Analog Input Solution – GE IC695ALG608 | PACSystems RX3i
Where This Product Is Used
The GE IC695ALG608 is an 8-channel analog input module engineered for demanding industrial environments where precise signal acquisition is critical. Engineers deploy this module across a wide range of applications:
- Oil & Gas Processing Plants – Monitoring pressure transmitters, flow meters, and temperature sensors across pipeline control systems.
- Chemical & Pharmaceutical Manufacturing – Acquiring 4–20 mA signals from process instruments in batch and continuous production lines.
- Power Generation & Utilities – Integrating with SCADA systems to monitor generator output, transformer loads, and grid parameters.
- Water & Wastewater Treatment – Reading level sensors, pH probes, and flow transmitters in pump station automation.
- Automotive Assembly Lines – Capturing torque, force, and position feedback from precision tooling and robotic cells.
- Food & Beverage Processing – Monitoring temperature and pressure in CIP (Clean-In-Place) and pasteurization systems.
- Building Automation & HVAC – Integrating with BMS controllers for chiller, AHU, and energy management applications.
Technical Specifications
- Part Number: IC695ALG608
- Series: GE PACSystems RX3i
- Module Type: Analog Input
- Number of Channels: 8 (single-ended) / 4 (differential)
- Input Signal Types: Voltage (±10 V, ±5 V, 0–10 V) and Current (0–20 mA, 4–20 mA)
- Resolution: 16-bit
- Isolation: Channel-to-backplane isolated
- Scan Rate: Configurable per channel
- Backplane Compatibility: IC695CHS007, IC695CHS012, IC695CHS016
- CPU Compatibility: IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE330, IC695CPE400
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Power Consumption: Refer to GE PACSystems RX3i System Manual (GFK-2314)
- Dimensions: Standard RX3i single-slot module
- Weight: Approx. 500 g
- Certifications: CE, UL, cUL
Why Engineers Specify This Model
- High-Resolution 16-Bit Conversion – Delivers ±0.1% accuracy across the full input range, meeting the precision demands of process control loops.
- Flexible Signal Configuration – Supports both voltage and current inputs on the same module, reducing the need for separate I/O cards and simplifying panel design.
- Hot-Swap Capable – Modules can be replaced under power in RX3i backplanes, minimizing unplanned downtime in 24/7 production environments.
- Seamless PACSystems Integration – Native compatibility with Proficy Machine Edition (PME) software enables rapid configuration, diagnostics, and firmware updates.
- Channel-Level Diagnostics – Open-wire detection and over-range alarms are reported directly to the CPU, enabling predictive maintenance strategies.
- Proven Field Reliability – Widely deployed in critical infrastructure globally, with a documented MTBF exceeding 300,000 hours.
Complete System Bill of Materials
For a fully operational PACSystems RX3i analog input subsystem, the following components are typically required:
- IC695ALG608 – 8-Channel Analog Input Module (this item)
- IC695CPE305 / IC695CPE310 – PACSystems RX3i CPU Module
- IC695CHS012 – 12-Slot Universal Backplane
- IC695PSA040 – 40W AC Power Supply
- IC695ETM001 – Ethernet Interface Module (for SCADA/HMI connectivity)
- IC695ACC402 – Thermocouple/RTD Terminal Block (optional, for sensor wiring)
Contact support@konmask.com for bundle pricing on complete RX3i system builds.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed – Recognized for use in North American industrial control panels
- IEC 61131-2 – Programmable Controller Equipment standard compliance
- RoHS Compliant – Restriction of Hazardous Substances Directive
- ATEX / IECEx – Consult factory for hazardous area installation requirements
Quality Assurance & Sourcing
Konmask.com specializes in the global sourcing of industrial automation components from verified supply chains. Every IC695ALG608 unit we supply undergoes:
- Visual and dimensional inspection against OEM specifications
- Firmware version verification
- Functional power-on testing where applicable
- Anti-counterfeit screening using OEM documentation cross-reference
- Secure ESD-safe packaging with full traceability documentation
We source from authorized distributors, OEM surplus channels, and certified industrial resellers to ensure authenticity and reliability.
How to Source This Part
- Request a Quote – Email support@konmask.com with your required quantity and delivery timeline.
- Receive Availability & Pricing – Our team responds within 24 business hours with stock status, lead time, and competitive pricing.
- Place Your Order – Secure checkout via this product page or via purchase order for B2B accounts.
- Fast Global Shipping – We ship worldwide via DHL, FedEx, and UPS with full export documentation support.
- After-Sales Support – Technical assistance available post-delivery for integration and commissioning queries.
Application-Specific FAQ
Q: Can the IC695ALG608 accept HART signals?
A: No. The IC695ALG608 does not natively support HART protocol. For HART-enabled analog input, consider the GE IC695ALG728 or use a standalone HART multiplexer.
Q: Is this module compatible with the PACSystems RX7i platform?
A: No. The IC695ALG608 is designed exclusively for the RX3i backplane architecture. RX7i systems require IC697-series analog modules.
Q: Can I mix voltage and current channels on the same module?
A: Yes. Each channel is independently configurable for voltage or current input via Proficy Machine Edition software, providing maximum wiring flexibility.
Q: What is the maximum cable length for analog signal wiring?
A: GE recommends shielded twisted-pair cable up to 300 meters (1,000 ft) for 4–20 mA current loops. Voltage inputs should be kept under 30 meters to minimize noise pickup.
Q: Do you offer warranty on this module?
A: Yes. Konmask.com provides a 90-day functional warranty on all modules. Extended warranty options are available upon request.
