Machinery Protection Communication Solution – Bently Nevada 3500/92-04-01-00 | 3500 Series
Where This Product Is Used
The Bently Nevada 3500/92-04-01-00 Communication Gateway is engineered for mission-critical industrial environments where real-time machinery health data must be transmitted reliably to plant-wide control and monitoring systems. Typical deployment sites include:
- Oil & Gas Facilities – Compressor trains, turbines, and pumping stations requiring continuous vibration and process data relay to DCS/SCADA platforms.
- Power Generation Plants – Steam and gas turbine protection racks integrated with plant historians and operator workstations via Modbus or Ethernet.
- Petrochemical & Refining – Rotating equipment monitoring systems where the 3500 rack must communicate alarm and trip data to safety instrumented systems (SIS).
- Marine & Offshore Platforms – Harsh-environment installations demanding robust serial and network communication with minimal latency.
- Pulp, Paper & Heavy Industry – Multi-rack 3500 systems networked to centralized condition monitoring software (e.g., System 1).
Technical Specifications
| Attribute | Detail |
|---|---|
| Part Number / SKU | 3500/92-04-01-00 |
| Series | Bently Nevada 3500 |
| Module Type | Communication Gateway |
| Communication Protocols | Modbus RTU, Modbus TCP/IP, Serial RS-232/RS-485, Ethernet |
| Rack Compatibility | Bently Nevada 3500 Machinery Protection System Rack |
| Slot Position | Dedicated communication slot (rack-dependent) |
| Power Supply | Supplied via 3500 rack backplane |
| Operating Temperature | 0 °C to +60 °C |
| Weight | 700 g (approx.) |
| Form Factor | Single-width 3500 series module card |
| Firmware | Field-upgradeable via Bently Nevada configuration software |
Why Engineers Specify This Model
- Seamless DCS/SCADA Integration – Bridges the 3500 rack to Honeywell, Emerson, ABB, Siemens, and Yokogawa control systems without additional protocol converters.
- Dual-Port Ethernet – Supports redundant network topologies, eliminating single points of failure in critical communication paths.
- High-Speed Data Throughput – Delivers low-latency alarm and trip status updates essential for SIL-rated safety loops.
- Backward Compatibility – Drop-in replacement for legacy 3500/92 variants; no rack rewiring required.
- Centralized Configuration – Fully configurable via Bently Nevada’s rack configuration software, reducing commissioning time.
- Proven Field Reliability – Widely deployed across API 670-compliant installations globally.
Complete System Bill of Materials
For a fully operational Bently Nevada 3500 communication node, engineers typically specify:
- 3500/92-04-01-00 – Communication Gateway Module (this item)
- 3500/20 – Rack Interface Module (RIM)
- 3500/15 – Power Supply Module
- 3500/22M – Transient Data Interface (TDI)
- 3500/40M – Proximitor / Seismic Monitor
- 3500/42M – Proximitor / Seismic Monitor (dual-channel)
- 3500/50M – Tachometer Module
- 3500/60 – Temperature Monitor
- Rack chassis (3500 series, 4- or 14-slot)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61508 / IEC 61511 – Functional Safety (SIL-capable system architecture)
- CE Marking – European conformity for EMC and low-voltage directives
- UL / cUL Listed – North American safety certification
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
Every Bently Nevada 3500/92-04-01-00 unit shipped by Konmask.com undergoes a structured quality verification process:
- Visual inspection for physical damage, corrosion, and connector integrity
- Functional power-on test and firmware version verification
- Traceability documentation provided upon request (serial number, revision level)
- Sourced from authorized distributors, certified refurbishers, or decommissioned plant stock with full disclosure
- 30-day return window for DOA (Dead on Arrival) units
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Add to Cart – Immediate checkout for stocked units
- Request a Quote – Email support@konmask.com with your PO requirements, delivery timeline, and quantity
- Bulk / Project Orders – Contact us for volume pricing on multi-rack system builds
- Lead Time – In-stock units ship within 1–3 business days; ex-stock lead times quoted on request
- Global Shipping – DHL, FedEx, and UPS express options available to 150+ countries
Application-Specific FAQ
Q: Is the 3500/92-04-01-00 compatible with all 3500 rack sizes?
A: Yes. It is compatible with both 4-slot and 14-slot 3500 series rack chassis, occupying the designated communication gateway slot.
Q: Can this module communicate with a Modbus TCP master simultaneously with a serial Modbus RTU master?
A: Yes. The -04-01-00 variant supports concurrent Modbus TCP and RTU sessions, enabling parallel DCS and local HMI connectivity.
Q: Does this replace the older 3500/92-01-01-00 or 3500/92-02-01-00 variants?
A: The 3500/92-04-01-00 is the current-generation variant and is backward-compatible with earlier 3500/92 form factors. Verify firmware compatibility with your rack configuration software version before installation.
Q: Is a Bently Nevada software license required to configure this module?
A: Configuration requires Bently Nevada’s rack configuration software (typically supplied with the 3500 system). Contact us if you need assistance sourcing the software or a configuration service.
Q: What warranty is provided?
A: Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available upon request.
