BROOKS 113142 TT1ENR2-1-TVS-NES-BROOKS10 Teach Pendant – Brooks Automation Wafer Transfer System
When a teach pendant fails on a semiconductor wafer transfer line, the consequences are immediate and severe. Operators lose the ability to manually jog, position, and calibrate robotic arms — bringing the entire FOUP-to-process-tool transfer sequence to a halt. In cleanroom environments where every minute of downtime translates to tens of thousands of dollars in lost wafer throughput, having a verified replacement on hand is not optional. It is a production-critical necessity.
The BROOKS 113142 (P/N: TT1ENR2-1-TVS-NES-BROOKS10, Ref: QJ92-1642-A / 0010-07586) is the OEM teach pendant designed for Brooks Automation’s atmospheric and vacuum wafer handling robot platforms. Within the Brooks Automation ecosystem, this unit serves as the primary human-machine interface for robot teaching, diagnostics, and manual override — a role that no generic HMI device can replicate. Brooks Automation commands a dominant position in global semiconductor fab automation, with installations across leading fabs in Taiwan, South Korea, the United States, and Japan.
Technical Specifications
- Manufacturer: BROOKS Automation
- Part Number: 113142
- Model / Config Code: TT1ENR2-1-TVS-NES-BROOKS10
- Reference Numbers: QJ92-1642-A / 0010-07586
- Product Type: Teach Pendant (Robot Programming & Manual Control Interface)
- Compatible Platform: Brooks Automation atmospheric & vacuum wafer transfer robots
- Weight: Approx. 4.1 kg (as shipped)
- Condition: New / Refurbished / Surplus (specify at inquiry)
Key Features & Benefits
- OEM-Matched Interface: Plug-and-play compatibility with Brooks robot controllers — no firmware patching or custom wiring required.
- Full Teach & Jog Capability: Enables precise axis-by-axis positioning for wafer slot teaching, end-effector calibration, and station mapping.
- Integrated Safety Deadman Switch: Compliant with industrial robot safety standards for manual operation in live environments.
- Durable Cleanroom-Ready Construction: Designed to withstand the rigors of semiconductor fab environments including ESD sensitivity and particulate control requirements.
- Diagnostic & Error Readout: Provides real-time robot status, fault codes, and axis position feedback directly on the pendant display.
- Genuine OEM Part: Sourced from authorized channels — not a third-party clone or reverse-engineered substitute.
Industry & Equipment Applications
- Semiconductor wafer fabrication (200mm / 300mm fabs)
- FOUP / SMIF pod handling and EFEM (Equipment Front End Module) systems
- Atmospheric wafer transfer robots (e.g., Brooks Reliance, Advantage series)
- Vacuum cluster tool wafer handling robots
- Photolithography, CVD, PVD, and etch tool front-end automation
- Flat panel display (FPD) substrate handling lines
System Integration & Compatible Parts
This teach pendant is designed for integration within the Brooks Automation robot controller ecosystem. Compatible system components typically include:
- Brooks robot controller cards and backplane assemblies
- Brooks Automation EFEM and loadport modules
- Brooks MagnaTran, Reliance, and Advantage series robot arms
- Associated teach pendant cables and connector harnesses (specify at inquiry)
Note: Always verify compatibility with your specific robot controller firmware version before installation. Contact our technical team for cross-reference support.
Our Quality Assurance Process
- Source Verification: All parts are traced to documented supply chains — OEM overstock, authorized distributors, or decommissioned fab equipment with full provenance records.
- Visual & Physical Inspection: Each unit is inspected for physical damage, connector integrity, label authenticity, and date code consistency.
- Functional Pre-Check: Where applicable, units undergo power-on and communication interface testing prior to shipment.
- Secure Anti-Static Packaging: All electronic components are packed in ESD-safe materials with moisture barrier protection for international transit.
How to Order
- Submit your inquiry via [email protected] with your required part number and quantity.
- Our technical team will confirm availability, condition grade, and lead time within 1 business day.
- Receive a formal quotation with shipping options (DHL / FedEx / sea freight).
- Confirm order and receive tracking information upon dispatch.
For urgent requirements, please indicate “URGENT” in your email subject line or call us directly at +0086 19859288691.
Why Choose Konmask.com?
- Specialized in Industrial Automation: We focus exclusively on automation, robotics, and semiconductor equipment components — not a generalist electronics marketplace.
- Global Sourcing Network: Access to surplus, refurbished, and new-old-stock parts from fabs and OEM channels across Asia, North America, and Europe.
- Technical Expertise: Our team includes engineers with hands-on experience in semiconductor fab automation — we speak your language.
- Fast International Shipping: DHL Express and FedEx International Priority available to 200+ countries, with full export documentation support.
- Transparent Condition Grading: We clearly disclose part condition (new, refurbished, tested surplus) — no surprises on arrival.
Frequently Asked Questions
Q: Is this a genuine BROOKS OEM part or an aftermarket substitute?
A: This is a genuine BROOKS Automation OEM part. We do not sell reverse-engineered or third-party clones. All units are sourced from verifiable supply chains.
Q: Can you provide a certificate of conformance or test report?
A: Yes, documentation availability varies by unit condition and source. Please request at time of inquiry and we will advise on what is available for the specific unit.
Q: What is the lead time for this part?
A: Lead time depends on current stock status. In-stock units typically ship within 2–3 business days. Out-of-stock items are sourced on request, typically 2–4 weeks.
Q: Do you ship to my country?
A: Yes. We ship globally via DHL, FedEx, and sea freight. Export documentation including commercial invoice, packing list, and COO is provided for all international shipments.
Q: What if the part does not match my system?
A: Contact us before purchase with your robot model and controller firmware version. Our technical team will verify compatibility. We also accept returns for incorrectly supplied parts per our return policy.
