Industrial SCADA & Serial Communication Solution – GE IC693CMM302 | Series 90-30
Where This Product Is Used
The GE IC693CMM302 Communication Module (CCM) is engineered for mission-critical industrial environments where reliable serial data exchange is non-negotiable. Typical deployment scenarios include:
- SCADA & DCS Integration: Connects Series 90-30 PLCs to supervisory control systems via RS-232/RS-422/RS-485 serial protocols, enabling real-time process monitoring in oil & gas, water treatment, and power generation plants.
- Manufacturing Execution Systems (MES): Bridges shop-floor PLC data to MES platforms in automotive, food & beverage, and pharmaceutical production lines.
- Legacy System Modernization: Provides a cost-effective serial communication path for existing Series 90-30 installations requiring protocol conversion without full system replacement.
- Remote Terminal Unit (RTU) Communication: Used in pipeline monitoring, substation automation, and remote I/O applications requiring point-to-point or multi-drop serial links.
- Machine-to-Machine (M2M) Communication: Facilitates data exchange between PLCs and third-party devices such as drives, HMIs, barcode readers, and weighing systems.
Technical Specifications
| Part Number | IC693CMM302 |
| Series | GE Series 90-30 |
| Module Type | Communication Co-Processor Module (CCM) |
| Serial Ports | 2 × RS-232 / RS-422 / RS-485 (software selectable) |
| Protocols Supported | SNP, SNP-X, RTU, ASCII, Modbus RTU (via ladder logic) |
| Baud Rate | Up to 19,200 bps |
| Backplane Interface | Series 90-30 CPU backplane (5-slot or 10-slot rack) |
| Power Consumption | 1.0 A @ 5 VDC (from backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Weight | 1,670 g (approx.) |
| Certifications | UL Listed, CE Marked, cUL |
| Form Factor | Single-slot Series 90-30 module |
Why Engineers Specify This Model
- Dual Independent Serial Ports: Two fully independent channels allow simultaneous communication with multiple devices or networks, eliminating the need for external serial splitters.
- Protocol Flexibility: Software-selectable RS-232/422/485 and support for SNP, SNP-X, and ASCII protocols make this module adaptable to virtually any serial device in the field.
- Co-Processor Architecture: Offloads communication processing from the main CPU, ensuring deterministic PLC scan times are not impacted by communication overhead — critical in high-speed process control.
- Proven Reliability: Designed to GE’s industrial-grade standards with wide temperature tolerance and vibration resistance for harsh plant environments.
- Drop-in Compatibility: Fits any Series 90-30 rack slot without hardware modification, simplifying upgrades and spare-parts management.
Complete System Bill of Materials
For a fully operational Series 90-30 communication node, engineers typically specify:
- IC693CMM302 — Communication Co-Processor Module (this item)
- IC693CPU364 / IC693CPU374 — Series 90-30 CPU Module
- IC693CHS391 / IC693CHS392 — 5-Slot or 10-Slot Baseplate/Rack
- IC693PWR321 / IC693PWR330 — Series 90-30 Power Supply
- IC693MDL655 / IC693MDL752 — Digital I/O Modules (as required)
- IC693ALG220 / IC693ALG390 — Analog I/O Modules (as required)
- IC690ACC901 — RS-232 Programming Cable (for initial configuration)
Compliance & Industry Standards
- UL 508 — Industrial Control Equipment
- CE Directive — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- cUL — Canadian Standards (CSA C22.2)
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- RoHS Compliant — Restriction of Hazardous Substances
Quality Assurance & Sourcing
Every GE IC693CMM302 unit offered by Konmask.com undergoes a rigorous multi-stage inspection process:
- ✅ Visual Inspection: Board-level examination for physical damage, corrosion, or counterfeit indicators
- ✅ Functional Power-On Test: Module powered and communication ports verified active
- ✅ Firmware Version Check: Confirmed against GE’s published revision history
- ✅ Burn-In Testing: Extended operational cycle to screen for early-life failures
- ✅ ESD-Safe Packaging: Shipped in anti-static bags with foam cushioning and moisture barrier
Units are sourced from authorized distributors, decommissioned OEM equipment, and certified refurbishers. Condition (New / Refurbished / Surplus) is clearly stated on each listing.
How to Source This Part
Konmask.com maintains stock of the IC693CMM302 for immediate dispatch. To place an order or request a quote:
- 📧 Email: support@konmask.com
- 📞 Phone/WhatsApp: +0086 19859288691
- 🌐 Online: Add to cart directly on this page for standard orders
- 💼 Bulk / OEM Inquiries: Contact us for volume pricing, blanket orders, and consignment stock arrangements
Typical lead time: In-stock items ship within 1–3 business days. Express air freight available for urgent plant shutdowns.
Application-Specific FAQ
Q: Can the IC693CMM302 communicate using Modbus RTU?
A: Yes. While the module natively supports GE’s SNP/SNP-X protocols, Modbus RTU communication can be implemented via ladder logic using the module’s ASCII/RTU serial ports. Many system integrators use this approach to interface with third-party drives and meters.
Q: Is this module compatible with the Series 90-30 CPU374 (Ethernet CPU)?
A: Yes. The IC693CMM302 occupies a standard backplane slot and is fully compatible with all Series 90-30 CPUs, including the IC693CPU374. It operates independently of the CPU’s Ethernet port.
Q: What is the maximum cable length for RS-485 multi-drop networks?
A: RS-485 supports cable runs up to 1,200 meters (4,000 ft) at lower baud rates. For the IC693CMM302, GE recommends shielded twisted-pair cable (Belden 9842 or equivalent) and proper termination resistors at both ends of the bus.
Q: Can I use two IC693CMM302 modules in the same rack?
A: Yes. Multiple CCM modules can coexist in the same rack, each assigned a unique slot address. This is common in applications requiring more than two serial communication channels.
Q: Do you provide a warranty?
A: All units sold by Konmask.com carry a minimum 90-day functional warranty. Extended warranty options are available upon request.
