GE MDI12 369B1843G5002 – 12-Channel Digital Input Module | GE Multilin Protection Platform
Engineering Background: The MDI12 369B1843G5002 is a factory-original digital input expansion module engineered by GE (General Electric) for integration with the GE Multilin 369 Motor Management Relay series. Designed to extend the discrete I/O capacity of protection and control systems in heavy industrial environments, this module delivers deterministic signal acquisition with the reliability demanded by mission-critical motor protection applications.
Product Positioning: Targeted at procurement engineers and system integrators managing motor protection infrastructure in power generation, oil & gas, water treatment, and heavy manufacturing facilities. The MDI12 serves as a direct OEM replacement or capacity expansion component within existing GE Multilin 369 relay architectures, eliminating the need for third-party I/O adapters or signal conditioning hardware.
Complete Technical Specifications
- Part Number: MDI12 / 369B1843G5002
- Manufacturer: GE (General Electric) – GE Multilin Division
- Module Type: 12-Channel Digital Input Module
- Compatible Platform: GE Multilin 369 Motor Management Relay
- Input Channels: 12 discrete digital inputs
- Input Signal Type: Dry contact / wet contact (voltage-sensing)
- Operating Voltage: Per GE Multilin 369 relay system specifications
- Communication Interface: Internal relay backplane bus
- Mounting: Direct plug-in to GE Multilin 369 relay chassis
- Operating Temperature: -20°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Approvals: CE, UL (per GE Multilin 369 system certification)
- Weight: Approx. 1.0 kg
- Country of Origin: United States
- HS Code: 8537.10
Proven Application Environments
- Motor protection and management systems in power generation plants
- Pump and compressor control in oil & gas upstream/downstream facilities
- Water and wastewater treatment motor control centers (MCC)
- Heavy manufacturing conveyor and drive protection systems
- Mining and minerals processing motor management infrastructure
- Utility substation feeder protection and automation panels
Engineering Advantages
- OEM Authenticity: Factory-original GE Multilin component — no third-party substitutes or rebranded equivalents
- Plug-and-Play Integration: Direct chassis insertion into GE Multilin 369 relay with zero firmware modification required
- Expanded I/O Density: 12 independent digital input channels per module, maximizing panel real estate efficiency
- Deterministic Signal Acquisition: Hardware-level input scanning ensures consistent response times for protection-grade applications
- Industrial-Grade Durability: Rated for wide temperature range and high-humidity environments without derating
- Long-Term Availability: Konmask.com maintains verified stock of legacy GE Multilin I/O modules for MRO and capital project procurement
System Architecture & Signal Flow
The MDI12 369B1843G5002 interfaces directly with the GE Multilin 369 Motor Management Relay via the internal expansion bus. Digital input signals from field devices (auxiliary contacts, limit switches, pushbuttons, or interlock relays) are routed to the module’s 12 input terminals. The relay’s firmware polls the MDI12 at the configured scan rate, integrating discrete status data into the protection logic, event logging, and SCADA communication stack (Modbus RTU / DNP3) of the host 369 relay.
Signal flow: Field Device → MDI12 Input Terminal → Internal Bus → 369 Relay CPU → Protection Logic / HMI / SCADA
Sourcing & Quality Verification
- All units sourced from authorized GE Multilin distribution channels or verified OEM surplus inventory
- Pre-shipment inspection includes visual examination, label verification (part number, date code, revision), and connector integrity check
- Serialization and revision traceability maintained for each unit
- Anti-counterfeit verification available upon request for critical infrastructure procurement
- Certificate of Conformance (CoC) and test reports available for qualified orders
Procurement Process
- Step 1: Confirm compatibility — verify your GE Multilin 369 relay firmware version and existing I/O configuration
- Step 2: Submit RFQ via support@konmask.com or place order directly on Konmask.com
- Step 3: Receive order confirmation with lead time and shipping options (DHL Express / FedEx International Priority)
- Step 4: Shipment with commercial invoice, packing list, and CoC documentation
- Step 5: Post-delivery technical support available for installation verification
Technical FAQ
Q: Is the MDI12 369B1843G5002 compatible with GE Multilin 369 relay firmware versions prior to v5.0?
A: Compatibility depends on the specific relay firmware revision. Contact our technical team with your relay nameplate data for confirmation before ordering.
Q: Can the MDI12 be used with other GE Multilin relay families (e.g., 469, 489)?
A: No. The MDI12 369B1843G5002 is specifically designed for the GE Multilin 369 platform. Cross-platform use is not supported by GE.
Q: What is the lead time for in-stock units?
A: In-stock units typically ship within 1–3 business days. Contact us for real-time availability confirmation.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 12-month warranty against manufacturing defects on all verified OEM components.
Q: Can I request a Certificate of Conformance or test documentation?
A: Yes. CoC and available test documentation can be provided upon request for qualified procurement orders.
