Process Control Signal Acquisition Solution — Fisher CL6824X1-A6 (12P0767X032) | DeltaV Series
Where This Product Is Used
The Fisher CL6824X1-A6 Analog Input Board is a critical signal-acquisition module deployed in Emerson DeltaV Distributed Control Systems (DCS) across high-demand process industries. Typical installation environments include:
- Oil & Gas Upstream/Midstream: Wellhead pressure and temperature monitoring, pipeline SCADA integration, separator control loops
- Petrochemical & Refining: Distillation column instrumentation, reactor temperature profiling, heat exchanger control
- Power Generation: Boiler drum level sensing, turbine inlet condition monitoring, emissions compliance measurement
- Pulp & Paper / Chemical: Multi-point pH, flow, and level signal aggregation into DeltaV controllers
- Water & Wastewater Treatment: Pump station telemetry, dosing control, effluent quality monitoring
Wherever a DeltaV system requires reliable 4–20 mA or HART analog signal termination and conversion, the CL6824X1-A6 board provides the hardware backbone.
Technical Specifications
| Part Number | CL6824X1-A6 |
| Reference / BOM Number | 12P0767X032 |
| Manufacturer | Fisher Controls International / Emerson Electric |
| Series / Platform | DeltaV DCS — Analog I/O Subsystem |
| Module Function | Analog Input Signal Termination & Conditioning Board |
| Signal Type | 4–20 mA (HART-compatible field wiring) |
| Form Factor | Plug-in PCB assembly for DeltaV I/O carrier |
| Weight | 960 g (as shipped) |
| Condition | Genuine OEM — tested, inspected, ready to install |
Why Engineers Specify This Model
- OEM Compatibility: Designed exclusively for Emerson DeltaV I/O subsystems — no firmware conflicts, no signal mapping workarounds
- HART Pass-Through: Supports HART communication over the 4–20 mA loop for device diagnostics and asset management via AMS Device Manager
- Hot-Swap Ready: DeltaV architecture allows board replacement without full system shutdown, minimizing process interruption
- Proven Field Reliability: Widely deployed in SIL-rated and non-SIL process control applications globally
- Dual Reference Numbers: CL6824X1-A6 (catalog) and 12P0767X032 (manufacturing BOM) — both cross-reference to the same assembly, simplifying procurement
Complete System Bill of Materials
For a fully operational DeltaV analog input channel using this board, engineers typically specify:
- Fisher CL6824X1-A6 / 12P0767X032 — Analog Input Board (this item)
- DeltaV AI 8-Channel or 16-Channel I/O Card (e.g., VE3005 or equivalent)
- DeltaV I/O Carrier / Marshalling Cabinet
- HART-compatible field transmitter (pressure, temperature, flow, level)
- DeltaV Controller (MD, MD Plus, or S-series)
- DeltaV Workstation with DeltaV Operate / Configure software
Compliance & Industry Standards
- Manufactured under Emerson’s ISO 9001-certified quality management system
- Compatible with IEC 61511 / ISA-84 functional safety frameworks (SIL loop design — consult SIL data sheet)
- Supports NAMUR NE 43 signal range conventions for fault detection
- CE marking applicable per Emerson DeltaV system-level declaration
- RoHS compliance per Emerson product documentation
Quality Assurance & Sourcing
Konmask.com sources Fisher / Emerson DeltaV components through established industrial automation supply channels. Every board offered undergoes:
- Visual inspection for physical damage, corrosion, and component integrity
- Label and part-number verification against Emerson OEM markings
- Functional bench test where applicable
- Anti-static packaging with humidity indicator card for safe transit
We do not sell counterfeit, re-labeled, or non-OEM substitute boards. If you require a Certificate of Conformance or test report, please contact us before ordering.
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Online: Add to cart directly on this page
- Email RFQ: support@konmask.com — include your required quantity, delivery timeline, and any certification requirements
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock items typically ship within 1–3 business days; ex-stock international shipments via DHL / FedEx
Application-Specific FAQ
Q: Is the CL6824X1-A6 compatible with all DeltaV controller generations?
A: This board is designed for the DeltaV I/O subsystem. Compatibility depends on your specific I/O carrier and controller revision. Contact us with your DeltaV system version for confirmation.
Q: Can this board be used in a SIL 2 safety loop?
A: SIL suitability depends on the complete safety loop design, including the field device and logic solver. Consult Emerson’s SIL data sheet for the CL6824X1-A6 and engage a TÜV-certified functional safety engineer for loop assessment.
Q: What is the difference between CL6824X1-A6 and 12P0767X032?
A: These are two reference numbers for the same physical assembly — CL6824X1-A6 is the catalog/ordering number and 12P0767X032 is the internal manufacturing BOM number used by Emerson.
Q: Do you offer exchange / repair services?
A: Yes. We offer board exchange programs for qualifying DeltaV I/O components. Contact us with your defective unit details for a repair or exchange quotation.
Q: Can I get a datasheet or wiring diagram?
A: Yes — email us at support@konmask.com and we will provide available Emerson technical documentation for this part number.
