GE IC200CPUE05-FH – High-Performance Embedded Ethernet CPU | VersaMax Micro PLUS Platform
Engineering Background
The IC200CPUE05-FH is a compact, high-capability CPU module from GE Fanuc’s VersaMax Micro PLUS series — a platform engineered for demanding discrete and process control applications where space, connectivity, and deterministic scan performance are non-negotiable. Designed for panel-mount environments, this CPU integrates a native Ethernet port, eliminating the need for external communication modules and reducing BOM complexity in networked automation architectures.
Product Positioning
Targeted at OEM machine builders, system integrators, and plant engineers who require a reliable, mid-range PLC CPU with embedded Ethernet connectivity, the IC200CPUE05-FH bridges the gap between entry-level micro PLCs and full-rack modular systems. It is a direct fit for standalone machine control, distributed I/O coordination, and SCADA-connected edge nodes.
Complete Technical Specifications
| Part Number | IC200CPUE05-FH |
| Manufacturer | GE Fanuc / GE Automation & Controls |
| Series | VersaMax Micro PLUS |
| CPU Type | Embedded Ethernet CPU |
| Program Memory | 14 KB (ladder logic) |
| Data Memory | 14 KB |
| Onboard I/O | 28 points (16 DI / 12 DO) |
| Input Voltage | 24 VDC |
| Output Type | Relay |
| Communication Port 1 | RS-232 (serial programming / HMI) |
| Communication Port 2 | 10/100 Mbps Ethernet (RJ-45) |
| Supported Protocols | SRTP, Modbus TCP, EGD (Ethernet Global Data) |
| Expansion Capability | Up to 4 expansion modules (IC200 series) |
| Scan Time | ~0.6 ms/K (Boolean) |
| Real-Time Clock | Yes (battery-backed) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Protection Rating | IP20 |
| Mounting | DIN rail / panel mount |
| Dimensions (W×H×D) | Approx. 130 × 90 × 70 mm |
| Weight | ~400 g |
| Power Consumption | ≤ 5 W |
| Certifications | UL, CE, cUL |
| Programming Software | Proficy Machine Edition (PME) |
| Firmware Suffix | -FH (latest production revision) |
Proven Application Environments
- Discrete Manufacturing: Assembly line sequencing, conveyor control, pick-and-place coordination
- Packaging Machinery: OEM filling, labeling, and wrapping machines requiring compact footprint
- Building Automation: HVAC control, access control panels, energy monitoring nodes
- Water & Wastewater: Pump station control with remote SCADA visibility via Modbus TCP
- Food & Beverage: Hygienic process control in panel-mount enclosures
- Oil & Gas Peripherals: Wellhead monitoring, skid-mounted control panels
- Distributed I/O Networks: Edge node in EGD-based peer-to-peer architectures
Engineering Advantages
- Native Ethernet eliminates gateway cost: Direct Modbus TCP / SRTP connectivity without add-on communication modules, reducing panel space and wiring complexity.
- Deterministic scan performance: ~0.6 ms/K Boolean scan ensures tight timing loops for high-speed discrete control.
- Compact form factor: DIN-rail mountable with 28 onboard I/O points — ideal for space-constrained panels.
- Expandable architecture: Up to 4 IC200-series expansion modules (analog, digital, specialty) without additional CPU overhead.
- Battery-backed RTC: Maintains time-stamped event logs and scheduled tasks through power cycles.
- Proficy Machine Edition compatibility: Full IEC 61131-3 programming environment with online diagnostics, force tables, and data logging.
- -FH revision: Latest production firmware suffix — ensures compatibility with current PME software releases and long-term spare parts availability.
System Architecture & Signal Flow
The IC200CPUE05-FH operates as the master controller in a VersaMax Micro PLUS backplane. Signal flow is as follows:
- Field Inputs (16 DI): 24 VDC discrete signals from sensors, pushbuttons, and limit switches are scanned each CPU cycle.
- CPU Execution: Ladder logic executes against the input image table; outputs are resolved and written to the output image table.
- Field Outputs (12 DO Relay): Relay contacts switch loads up to the rated current — suitable for direct actuation of solenoids, contactors, and pilot lights.
- Expansion Bus: Up to 4 IC200 expansion modules extend I/O capacity; data is exchanged over the internal backplane bus each scan.
- Ethernet Port: SRTP/Modbus TCP frames are processed asynchronously; EGD exchanges are scheduled at configurable intervals independent of the PLC scan.
- RS-232 Port: Used for HMI communication (SNP/SNPX protocol) or local programming via PME.
Sourcing & Quality Verification
- Origin: Genuine GE Fanuc / GE Automation & Controls manufactured hardware — not aftermarket or remanufactured.
- Inspection: Each unit undergoes visual inspection, label verification (part number, revision suffix, date code), and functional power-on check prior to shipment.
- Packaging: Ships in anti-static ESD bag with original or equivalent protective packaging. Fragile components are foam-cushioned for international transit.
- Traceability: Serial number and firmware revision documented per order for warranty and maintenance records.
- Condition: New surplus or factory-refurbished stock clearly disclosed at time of quotation — no misrepresentation of condition.
Procurement Process
- Confirm Part Number: Verify IC200CPUE05-FH matches your BOM — check firmware suffix (-FH) and I/O configuration against your application requirements.
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation.
- Place Order: Purchase directly via Konmask.com product page or via PO for B2B accounts.
- Shipping: DHL / FedEx / UPS international express available. Domestic CN orders ship same or next business day.
- Documentation: Commercial invoice, packing list, and certificate of conformance available upon request for customs and QA purposes.
- After-Sales: 12-month warranty on verified genuine units. Technical support available via email for integration questions.
Technical FAQ
Q: Is the IC200CPUE05-FH compatible with Proficy Machine Edition v9.x?
A: Yes. The -FH firmware revision is fully supported by PME v8.0 and later, including v9.x. Ensure your PME license includes the VersaMax Micro PLUS target type.
Q: Can this CPU communicate with a SCADA system over Modbus TCP?
A: Yes. The onboard Ethernet port supports Modbus TCP server (slave) mode natively. Configure register mapping in PME’s hardware configuration tool.
Q: What is the maximum number of I/O points with expansion modules?
A: With 4 IC200-series expansion modules, total I/O can reach approximately 64–112 points depending on module type selected.
Q: Does the unit ship with a battery installed?
A: Units are shipped with the RTC battery installed. Battery life is typically 5–7 years under normal operating conditions. Replacement battery: IC200ACC001.
Q: What is the difference between IC200CPUE05 and IC200CPUE05-FH?
A: The -FH suffix denotes the latest production firmware revision. It is backward-compatible with all IC200CPUE05 applications and is the recommended procurement choice for new installations.
Q: Can I use EGD (Ethernet Global Data) for peer-to-peer communication?
A: Yes. EGD is supported on the onboard Ethernet port and allows scheduled, deterministic data exchange between multiple GE PLCs without a SCADA intermediary.
