DeltaV DCS Signal Repeater Solution – EMERSON KJ2221X1-BA1 | VS6002 Series
Where This Product Is Used
The EMERSON KJ2221X1-BA1 (12P3232X132, VS6002) Repeater Module is deployed across a wide range of process-critical environments where signal integrity over long cable runs is non-negotiable:
- Oil & Gas Upstream/Midstream: SCADA and DCS backbone signal conditioning in remote wellhead and pipeline control panels
- Petrochemical & Refining: Fieldbus segment extension in hazardous-area marshalling cabinets
- Power Generation: Turbine control and boiler management systems requiring reliable I/O signal propagation
- Pulp & Paper / Mining: Long-distance field device communication in large-footprint plant layouts
- Water & Wastewater Treatment: Remote I/O signal repeating between distributed pump stations and central control rooms
- Pharmaceutical Manufacturing: GMP-compliant process control architectures with validated DeltaV DCS platforms
Technical Specifications
| Manufacturer | Emerson Electric / Fisher-Rosemount |
| Part Number | KJ2221X1-BA1 |
| Cross-Reference | 12P3232X132 / VS6002 |
| Module Type | Repeater Module |
| Compatible Platform | Emerson DeltaV DCS Series |
| Form Factor | DIN-rail / Carrier-mounted plug-in module |
| Signal Type | Digital fieldbus / I/O signal repeating |
| Weight | 200 g (approx.) |
| Condition Available | New surplus / Refurbished / Used tested |
| Lead Time | In stock — ships within 1–3 business days |
Why Engineers Specify This Model
- Signal Integrity at Distance: Regenerates and conditions digital signals across extended fieldbus segments, eliminating noise-induced faults in large plant layouts
- Plug-and-Play DeltaV Compatibility: Designed specifically for the DeltaV ecosystem — no custom configuration or firmware flashing required
- Reduced Wiring Complexity: Enables segment extension without additional marshalling hardware, lowering installed cost
- Proven Field Reliability: VS6002 / 12P3232X132 cross-references confirm multi-generation production history with documented MTBF in process environments
- Hot-Swap Capable: Supports live replacement in carrier-mounted configurations, minimizing planned downtime windows
- Compact Footprint: Fits existing DeltaV I/O carrier slots — no panel re-engineering required for retrofit projects
Complete System Bill of Materials
This module is typically specified alongside the following DeltaV components for a complete repeater segment solution:
- DeltaV I/O Carrier / Baseplate (8- or 16-slot)
- DeltaV Controller Module (MD, MD Plus, or S-series)
- DeltaV Power Supply Module (KJ4001X1-BA1 or equivalent)
- Fieldbus Segment Terminator (passive, per IEC 61158)
- Shielded Twisted-Pair Fieldbus Cable (Type A, per IEC 61158-2)
- DeltaV Workstation / Engineering Station (for configuration)
Contact [email protected] for bundle pricing on multi-module BOM sourcing.
Compliance & Industry Standards
- IEC 61158 / IEC 61784: Fieldbus communication standard compliance
- CE Marking: Electromagnetic compatibility and low-voltage directive conformity
- RoHS Compliant: Restriction of Hazardous Substances (where applicable to production batch)
- UL / cUL Listed: North American safety certification (verify with datasheet for specific revision)
- ATEX / IECEx: Consult Emerson documentation for hazardous-area rated variants
- ISA-5.1 / ISA-18.2: Compatible with instrumentation and alarm management standards
Quality Assurance & Sourcing
Every KJ2221X1-BA1 unit sourced through Konmask.com undergoes the following verification process before dispatch:
- ✔ Visual inspection for physical damage, corrosion, and connector integrity
- ✔ Label and part-number cross-check against Emerson OEM documentation
- ✔ Functional power-on test where test fixtures are available
- ✔ Anti-static packaging with humidity indicator card
- ✔ Traceable sourcing records maintained for audit purposes
We supply to EPC contractors, MRO procurement teams, and plant maintenance departments globally. All units are shipped with a 90-day replacement warranty against DOA or latent defects.
How to Source This Part
- Add to Cart — Select quantity and proceed to checkout directly on this page
- Request a Quote — Email [email protected] with your PO number, required quantity, and delivery timeline for volume pricing
- Phone / WhatsApp — Call or message +0086 19859288691 for urgent requirements or technical pre-sales questions
- Bulk / BOM Orders — Submit your full bill of materials to receive a consolidated quote with consolidated shipping
Typical order processing: same-day dispatch for orders placed before 14:00 CST on business days.
Application-Specific FAQ
Q: Is the KJ2221X1-BA1 compatible with all DeltaV controller generations?
A: It is designed for the DeltaV platform and is compatible with MD, MD Plus, and S-series controllers. Confirm firmware revision compatibility with your site’s DeltaV version before installation.
Q: Can this module be used in a FOUNDATION Fieldbus H1 segment?
A: The VS6002 / KJ2221X1-BA1 is a DeltaV-native repeater. For FF-H1 segment extension, verify the specific fieldbus protocol support in the Emerson product datasheet or contact our technical team.
Q: What is the maximum cable extension achievable with this repeater?
A: Per IEC 61158-2 and Emerson application guidelines, a single repeater can extend a segment by up to 1,900 m (Type A cable). Actual distance depends on cable type, number of devices, and installation conditions.
Q: Do you supply the matching I/O carrier for this module?
A: Yes. Contact us with your carrier part number and we will confirm availability and pricing as part of a complete assembly quote.
Q: Is a certificate of conformance (CoC) available?
A: CoC documentation is available upon request for orders requiring traceability records. Please specify this requirement at the time of order.
