Bently Nevada 3500/61-01-00 163179-02+133819-02 Temperature Monitor | Replacement, Equivalent & Selection Guide
The Bently Nevada 3500/61-01-00 (P/N 163179-02 + 133819-02) is a dedicated Temperature Monitor module within the Bently Nevada 3500 Series machinery protection system. It provides continuous temperature measurement with analog recorder outputs, designed for critical rotating machinery in oil & gas, power generation, and heavy industrial environments. This page serves as a comprehensive selection, replacement, and compatibility reference for procurement engineers and maintenance teams.
Technical Specifications
- Model: 3500/61-01-00
- Part Numbers: 163179-02 (Monitor) + 133819-02 (I/O Module)
- Series: Bently Nevada 3500
- Function: Temperature monitoring with recorder (4–20 mA) outputs
- Input Type: Thermocouple / RTD (configuration-dependent)
- Recorder Output: 4–20 mA analog, isolated
- Channels: Up to 4 temperature channels per module
- Rack Compatibility: Bently Nevada 3500 Rack (standard 19″ rack mount)
- Communication: Supports Modbus RTU / TCP (via rack gateway)
- Power Supply: Supplied via 3500 rack backplane
- Operating Temperature: 0°C to +65°C
- Certifications: CE, SIL 1 capable (system-level)
- Weight: 1,230 g (module assembly)
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or direct replacements for the 3500/61-01-00 in temperature monitoring applications. Always verify rack firmware version and I/O module compatibility before substitution.
- Bently Nevada 3500/61-00-00 — Base variant without recorder output; suitable where 4–20 mA output is not required
- Bently Nevada 3500/61-02-00 — Enhanced variant with dual-channel recorder output
- Bently Nevada 3500/62-01-00 — Process variable monitor; compatible I/O footprint, broader input range
- Emerson CSI 6500 ATG — Next-generation platform; requires rack migration but offers expanded diagnostics
- Metrix ST5484E — Third-party equivalent for temperature/vibration monitoring; DIN-rail mount alternative
- Rockwell 1715-AENTR — Not a direct replacement; requires engineering re-design for SIL-rated applications
Note: Cross-brand substitutions require full I/O mapping review and system re-validation. Contact Konmask engineering support for assistance.
Why Choose the Original Model
- OEM Accuracy: Factory-calibrated to Bently Nevada 3500 system tolerances; no re-calibration required on installation
- Seamless Integration: Plug-and-play with existing 3500 racks — no firmware changes or re-wiring
- SIL Compliance: Maintains system-level SIL integrity; third-party substitutes may invalidate safety certification
- Long-Term Support: Bently Nevada (Emerson) provides extended lifecycle support, firmware updates, and spare parts
- Proven Reliability: Deployed in thousands of critical machinery protection systems globally
Typical Applications
- Bearing temperature monitoring on gas turbines, steam turbines, and compressors
- Motor winding temperature protection in power generation facilities
- Heat exchanger and process fluid temperature surveillance
- Continuous temperature trending with DCS/SCADA recorder integration via 4–20 mA loop
- Offshore platform and refinery critical machinery protection systems
System Compatibility
- Rack: Bently Nevada 3500 Rack (all standard frame sizes)
- Power Module: 3500/15 Power Supply Module
- Communication Gateway: 3500/92 Communication Gateway (Modbus, Ethernet)
- System Software: System 1 (v6.x and above), Bently Nevada 3500 Rack Configuration Software
- DCS Integration: Compatible with Emerson DeltaV, Honeywell Experion, ABB 800xA via 4–20 mA or Modbus
- Not Compatible With: 3300 Series racks; 1900/65 Series (different backplane architecture)
Selection Guide
Use the following criteria to confirm the correct model for your application:
- Step 1 — Input Type: Confirm sensor type (thermocouple J/K/T or RTD PT100/PT1000). The -01-00 suffix supports standard thermocouple inputs; verify I/O module 133819-02 matches your sensor wiring.
- Step 2 — Output Requirement: If 4–20 mA recorder output to DCS/historian is required, confirm -01-00 variant (recorder output enabled). Use -00-00 if output is not needed.
- Step 3 — Channel Count: Single module supports up to 4 channels. For higher channel density, consider multiple modules or the 3500/62 process monitor.
- Step 4 — Rack Slot Availability: Verify available slots in your 3500 rack. Each 3500/61 occupies 2 adjacent slots (monitor + I/O module).
- Step 5 — Firmware Version: Confirm rack firmware v3.x or above for full feature support. Contact Konmask if firmware version is unknown.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels with full traceability documentation
- Pre-shipment functional test available on request (test report provided)
- Original packaging preserved where available; repackaged units clearly labeled
- 12-month warranty on all stocked units; extended warranty available
- Export compliance: ECCN classification reviewed; export license obtained where required
How to Order
- Confirm part numbers: 163179-02 (Monitor Module) + 133819-02 (I/O Module) — both required for complete assembly
- Specify quantity and required delivery timeline
- Request a quotation via support@konmask.com or call +0086 19859288691
- Provide end-use declaration for export compliance if shipping outside China
- Payment: T/T, PayPal, or trade finance terms available for qualified buyers
Replacement & Compatibility FAQ
Q: Can I use the 3500/61-00-00 instead of the 3500/61-01-00?
A: Yes, if you do not require the 4–20 mA recorder output. The -00-00 variant is functionally identical for temperature measurement but omits the analog output channel.
Q: Is the 133819-02 I/O module interchangeable with other 3500/61 I/O modules?
A: The 133819-02 is specific to thermocouple input configurations. RTD applications require a different I/O module. Verify your sensor type before ordering.
Q: Will this module work in a 3300 Series rack?
A: No. The 3500 and 3300 series use incompatible backplane architectures. The 3500/61 is exclusively for 3500 Series racks.
Q: Can Konmask provide a functional test certificate?
A: Yes. Pre-shipment functional testing with a written test report is available upon request at no additional charge for orders above 2 units.
Q: What is the lead time for this module?
A: In-stock units ship within 3–5 business days. For out-of-stock items, typical lead time is 4–8 weeks. Contact us for current availability.
