industrial distribution channels. Every unit is:
- Inspected for physical integrity and original packaging
- Cross-referenced against Bently Nevada part number databases
- Shipped with documentation (datasheet, calibration certificate where available)
- Supported by our 12-month quality guarantee on genuine parts
We do not supply counterfeit or uncertified substitutes. If a genuine unit is unavailable, we will clearly communicate lead time and alternatives.
How to Order
- Online: Add to cart directly from this page
- Email RFQ: support@konmask.com — include quantity, delivery location, and urgency
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock orders ship within 1–3 business days; sourced orders 7–21 days depending on availability
- Export: We support international shipping with commercial invoice, packing list, and HS code documentation
Replacement & Compatibility FAQ
Q: Can I use the 330904-00-23-05-01-00 with a standard 3300 driver (non-NSv)?
A: No. The NSv (Non-Standard voltage) probe requires a matched NSv driver. Using a standard driver will result in incorrect scale factor and potential measurement errors.
Q: Is the 330904-00-23-05-01-00 interchangeable with the 330903 series?
A: The probe tip and thread are identical, but cable lengths differ. Verify total system cable length matches your driver’s specification before substituting.
Q: Can Epro or Metrix probes replace this unit?
A: In some non-API-670-critical applications, third-party probes with matching scale factors can be used. However, for machinery protection systems under API 670, OEM parts are strongly recommended.
Q: What is the lead time for this part?
A: Typically 1–3 business days for in-stock units. Contact us for current availability.
Q: Do you provide calibration certificates?
A: Yes, calibration documentation is provided where available with genuine OEM units.
