Vibration Monitoring Solution – Bently Nevada 3500/42-01-00 | 3500 Series
Where This Product Is Used
The Bently Nevada 3500/42-01-00 Internal I/O Module (part numbers 176449-02 + 128229-01) is purpose-built for continuous machinery protection and condition monitoring in mission-critical industrial environments. Typical deployment sites include:
- Oil & Gas Upstream/Downstream: Compressor trains, gas turbines, and centrifugal pumps on offshore platforms and onshore processing facilities
- Power Generation: Steam turbines, hydro generators, and combined-cycle plant rotating equipment requiring 24/7 vibration surveillance
- Petrochemical & Refining: Reactor feed pumps, cracked-gas compressors, and critical agitators where unplanned downtime carries multi-million-dollar consequences
- LNG Terminals: Main refrigerant compressors and boil-off gas handling systems demanding API 670-compliant monitoring
- Pulp & Paper / Mining: Large induced-draft fans, ball mills, and kiln drives integrated into plant-wide DCS/SCADA architectures
Technical Specifications
| Attribute | Detail |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 3500/42-01-00 |
| Sub-Part Numbers | 176449-02 (I/O board) + 128229-01 (terminal block) |
| Series | Bently Nevada 3500 Machinery Protection System |
| Module Type | Internal I/O Module |
| Channel Configuration | Dual-channel vibration / position input |
| Input Signal Types | Proximitor / eddy-current, velocity, acceleration |
| Output | 4–20 mA analog, relay contact (OK / Alert / Danger) |
| Power Supply | Supplied via 3500 rack backplane (24 VDC) |
| Communication | Rack-based backplane; compatible with 3500/20 Communication Gateway |
| Approvals | SIL 1 capable; CE; FM; ATEX (zone-dependent) |
| Operating Temperature | 0 °C to +65 °C |
| Weight | 1,250 g (approx.) |
| Form Factor | Single-slot 3500 rack card |
Why Engineers Specify This Model
- API 670 Compliance: Meets the industry standard for machinery protection systems — mandatory for most EPC and owner-operator specifications in oil & gas
- Dual-Channel Architecture: Monitors two measurement points simultaneously, reducing rack slot count and wiring complexity
- Seamless 3500 Ecosystem Integration: Plug-and-play replacement within existing 3500 racks — no firmware re-flash or rack reconfiguration required
- High-Resolution Measurement: Sub-micron displacement resolution for early-warning detection of rotor instability, rubs, and bearing wear
- Proven Field Reliability: Bently Nevada 3500 series modules are installed on tens of thousands of machines globally with documented MTBF exceeding 10 years
- Configurable Alarm Setpoints: Alert and Danger thresholds independently programmable via System 1 / Rack Configuration Software
Complete System Bill of Materials
For a fully operational 3500 vibration monitoring loop, the following components are typically required alongside the 3500/42-01-00:
- 3500/05 Rack Power Supply Module
- 3500/15 or 3500/20 Communication Gateway
- 3500/22M Transient Data Interface (optional, for waveform capture)
- Bently Nevada 3300 XL or 3300 8mm Proximitor Sensor
- Extension Cable (armored, matched length per calibration)
- 3500 Rack (3, 7, or 14-slot chassis)
- System 1 Evolution Software (for configuration and trending)
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition)
- IEC 61511 — Functional Safety / SIL assessment
- IEC 60068 — Environmental testing (vibration, temperature, humidity)
- CE Marking — EMC Directive 2014/30/EU
- FM / CSA — North American hazardous location approvals (verify suffix)
- ATEX / IECEx — European & international Ex zone ratings (verify suffix)
Quality Assurance & Sourcing
Konmask.com sources Bently Nevada 3500-series modules through authorized distribution channels and vetted surplus networks. Every unit offered undergoes:
- Visual inspection for physical damage, corrosion, and counterfeit indicators
- Label and date-code verification against OEM records
- Functional bench test where applicable
- Anti-static packaging with humidity indicator cards
- Full traceability documentation available on request
We offer genuine OEM new, factory-reconditioned, and tested surplus stock — clearly identified at time of quotation.
How to Source This Part
- Submit an RFQ — Email support@konmask.com with your required quantity, delivery timeline, and any certification requirements
- Receive Quote — Typically within 4 business hours; includes lead time, condition grade, and freight options
- Order Confirmation — Pro-forma invoice issued; payment via T/T, PayPal, or trade credit (approved accounts)
- Shipping — DHL / FedEx Express worldwide; export documentation (CO, packing list, commercial invoice) included
- After-Sales Support — Technical assistance available for installation, configuration, and compatibility queries
Application-Specific FAQ
Q: Is the 3500/42-01-00 compatible with both proximitor and velocity inputs?
A: Yes. The module supports eddy-current (proximitor), velocity, and acceleration transducer inputs. Input type is configured via the Rack Configuration Software — no hardware modification required.
Q: Can this module replace a 3500/42M in an existing rack?
A: The 3500/42-01-00 and 3500/42M occupy the same rack slot and share the same backplane connector. Compatibility depends on firmware version and rack revision — contact us with your rack serial number for confirmation.
Q: What is the difference between part numbers 176449-02 and 128229-01?
A: 176449-02 is the main I/O circuit board; 128229-01 is the mating terminal block / I/O connector. Both are required for a complete, field-wirable assembly.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 12-month warranty on all tested and reconditioned units. New OEM units carry the original manufacturer warranty.
Q: Can you supply the matching Proximitor sensors and cables?
A: Yes. We stock a broad range of Bently Nevada 3300 and 3500 series transducers, extension cables, and rack accessories. Request a complete BOM quote.
