Bently Nevada 3500/40-01-00 Proximitor / Velomitor Monitor | Replacement, Equivalent & Selection Guide
The Bently Nevada 3500/40-01-00 is a dual-channel Proximitor/Velomitor Monitor designed for the 3500 Series Machinery Protection System. It accepts signals from eddy-current proximity probes and Velomitor piezo-velocity sensors to provide continuous vibration monitoring for rotating machinery in critical industrial applications.
Technical Specifications
- Part Number: 3500/40-01-00
- Series: Bently Nevada 3500
- Module Type: Dual-Channel Proximitor / Velomitor Monitor
- Input Channels: 2 (accepts Proximitor or Velomitor sensor signals)
- Measurement Parameters: Radial vibration, axial position, velocity
- Sensor Compatibility: 3300 XL / 7200 Series Proximitors; Velomitor CT / XA sensors
- Output: 4–20 mA buffered transducer output per channel
- Relay Outputs: Alert and Danger relay via 3500/32 Relay Module
- Power Supply: Supplied via 3500 rack backplane
- Communication: Compatible with 3500/22M Communication Gateway
- Rack Compatibility: 3500 Rack (19-slot and 6-slot)
- Operating Temperature: 0 °C to +65 °C
- Weight: 910 g (approx.)
- Approvals: CE, FM, CSA (refer to product datasheet for full certifications)
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or direct replacements for the 3500/40-01-00. Always verify firmware revision and rack configuration before substitution:
- 3500/40-01-01 – Upgraded revision with enhanced diagnostics; drop-in replacement in most 3500 racks
- 3500/40M-01-00 – Modular variant with identical channel configuration
- 3500/42M-01-00 – Dual-channel Proximitor Monitor with extended memory; suitable upgrade path
- 3500/44M-01-00 – Aeroderivative Turbine Monitor; compatible in mixed-sensor environments
- 3500/45-01-00 – Position Monitor; alternative for axial-only applications
- Emerson 3500/40 (post-Baker Hughes rebranding) – Functionally identical, same firmware base
Note: Third-party equivalents may exist. Contact support@konmask.com for cross-reference verification.
Why Choose the Original 3500/40-01-00
- Factory-calibrated for highest measurement accuracy on Bently Nevada sensor chains
- Full API 670 compliance for machinery protection in oil & gas and power generation
- Seamless integration with System 1 software for real-time condition monitoring
- Proven reliability in continuous 24/7 operation environments
- OEM firmware and diagnostics support via Emerson / Baker Hughes service network
Typical Applications
- Centrifugal compressors and steam turbines in petrochemical plants
- Gas turbine generators in power generation facilities
- Pumps, fans, and gearboxes in process industries
- Offshore platform rotating equipment monitoring
- LNG plant critical machinery protection systems
System Compatibility
- Rack: Bently Nevada 3500 Rack (3500/05, 3500/05-01-02-00-00-01)
- Power Supply: 3500/15 Power Supply Module
- I/O Module: 3500/20 I/O Module (required for relay and buffered output wiring)
- Communication: 3500/22M Ethernet/Modbus Gateway
- Software: System 1 Evolution, Bently Nevada Rack Configuration Software
- Sensors: 3300 XL 8mm / 11mm Proximitor, 7200 Series, Velomitor CT, Velomitor XA
Selection Guide
Use the table below to select the correct 3500/40 variant for your application:
- Radial vibration (proximity probe): → 3500/40-01-00 ✓
- Velocity measurement (Velomitor): → 3500/40-01-00 ✓
- Axial position only: → Consider 3500/45-01-00
- High-temperature environment (>65 °C): → Consult Emerson for special-order variants
- SIL-rated application: → Verify SIL certification with Emerson; 3500/40 is not inherently SIL-rated
- Replacement for failed module: → Confirm -01-00 vs -01-01 suffix; both are compatible in standard racks
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Pre-shipment functional inspection and visual QC performed
- Original packaging and documentation preserved where available
- Traceability records available upon request for critical installations
- Konmask.com specializes in industrial automation components for B2B buyers globally
How to Order
- Online: Add to cart directly on this page
- Email RFQ: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock items ship within 1–3 business days; ex-stock subject to availability
- Shipping: DHL / FedEx / UPS international express available
- Payment: T/T, PayPal, credit card accepted
Replacement & Compatibility FAQ
Q: Can 3500/40-01-01 replace 3500/40-01-00 directly?
A: Yes, in most standard 3500 racks the -01-01 revision is a drop-in replacement. Verify rack firmware version compatibility before installation.
Q: Is the 3500/40-01-00 compatible with older 3300 Series racks?
A: No. The 3500/40 is designed exclusively for the 3500 Series rack architecture and is not backward-compatible with 3300 Series racks.
Q: Can I use a third-party proximity probe with this monitor?
A: The module is optimized for Bently Nevada Proximitor sensor chains. Third-party probes may require sensitivity and gap voltage verification. Contact us for application support.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all modules. Extended warranty options available on request.
Q: Can you provide a certificate of conformance?
A: Yes, available upon request for qualified B2B orders.
