Honeywell 51153818-201 – Field Wiring Jumper Kit | TDC 3000 Distributed Control System
Engineering Background
The Honeywell TDC 3000 platform has been the backbone of process automation in refining, petrochemical, and power generation facilities for decades. Reliable field termination is critical to signal integrity across the entire control loop. The 51153818-201 Jumper Kit is an OEM-specified termination accessory designed to maintain loop continuity and simplify field wiring configurations within TDC 3000 termination assemblies.
Product Positioning
Sourced directly from Honeywell-authorized supply chains, this jumper kit is the correct replacement and spare component for engineers maintaining or expanding legacy TDC 3000 installations. It eliminates improvised field wiring, reduces commissioning time, and ensures compliance with Honeywell’s original termination architecture.
Complete Technical Specifications
- Part Number: 51153818-201
- Manufacturer: Honeywell Process Solutions
- Series / Platform: TDC 3000 Distributed Control System
- Component Type: Jumper Kit – Field Wiring Termination Accessory
- Application: Termination Assembly field wiring continuity and loop configuration
- Weight: 2,600 g (shipping weight)
- Condition: New / Refurbished (OEM-spec, factory-tested)
- Compliance: Designed to Honeywell OEM specifications for TDC 3000 architecture
- Country of Origin: USA (Honeywell Process Solutions)
Proven Application Environments
- Oil & Gas Refining – DCS field termination panels
- Petrochemical Plants – TDC 3000 I/O termination assemblies
- Power Generation – Control room loop wiring configurations
- Pulp & Paper – Process automation field wiring maintenance
- Pharmaceutical Manufacturing – Validated DCS control loop integrity
- Water Treatment – SCADA/DCS hybrid termination upgrades
Engineering Advantages
- OEM Specification Compliance: Exact fit for Honeywell TDC 3000 termination assemblies – no field modification required.
- Signal Integrity: Maintains loop continuity and eliminates improvised jumper wiring that introduces resistance variance.
- Commissioning Efficiency: Pre-configured jumper layout reduces field wiring time and documentation burden.
- Long-Term Availability: Stocked as a critical spare to support aging TDC 3000 installations with extended lifecycle requirements.
- Traceability: Each unit ships with part number verification documentation for MRO and audit compliance.
System Architecture & Signal Flow
Within the TDC 3000 architecture, field signals from transmitters and actuators are routed through termination assemblies before entering the I/O modules. The 51153818-201 Jumper Kit provides the internal wiring bridges within these assemblies, ensuring that analog and discrete signals are correctly looped or isolated per the engineering design. Proper installation of this kit is essential for maintaining the signal path integrity between field devices and the High-Performance Process Manager (HPM) or equivalent controller modules.
Sourcing & Quality Verification
- All units sourced through Honeywell-authorized distributors or verified MRO channels.
- Pre-shipment inspection includes visual check, part number verification (51153818-201), and packaging integrity review.
- Certificates of conformance and test reports available upon request for critical installations.
- Konmask.com maintains a zero-counterfeit policy – all Honeywell parts are cross-referenced against OEM documentation prior to listing.
Procurement Process
- Submit Inquiry: Contact support@konmask.com or call +0086 19859288691 with your project quantity and delivery timeline.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options.
- Order Confirmation: Purchase order accepted via email. Payment terms available for qualified accounts.
- Shipment: Ships from our warehouse with full tracking. Express air freight available for urgent requirements.
- Documentation: Packing list, commercial invoice, and CoC provided with every shipment.
Technical FAQ
Q: Is the 51153818-201 compatible with all TDC 3000 termination assemblies?
A: This kit is designed for specific TDC 3000 termination assembly configurations. Please confirm your assembly part number with our engineering team before ordering to ensure compatibility.
Q: Can this jumper kit be used in SIL-rated safety loops?
A: The 51153818-201 is a standard process control component. For SIL-rated applications, consult Honeywell’s functional safety documentation and verify with your SIS engineer.
Q: What is the lead time for bulk orders?
A: Standard stock orders ship within 3–5 business days. For bulk procurement (>10 units), contact us for dedicated lead time and pricing.
Q: Do you provide installation support?
A: We provide part-level technical documentation. For system-level commissioning support, we can refer you to certified Honeywell system integrators.
Q: Is a warranty provided?
A: All units carry a 90-day warranty against manufacturing defects. Extended warranty options available for qualified projects.
