Industrial HMI Solution – Bosch Rexroth VDP40.3DIN-D1-NN-CG | IndraControl V Series
Where This Product Is Used
The Bosch Rexroth VDP40.3DIN-D1-NN-CG is a DIN-rail-mounted control and display unit from the IndraControl V series, engineered for demanding industrial environments where compact panel space and reliable operator interaction are critical. Typical deployment scenarios include:
- CNC Machining Centers – Operator interface for axis control, program selection, and real-time status monitoring on multi-axis milling and turning machines.
- Robotic Work Cells – Local HMI node integrated with Bosch Rexroth IndraMotion MTX/MLC controllers for teach-in, jog, and diagnostic display.
- Automated Assembly Lines – Decentralized display unit mounted inside control cabinets to surface PLC status, alarm codes, and production counters without a full panel PC.
- Hydraulic & Press Systems – Paired with Rexroth IndraDrive or IndraControl platforms to visualize pressure setpoints, cycle counts, and fault diagnostics.
- Packaging & Material Handling – Compact form factor fits DIN-rail installations in space-constrained conveyor and palletizing control panels.
- Energy & Utilities – Substation and pump-station control cabinets requiring a rugged, low-power display interface.
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number / SKU | VDP40.3DIN-D1-NN-CG |
| Series | IndraControl V (VDP40) |
| Manufacturer | Bosch Rexroth AG |
| Device Type | Control / Display Unit |
| Mounting Style | DIN-rail (DIN) |
| Display Variant | D1 – Integrated display module |
| Communication | NN – Standard interface configuration |
| Color / Housing | CG – Light grey RAL 7035 |
| Weight (approx.) | 19 kg (shipping weight incl. packaging) |
| Country of Origin | Germany |
| Compatibility | IndraControl V platform; IndraMotion MTX / MLC; IndraDrive series |
Full electrical ratings, I/O specifications, and dimensional drawings are available in the Bosch Rexroth VDP40 documentation (DOK-IWORKS-VDP40*V3-AW01-EN-P). Contact us for the datasheet.
Why Engineers Specify This Model
- DIN-Rail Integration – Eliminates the need for a dedicated panel cutout; snaps directly onto standard 35 mm DIN rail inside the control cabinet, saving engineering time and panel real estate.
- Native Rexroth Ecosystem Compatibility – Designed to communicate natively with IndraControl and IndraMotion platforms, reducing integration risk and commissioning time versus third-party HMIs.
- Compact Footprint, Full Functionality – Delivers operator display and control input in a single DIN-rail unit, ideal for retrofit projects where space is at a premium.
- Industrial-Grade Reliability – Built to Bosch Rexroth’s stringent quality standards for continuous-duty industrial operation, with robust EMC shielding suitable for noisy drive environments.
- Simplified Spare-Parts Management – A single SKU covers display and control functions, reducing the number of line items in your spare-parts inventory.
Complete System Bill of Materials
For a fully operational IndraControl V operator station, engineers typically specify the following alongside the VDP40.3DIN-D1-NN-CG:
- Bosch Rexroth IndraControl V IPC or VCP controller module
- Bosch Rexroth IndraDrive Cs/Mi drive (axis-count dependent)
- Rexroth system cable set (display-to-controller ribbon/connector)
- 24 VDC DIN-rail power supply (Rexroth PST or equivalent, ≥ 5 A)
- DIN-rail terminal blocks and grounding bus bar
- Surge protection module (per IEC 61643-11) for cabinet power feed
Contact support@konmask.com for bundle pricing on complete system configurations.
Compliance & Industry Standards
- CE Marking – EU Machinery Directive 2006/42/EC & EMC Directive 2014/30/EU
- UL / cUL Listed (Bosch Rexroth factory certification – verify current listing with Rexroth)
- RoHS 2 Compliant (Directive 2011/65/EU)
- IEC 61131-2 – Programmable controllers: equipment requirements and tests
- EN 60068 – Environmental testing (vibration, shock, temperature)
Quality Assurance & Sourcing
Konmask.com sources industrial automation components through verified supply channels. Every unit offered is:
- Inspected for physical integrity and label authenticity prior to listing
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging where available
- Traceable via manufacturer serial number and date code
We do not sell counterfeit, refurbished-as-new, or grey-market goods. If you require a Certificate of Conformance or test report, please request it at the time of order.
How to Source This Part
- Add to Cart – Click Add to Cart above and proceed to checkout for standard web orders.
- Request a Quote – For volume orders (3+ units), OEM pricing, or project-based procurement, email support@konmask.com with your project details.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock or factory-order items: lead time quoted on request.
- Export & Cross-Border – We ship globally. Export documentation (commercial invoice, packing list, HS code 8537.10) provided for all international shipments.
- Phone / WeChat – Reach our technical sales team at +0086 19859288691 for urgent requirements.
Application-Specific FAQ
Q: Is the VDP40.3DIN-D1-NN-CG compatible with IndraMotion MTX CNC controllers?
A: Yes. The VDP40 series is designed as the operator display interface for Bosch Rexroth’s IndraControl V and IndraMotion MTX platforms. Confirm firmware revision compatibility with your MTX version before installation.
Q: Can this unit replace a VDP40.2 in an existing installation?
A: The VDP40.3 is the third-generation variant. Mechanical mounting is DIN-rail compatible with prior generations, but connector pinouts and firmware may differ. Consult the Rexroth migration guide or contact us for a compatibility assessment.
Q: What cable connects the VDP40 to the IndraControl V controller?
A: Bosch Rexroth supplies a dedicated display cable (part number varies by cabinet depth). Specify your cabinet depth when ordering to ensure the correct cable length is included.
Q: Do you offer warranty on this part?
A: Konmask.com provides a 90-day functional warranty on all stocked components. Extended warranty and service contracts are available on request.
Q: Can I get a datasheet or wiring diagram before purchasing?
A: Yes. Email support@konmask.com with your inquiry and we will provide the relevant Bosch Rexroth documentation.
