Machine Control & HMI Solution – B&R 5PP580.1505-00 | Power Panel Series
Where This Product Is Used
The B&R 5PP580.1505-00 Power Panel is engineered for demanding industrial environments where a combined HMI and controller in a single compact unit is essential. Typical deployment scenarios include:
- Packaging Machinery – Real-time recipe management, line speed control, and operator interface on form-fill-seal and cartoning machines.
- Plastics & Injection Molding – Precise cycle monitoring, temperature loop visualization, and alarm management on injection molding cells.
- Food & Beverage Processing – Hygienic-area panel mounting with IP65 front face; ideal for CIP/SOP sequence visualization.
- Automotive Assembly Lines – Station-level HMI for torque monitoring, traceability logging, and error-proofing displays.
- Water & Wastewater Treatment – SCADA front-end terminal for pump control, flow metering, and remote diagnostics.
- Printing & Converting – Web tension control visualization and register adjustment on flexographic and offset presses.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 5PP580.1505-00 |
| Series | Power Panel 500 |
| Manufacturer | B&R Industrial Automation |
| Display Size | 15″ (38.1 cm) TFT LCD |
| Resolution | 1024 × 768 (XGA) |
| Touch Technology | Resistive touchscreen |
| CPU | Intel Atom / Celeron (series-dependent) |
| Operating System | Windows Embedded / B&R Automation Runtime |
| Communication | Ethernet (2×), USB, CAN, POWERLINK |
| Protection Rating | IP65 (front panel) |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Supply Voltage | 24 V DC |
| Weight | 560 g (unit only) |
| Mounting | Panel cut-out, rear mounting clamps |
Why Engineers Specify This Model
- All-in-One Architecture – Eliminates the need for a separate PLC cabinet and HMI terminal, reducing panel footprint by up to 40%.
- B&R Automation Studio Integration – Seamless programming with IEC 61131-3 languages; single-tool engineering environment.
- POWERLINK Real-Time Network – Deterministic Ethernet fieldbus for sub-millisecond cycle times across distributed I/O.
- IP65 Front Protection – Suitable for wash-down and dusty environments without additional enclosure upgrades.
- Scalable I/O Expansion – Compatible with B&R X20 and X67 I/O modules for flexible system growth.
- Long Product Lifecycle – B&R’s 10-year spare parts availability commitment reduces long-term obsolescence risk.
Complete System Bill of Materials
For a complete machine control system based on the 5PP580.1505-00, engineers typically specify:
- B&R 5PP580.1505-00 – Power Panel (this unit)
- B&R X20CP1586 or X20CP3586 – Expansion CPU (if additional processing required)
- B&R X20DI9371 – Digital Input Module (24 V DC, 12-channel)
- B&R X20DO9322 – Digital Output Module (24 V DC, 12-channel)
- B&R X20AI4622 – Analog Input Module (4-channel, ±10 V / 4–20 mA)
- B&R 0PS1300.1 – 24 V DC Power Supply Unit
- B&R POWERLINK Cable Set – Shielded Cat5e for POWERLINK topology
- Panel Mounting Hardware Kit – Rear clamps and gasket seal
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU.
- UL/cUL Listed – Recognized for use in North American industrial control panels.
- IEC 61131-3 – Programming environment supports all five standard PLC languages.
- EN 61000-6-2 / EN 61000-6-4 – Industrial EMC immunity and emission standards.
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU.
Quality Assurance & Sourcing
Every B&R 5PP580.1505-00 unit supplied by Konmask.com undergoes a multi-point inspection process:
- Visual inspection for physical damage, label integrity, and connector condition.
- Power-on functional test verifying display, touch response, and communication ports.
- Firmware version verification against B&R official release notes.
- Anti-static packaging with humidity indicator card for safe international transit.
Units are sourced from authorized B&R distributors and verified surplus channels. Traceability documentation available on request.
How to Source This Part
- In Stock: Add to cart and complete checkout — most orders ship within 1–3 business days.
- Lead Time Orders: Contact us for volume pricing, scheduled delivery, and OEM project support.
- Urgent Requirements: Email support@konmask.com or call +0086 19859288691 for same-day quotation.
- Export & Cross-Border: We ship globally with full commercial invoice, packing list, and HS code documentation for customs clearance.
Application-Specific FAQ
Q: Can the 5PP580.1505-00 run B&R Automation Runtime without a Windows license?
A: Yes. The Power Panel 500 series supports B&R Automation Runtime as a standalone OS, eliminating Windows licensing costs for pure PLC/HMI applications.
Q: Is this unit compatible with B&R Automation Studio 4.x?
A: Yes. The 5PP580.1505-00 is fully supported under Automation Studio 4.x for programming, configuration, and remote monitoring.
Q: What fieldbus protocols does this panel support?
A: Native support for POWERLINK; additional protocols (PROFIBUS, PROFINET, EtherNet/IP, Modbus TCP) available via plug-in interface cards.
Q: Can I replace just the display assembly if the touchscreen is damaged?
A: B&R offers display replacement kits for the PP500 series. Contact Konmask.com for spare part availability and service guidance.
Q: What is the typical lead time for new units from B&R factory?
A: Standard lead time from B&R factory is 8–14 weeks. Konmask.com maintains stock of popular configurations to support urgent project timelines.
