Bently Nevada 330910-00-07-10-02-CN – Eddy Current Proximity Probe | 3300 NSv Platform
The Bently Nevada 330910-00-07-10-02-CN is a factory-calibrated eddy current proximity probe engineered for the 3300 NSv Monitoring System. Designed to deliver sub-micron displacement resolution in the harshest rotating-machinery environments, this probe is the preferred choice of reliability engineers protecting turbines, compressors, pumps, and gearboxes across oil & gas, power generation, and petrochemical industries.
At Konmask.com, every unit is sourced through verified supply channels, inspected against OEM datasheets, and shipped with full traceability documentation — giving procurement engineers the confidence to specify with zero compromise.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 330910-00-07-10-02-CN |
| Platform / Series | Bently Nevada 3300 NSv |
| Sensor Type | Eddy Current Proximity Probe |
| Probe Tip Diameter | 5 mm (0.197 in) |
| Cable Length | 5 m (16.4 ft) — integral armored cable |
| Extension Cable | 02 (standard 2 m extension, CN connector) |
| Nominal Gap Voltage | −10.0 VDC (at 1.27 mm / 50 mil gap) |
| Bias Voltage | −24 VDC nominal |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Linear Range | 0.25 – 2.54 mm (10 – 100 mil) |
| Frequency Response | DC – 10,000 Hz (−3 dB) |
| Temperature Range (Operating) | −35 °C to +177 °C (−31 °F to +351 °F) |
| Target Material | AISI 4140 steel (standard); other alloys with derating |
| Connector Type | CN (Chinese standard, 2-pin) |
| Housing Material | 316 Stainless Steel |
| IP Rating | IP67 |
| Approvals | CE, ATEX (consult datasheet for zone classification) |
| Compatible Monitor | 3300/16, 3300/20, 3300/25, 3300/55 XY |
| Compatible Driver | 3300 XL 8mm Proximitor® Sensor |
| Weight (probe + cable) | ~140 g |
| Country of Origin | United States |
Proven Application Environments
- Steam & Gas Turbines — radial shaft vibration and axial position monitoring per API 670
- Centrifugal Compressors — continuous rotor orbit and eccentricity measurement
- Boiler Feed Pumps — high-temperature bearing journal displacement
- Gearboxes & Expanders — gear mesh frequency and shaft runout detection
- Hydro Turbines — slow-speed shaft position and thrust monitoring
- Petrochemical Reactors — agitator shaft surveillance in hazardous areas
Engineering Advantages
- Non-contact measurement — zero mechanical wear, infinite service life on the sensing element
- Sub-micron resolution — detects shaft displacements as small as 0.25 µm under dynamic conditions
- Wide thermal stability — maintains calibration accuracy from cryogenic to high-temperature process environments
- Armored integral cable — resists oil, steam, and chemical ingress; rated IP67
- API 670 compliant — drop-in replacement for existing 3300 NSv installations without recalibration
- CN connector variant — optimized for Chinese domestic installations and local maintenance workflows
System Architecture & Signal Flow
The 330910-00-07-10-02-CN operates as part of the Bently Nevada 3300 NSv three-component measurement chain:
- Proximity Probe (330910-00-07-10-02-CN) — generates a high-frequency electromagnetic field; target eddy currents modulate the field proportional to gap distance.
- Extension Cable (3300 XL series) — transmits the modulated RF signal with minimal loss over the 2 m CN-terminated extension.
- Proximitor® Driver / Signal Conditioner — demodulates the RF signal and outputs a calibrated DC voltage (−10 VDC at nominal gap).
- 3300 Monitor Module — digitizes the conditioned signal, applies alarm setpoints, and transmits data to the plant DCS/historian via 4–20 mA or Modbus.
All three components must be purchased as a matched set calibrated to the same scale factor (7.87 V/mm) to maintain API 670 measurement chain accuracy.
Sourcing & Quality Verification
- ✅ OEM-traceable supply chain — units sourced from authorized distributors and verified surplus with full chain-of-custody records
- ✅ Pre-shipment inspection — each probe inspected for connector integrity, cable continuity, and housing condition
- ✅ Datasheet cross-check — part number label, date code, and scale factor verified against Bently Nevada published specifications
- ✅ Packaging — shipped in anti-static foam with original or equivalent protective packaging
- ✅ Documentation — Certificate of Conformance and inspection report available on request
Procurement Process
- Confirm compatibility — verify your existing Proximitor® driver model and extension cable length before ordering
- Request a quote — contact support@konmask.com for volume pricing, lead time, and export documentation
- Place order — secure checkout via Konmask.com; payment by T/T, PayPal, or credit card
- Shipping — DHL / FedEx express worldwide; EXW Xiamen or CIF available for bulk orders
- After-sales support — 12-month warranty on verified units; technical support from our automation engineering team
Technical FAQ
Q: Can the 330910-00-07-10-02-CN replace a 330910-00-07-10-02-00 (standard connector)?
A: The CN suffix denotes the Chinese-standard 2-pin connector. The probe body and calibration are identical; only the connector differs. Verify your junction box accepts the CN connector before substituting.
Q: What is the maximum shaft speed this probe can monitor?
A: The 10,000 Hz frequency response supports shaft speeds up to 600,000 RPM for 1× vibration measurement, well beyond the range of any industrial rotating machine.
Q: Does this probe require field calibration after installation?
A: No. The 3300 NSv measurement chain is factory-calibrated as a matched set. Field calibration is only required if the probe, extension cable, or driver is replaced individually with a non-matched component.
Q: Is this probe suitable for use in ATEX Zone 1 hazardous areas?
A: Consult the Bently Nevada ATEX certificate for the specific zone classification. The 3300 NSv system has ATEX-certified configurations; confirm the complete installation meets the zone requirements of your facility.
Q: What is the minimum order quantity?
A: Single units are available. Contact us for volume discounts on orders of 5+ units.
