Engineering Background

The GE IC200UDR005 is a compact, high-reliability programmable logic controller from GE Fanuc’s VersaMax Micro platform — a series purpose-built for distributed I/O control in space-constrained industrial environments. Designed to meet the demands of OEM machine builders and system integrators, this unit delivers deterministic scan-cycle performance with a robust relay output architecture suited for direct load switching without external relay banks.

Product Positioning

Positioned as an entry-to-mid-tier standalone controller, the IC200UDR005 is the preferred choice for engineers who require a self-contained PLC with onboard I/O, native 24VDC operation, and seamless integration into GE Fanuc automation ecosystems. It is widely deployed in packaging lines, conveyor systems, HVAC controls, and light manufacturing automation where footprint and cost-efficiency are critical procurement criteria.

Complete Technical Specifications

Part Number	IC200UDR005
Manufacturer	GE Fanuc / GE Automation & Controls
Series / Platform	VersaMax Micro
Form Factor	Standalone Micro PLC (DIN-rail mountable)
Power Supply	24VDC (nominal), 20.4–28.8VDC operating range
Total Onboard I/O	28 points
Digital Inputs	16 × 24VDC discrete inputs
Digital Outputs	12 × relay outputs (Form A, normally open)
Output Contact Rating	2A per point, 8A per common
Program Memory	10 KB user program memory
Data Memory	10 KB data memory
Scan Time	~0.6 ms/K (Boolean), ~1.0 ms/K (mixed)
Communication Port	1 × RS-232 serial (SNP/SNP-X protocol)
Programming Software	Proficy Machine Edition (ME) / VersaPro
Programming Languages	Ladder Diagram (LD), Instruction List (IL)
Operating Temperature	0°C to +55°C
Storage Temperature	-40°C to +85°C
Relative Humidity	5% to 95% non-condensing
Protection Rating	IP20
Certifications	UL, CE, cUL
Dimensions (W×H×D)	Approx. 140 × 90 × 70 mm
Weight	Approx. 400 g
Mounting	35mm DIN rail or panel mount

Proven Application Environments

• Packaging & Labeling Machines – Relay outputs directly drive solenoids, motors, and actuators without intermediate relay panels.
• Conveyor & Material Handling – Deterministic scan cycle ensures precise sequencing and interlock logic.
• HVAC & Building Automation – 24VDC native operation aligns with standard building control power architectures.
• OEM Machine Control – Compact footprint and DIN-rail mounting simplify panel integration for machine builders.
• Pump & Motor Control Panels – Relay outputs rated for direct motor starter coil switching.
• Light Manufacturing Automation – Cost-effective standalone control for single-machine or small-cell automation.

Engineering Advantages

• Relay Output Architecture – Eliminates the need for external relay modules; outputs switch AC or DC loads directly, reducing BOM cost and panel complexity.
• Deterministic Scan Performance – Sub-millisecond Boolean scan time ensures reliable timing-critical logic execution.
• Native 24VDC Power – Operates directly from standard 24VDC control power supplies; no additional power conversion required.
• GE Fanuc Ecosystem Compatibility – Fully programmable via Proficy Machine Edition; integrates with GE HMI, SCADA, and motion platforms.
• Compact DIN-Rail Form Factor – Minimizes panel real estate; suitable for retrofit and space-constrained new builds.
• Wide Temperature Tolerance – Operates reliably from 0°C to 55°C, covering most industrial indoor environments without additional thermal management.

System Architecture & Signal Flow

The IC200UDR005 operates as a self-contained control node. The 24VDC supply powers the CPU and input circuitry. The 16 discrete inputs accept 24VDC field signals (sensors, switches, pushbuttons) and pass them through optical isolation to the CPU. The CPU executes the user ladder program each scan cycle and updates the 12 relay output coils accordingly. Each relay output is independently addressable and switches the connected load circuit. The RS-232 port provides programming access and can be used for HMI communication via SNP protocol. No expansion modules are supported on this base unit — for expanded I/O, the VersaMax Micro Plus or VersaMax Nano platforms should be evaluated.

Sourcing & Quality Verification

• Authenticity – All units sourced through verified industrial distribution channels. Counterfeit screening performed on every batch.
• Condition – New (factory-sealed) and refurbished (tested, cleaned, re-labeled) stock available. Condition clearly stated per listing.
• Testing Protocol – Refurbished units undergo power-on functional test, I/O point verification, and communication port check prior to shipment.
• Traceability – Date codes and lot numbers documented. Available upon request for quality-critical procurement.
• Warranty – 12-month warranty on all units. Defective units replaced or refunded within warranty period.

Procurement Process

1. Confirm Part Number – Verify IC200UDR005 against your BOM or existing panel documentation. Cross-reference with GE catalog if substitution evaluation is needed.
2. Select Condition & Quantity – Choose new or refurbished stock. Bulk pricing available for orders of 5+ units — contact us for a quote.
3. Place Order – Add to cart and complete checkout. Purchase orders (PO) accepted for qualified B2B accounts.
4. Shipping & Lead Time – In-stock units ship within 1–3 business days. Express shipping available. International orders supported with full customs documentation.
5. Post-Delivery Support – Technical support available for installation, programming, and integration questions. Contact support@konmask.com.

Technical FAQ

Q: Can the IC200UDR005 be expanded with additional I/O modules?
A: No. The IC200UDR005 is a fixed-I/O standalone unit. For expandable I/O, consider the VersaMax Micro Plus (IC200UDR020 or similar) which supports expansion modules.

Q: What programming software is required?
A: GE Proficy Machine Edition (ME) is the current supported programming environment. Legacy VersaPro software is also compatible for older projects.

Q: What communication protocols does the IC200UDR005 support?
A: The onboard RS-232 port supports GE SNP and SNP-X protocols. Modbus RTU is not natively supported on this model without a third-party converter.

Q: Are the relay outputs rated for AC loads?
A: Yes. The relay outputs are dry-contact Form A relays rated for both AC and DC loads. Verify the specific voltage and current ratings against your load requirements before wiring.

Q: Is a battery required for program retention?
A: The IC200UDR005 uses flash memory for program storage — no battery is required for program retention. A battery may be required for real-time clock functions if applicable to your configuration.

Q: Can I use this unit as a replacement for an existing IC200UDR005 in a running system?
A: Yes, provided the replacement unit is loaded with the same program version. Backup your existing program from the original unit before replacement using Proficy ME.

---
