Turbine Vibration Monitoring Solution – Bently Nevada 330930-045-04-05 | 3300 XL NSv Series
Where This Product Is Used
The Bently Nevada 330930-045-04-05 is a 3300 XL NSv Extension Cable (4.5 m / 15 ft) engineered for continuous-duty vibration and position monitoring in rotating machinery environments. It is routinely specified in the following industrial applications:
- Gas & Steam Turbines – Connects proximity probes to 3300 XL monitors for shaft radial vibration and eccentricity measurement on power-generation turbines.
- Centrifugal Compressors – Provides the signal path between probe tip and monitor rack in high-pressure compressor trains on oil & gas platforms and refineries.
- Pumps & Fans – Used in balance-of-plant rotating equipment where API 670 compliance is required.
- Marine Propulsion Systems – Deployed in shipboard machinery rooms where cable routing demands a mid-length extension.
- Petrochemical & LNG Plants – Installed in hazardous-area installations requiring intrinsically safe signal cables.
The 4.5 m length fills the gap between the standard probe armored cable and the monitor rack, making it the most commonly ordered extension length in the 3300 XL NSv system.
Technical Specifications
| Part Number | 330930-045-04-05 |
| Brand | Bently Nevada (Baker Hughes) |
| Series | 3300 XL NSv Proximity System |
| Cable Type | NSv Extension Cable |
| Cable Length | 4.5 m (15 ft) |
| Connector (Probe End) | Coaxial, compatible with 3300 XL NSv probes |
| Connector (Monitor End) | Coaxial, compatible with 3300 XL monitor inputs |
| Operating Temperature | –40 °C to +85 °C |
| Signal Type | Eddy-current proximity (low-noise coaxial) |
| Compliance | API 670, CE, RoHS |
| Weight (approx.) | 120 g |
Why Engineers Specify This Model
- System-Matched Performance – Designed exclusively for the 3300 XL NSv probe/driver ecosystem; impedance and capacitance are factory-tuned to maintain ±1% linearity across the full gap range.
- 4.5 m Sweet Spot – The most versatile extension length: long enough to reach monitor racks mounted away from bearing housings, short enough to avoid signal attenuation issues.
- Rugged Construction – Armored outer jacket resists oil, coolant, and mechanical abrasion in turbine halls and compressor buildings.
- API 670 Compliance – Meets the international standard for machinery protection systems, satisfying EPC contractor and end-user specifications without additional qualification.
- Drop-In Replacement – Identical form, fit, and function to the OEM cable; no recalibration of the monitor system required after installation.
Complete System Bill of Materials
The 330930-045-04-05 is part of the Bently Nevada 3300 XL NSv proximity system. A complete channel typically includes:
- Proximity Probe – e.g., 330103-00-06-05-02-00 (8 mm, 5 m cable)
- Extension Cable – 330930-045-04-05 (this item, 4.5 m)
- Proximitor / Driver – e.g., 330180-X1-05 (3300 XL NSv driver)
- Monitor Module – e.g., 3300/16 or 3500/42M (rack-mount vibration monitor)
- Rack / Power Supply – 3300 or 3500 series rack with appropriate PSU
Contact support@konmask.com to source the complete BOM in a single order.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61508 – Functional Safety (SIL-capable installations)
- ATEX / IECEx – Suitable for use in intrinsically safe circuits (verify with local authority)
- CE Marking – Compliant with EU EMC and Low Voltage Directives
- RoHS – Restriction of Hazardous Substances compliant
Quality Assurance & Sourcing
Every 330930-045-04-05 unit shipped by Konmask.com undergoes the following verification process:
- Visual and dimensional inspection against OEM drawings
- Connector continuity and impedance check
- Traceability documentation (batch/lot records available on request)
- Secure anti-static packaging for international freight
We source from authorized distributors and verified surplus channels. Counterfeit-risk screening is applied to all Bently Nevada / Baker Hughes parts.
How to Source This Part
- Email support@konmask.com with your part number and required quantity.
- Receive a formal quotation with lead time and freight options within 24 hours.
- Confirm order; payment via T/T, PayPal, or trade-finance terms for qualified accounts.
- Shipment via DHL / FedEx with tracking; export documentation included.
- Post-delivery technical support available for installation queries.
📞 WhatsApp / Phone: +0086 19859288691
Application-Specific FAQ
Q: Can I use the 330930-045-04-05 with older 3300 (non-XL) probes?
A: No. The NSv extension cable is designed for the 3300 XL NSv system. Using it with legacy 3300 probes may cause calibration errors. Verify your probe part number before ordering.
Q: What is the total system cable length when combined with a standard probe?
A: A 5 m probe cable + 4.5 m extension = 9.5 m total. The 3300 XL NSv system supports total cable lengths up to 9 m or 15 m depending on driver configuration — confirm with your system datasheet.
Q: Is this cable suitable for hazardous area (Zone 1 / Zone 2) installations?
A: The cable itself is passive; hazardous-area suitability depends on the associated Proximitor driver’s ATEX/IECEx certification. Consult the driver datasheet and your site safety authority.
Q: Do you offer other lengths in the 330930 series?
A: Yes. Common alternatives include 330930-020-04-05 (2 m), 330930-060-04-05 (6 m), and 330930-090-04-05 (9 m). Contact us for availability.
Q: Can Konmask provide a certificate of conformance?
A: Yes, a CoC is available upon request at no additional charge.
