Hollysys FM131-E Main Control Unit — Central Processing Module | LK Series DCS Platform
Engineering Background
The Hollysys LK Series Distributed Control System (DCS) is a flagship industrial automation platform widely deployed across petrochemical, power generation, pharmaceutical, and municipal water treatment sectors throughout China and Southeast Asia. As the central intelligence of the LK Series control network, the FM131-E Main Control Unit orchestrates real-time data acquisition, logic execution, and inter-module communication across the entire control loop.
Product Positioning
The FM131-E is engineered for mission-critical process control environments where deterministic scan cycles, high-availability redundancy, and long-term platform continuity are non-negotiable. It serves as the primary CPU module for LK Series DCS cabinets, directly interfacing with I/O modules, communication buses, and engineering workstations. Procurement engineers specifying replacement or expansion units for existing LK Series installations will find the FM131-E the authoritative OEM solution.
Complete Technical Specifications
| Manufacturer | Hollysys Automation Technologies Ltd. |
| Part Number / SKU | FM131-E |
| Module Type | Main Control Unit (CPU Module) |
| Platform | Hollysys LK Series DCS |
| Processor Architecture | 32-bit RISC embedded processor |
| Operating System | Real-time embedded OS (RTOS) |
| Scan Cycle | Configurable; typical 10–100 ms |
| Program Memory | Flash-based non-volatile storage |
| Communication Interfaces | Ethernet (100 Mbps), RS-485, proprietary LK backplane bus |
| Redundancy Support | Hot-standby CPU redundancy (1:1) |
| I/O Expansion | Via LK Series I/O modules on shared backplane |
| Power Supply | 24 V DC (supplied via backplane) |
| Power Consumption | ≤ 5 W (typical) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | −40 °C to +70 °C |
| Relative Humidity | 5% to 95% RH, non-condensing |
| Protection Rating | IP20 |
| Mounting | DIN rail / LK Series backplane slot |
| Dimensions (W × H × D) | Approx. 40 × 130 × 110 mm (module form factor) |
| Weight | 380 g |
| Certifications | CE, CCC (China Compulsory Certification) |
| Firmware Upgrade | Supported via engineering workstation (HOLLiAS MACS) |
| Configuration Tool | HOLLiAS MACS V6.x / V7.x |
Note: Specifications are based on Hollysys published documentation. Confirm exact revision compatibility with your system integrator or contact Konmask technical support.
Proven Application Environments
- Petrochemical & Refining: Continuous process control for distillation columns, reactors, and heat exchangers requiring deterministic loop execution.
- Power Generation: Boiler management systems (BMS) and turbine control where CPU redundancy and fast failover are mandatory.
- Pharmaceutical Manufacturing: GMP-compliant batch process control with full audit trail support via HOLLiAS MACS historian.
- Municipal Water & Wastewater: SCADA-integrated control of pumping stations and treatment processes with remote I/O expansion.
- Building Automation & Utilities: Central HVAC and energy management in large industrial campuses running LK Series infrastructure.
Engineering Advantages
- Hot-Standby Redundancy: Seamless 1:1 CPU switchover with zero process interruption — critical for continuous production environments.
- Deterministic Real-Time Execution: RTOS-based scan cycle ensures predictable control loop timing, eliminating jitter-induced process deviations.
- Native LK Backplane Integration: Direct plug-in compatibility with all LK Series I/O, power, and communication modules — no adapter or gateway required.
- HOLLiAS MACS Ecosystem: Full lifecycle support including online programming, diagnostics, firmware management, and historian integration.
- Long-Term OEM Availability: Hollysys maintains production continuity for LK Series modules, protecting your installed base investment over a 10+ year horizon.
- Compact Form Factor: Single-slot module design maximises cabinet density without sacrificing processing headroom.
System Architecture & Signal Flow
The FM131-E occupies the designated CPU slot on the LK Series backplane. On power-up, it initialises the backplane bus, enumerates all connected I/O modules, and establishes Ethernet communication with the HOLLiAS MACS engineering workstation and operator stations. During runtime, the module executes the downloaded control strategy at the configured scan rate, reads process values from distributed I/O modules, applies control algorithms, and writes output commands — all within a single deterministic cycle. In redundant configurations, the standby FM131-E maintains a synchronised mirror of the active CPU state, enabling bumpless transfer upon primary failure detection.
Sourcing & Quality Verification
- OEM Origin: All FM131-E units supplied by Konmask.com are sourced directly from Hollysys-authorised distribution channels or verified surplus from decommissioned OEM installations.
- Pre-Shipment Inspection: Each module undergoes visual inspection, label verification (part number, firmware revision, date code), and functional power-on check prior to dispatch.
- Authenticity Guarantee: Konmask provides a certificate of authenticity and full traceability documentation upon request.
- Packaging: ESD-safe anti-static bag, foam-lined carton, with desiccant pack for international shipments.
Procurement Process
- Confirm Compatibility: Verify your LK Series DCS cabinet revision and HOLLiAS MACS software version with your system documentation or contact our technical team.
- Request a Quote: Submit your RFQ via the product page or email support@konmask.com with quantity and required delivery date.
- Order Confirmation: Konmask issues a proforma invoice with lead time, shipping options (DHL / FedEx / sea freight), and payment terms.
- Quality Documentation: Request packing list, inspection report, and certificate of authenticity at order placement.
- Delivery & Commissioning Support: Our engineers are available for remote commissioning guidance at no additional charge for qualified orders.
Technical FAQ
Q: Is the FM131-E compatible with both HOLLiAS MACS V6 and V7?
A: The FM131-E hardware is compatible with both versions; however, firmware revision must match your MACS software version. Contact Konmask to confirm the correct firmware build for your installation.
Q: Can the FM131-E operate in a non-redundant (simplex) configuration?
A: Yes. The module functions as a standalone CPU in simplex mode. Redundancy is enabled by populating the secondary CPU slot with a second FM131-E and configuring the redundancy parameters in HOLLiAS MACS.
Q: What is the typical lead time for FM131-E?
A: In-stock units ship within 3–5 business days. For larger quantities or specific firmware revisions, lead time is 2–4 weeks. Contact us for real-time stock status.
Q: Does Konmask offer a warranty on this module?
A: Yes. Konmask provides a 12-month warranty covering manufacturing defects. Warranty claims are processed with full RMA support.
Q: Can I return a module if it is incompatible with my system?
A: Konmask accepts returns within 30 days of delivery for unused modules in original packaging. Please contact support@konmask.com to initiate a return authorisation.
