Turbine & Compressor Vibration Monitoring Solution – Bently Nevada 330905-00-13-10-02-00 | 3300 NSv Series
Where This Product Is Used
The Bently Nevada 330905-00-13-10-02-00 proximity probe is engineered for continuous, non-contact shaft vibration and position measurement in the most demanding rotating machinery environments. Typical deployment sites include:
- Gas & Steam Turbines – Radial vibration monitoring on HP/LP rotor shafts in power generation plants
- Centrifugal Compressors – Shaft displacement measurement in petrochemical and LNG facilities
- Pumps & Fans – Continuous bearing health monitoring in water treatment and HVAC systems
- Gearboxes – Gear mesh frequency and shaft orbit analysis in heavy industry
- Marine Propulsion Systems – Shaft alignment and axial position monitoring on vessel drive trains
- Paper & Steel Mills – Roll and spindle vibration surveillance in continuous process lines
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 330905-00-13-10-02-00 |
| Series | 3300 NSv (Non-Standard Voltage) |
| Probe Type | Eddy-Current Proximity Probe |
| Cable Length | 1.3 m (integral) |
| Tip Diameter | 10 mm |
| Thread Size | M10 × 1 |
| Connector | 2-pin MIL-C-5015 style |
| Operating Temperature | -35 °C to +177 °C |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 0.25 mm – 2.54 mm (10–100 mil) |
| Supply Voltage | -24 VDC (via Proximitor) |
| Target Material | AISI 4140 steel (standard) |
| IP Rating | IP67 |
| Weight | Approx. 40 g |
Why Engineers Specify This Model
- NSv Compatibility – Designed specifically for the 3300 NSv Proximitor system, ensuring calibrated output without field re-ranging
- Compact 10 mm Tip – Fits tight bearing housings where standard 25 mm probes cannot be installed
- High-Temperature Tolerance – Rated to 177 °C, suitable for hot-section turbine bearing pedestals
- Integral Cable Design – Eliminates field-splice failure points; 1.3 m pre-terminated cable reduces installation time
- API 670 Alignment – Meets the measurement chain requirements referenced in API 670 5th Edition for machinery protection systems
- Proven Reliability – Bently Nevada 3300 series is the de-facto standard in turbomachinery OEM and retrofit projects worldwide
Complete System Bill of Materials
For a fully functional eddy-current measurement chain using this probe, the following components are required:
- Proximity Probe: 330905-00-13-10-02-00 (this item)
- Extension Cable: 330130-080-00-00 (8 m) or 330130-050-00-00 (5 m)
- Proximitor Sensor: 3300 NSv Proximitor (e.g., 330180-X1-05)
- Mounting Hardware: Probe holder, lock nut, and armored conduit fittings
- Monitor Card: 3500/42M or 3500/40M Proximitor Monitor (3500 rack system)
Contact support@konmask.com for bundle pricing on complete measurement chains.
Compliance & Industry Standards
- API 670 – 5th Edition: Machinery Protection Systems (measurement chain reference)
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation of machines
- IEC 60529 – IP67 ingress protection rating
- CE Marking – Compliant with applicable EU directives
- RoHS – Restriction of Hazardous Substances compliant
Quality Assurance & Sourcing
All Bently Nevada components supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes the following before dispatch:
- Visual inspection for physical damage and connector integrity
- Part number and date-code verification against manufacturer documentation
- Packaging integrity check (original or equivalent ESD-safe packaging)
- Certificate of conformance available upon request
We do not supply counterfeit, refurbished-as-new, or grey-market parts. Traceability documentation is available for critical applications.
How to Source This Part
- In Stock Orders: Add to cart and check out online. Same-day dispatch for orders placed before 15:00 CST.
- Bulk / Project Quotes: Email support@konmask.com with your BOM for volume pricing.
- Urgent Shutdown Requirements: Call or WhatsApp +0086 19859288691 for expedited sourcing.
- International Shipping: DHL Express / FedEx International Priority available to 200+ countries. Export documentation (CO, packing list, commercial invoice) included.
Application-Specific FAQ
Q: Is 330905-00-13-10-02-00 compatible with the standard 3300 Proximitor (non-NSv)?
A: No. The NSv probe is calibrated for the NSv Proximitor output range. Using it with a standard 3300 Proximitor will result in incorrect scale factor and alarm setpoints. Always match probe and Proximitor series.
Q: What is the target material correction factor for stainless steel shafts?
A: Bently Nevada publishes target material correction factors in their TN-13 technical note. For 316 SS, a scale factor correction of approximately +8% is typical. Konmask can supply the relevant documentation on request.
Q: Can this probe be used for axial (thrust) position measurement?
A: Yes, provided the mounting geometry and gap are set within the linear range (0.25–2.54 mm). Axial position applications require a dedicated thrust monitor channel in the 3500 rack.
Q: What is the lead time if out of stock?
A: Typical sourcing lead time is 3–7 business days for standard stock replenishment. Contact us for real-time availability.
Q: Do you provide installation and commissioning support?
A: Konmask provides technical documentation and remote commissioning guidance. On-site support can be arranged through our partner network.
