Honeywell 51304540-200 Paddle Board | Replacement, Equivalent & Selection Guide
The Honeywell 51304540-200 is a Paddle Board module designed for use in Honeywell TDC 3000 / TotalPlant Solution (TPS) Distributed Control Systems (DCS). This page provides full technical specifications, compatible replacement options, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Part Number: 51304540-200
- Manufacturer: Honeywell Process Solutions
- Module Type: Paddle Board / Backplane Interface Card
- Compatible Platform: Honeywell TDC 3000 / TPS DCS
- Form Factor: PCB card module
- Weight: Approx. 240 g
- Condition Available: New, Refurbished, Tested Surplus
- Warranty: 12-month Konmask quality warranty
- RoHS Compliance: Per original OEM specification
Note: Full datasheet available upon request. Contact support@konmask.com for detailed electrical and mechanical specifications.
Compatible Replacement & Equivalent Models
When the 51304540-200 is unavailable or end-of-life, the following models may serve as functional equivalents or drop-in replacements depending on your system revision. Always verify firmware and slot compatibility before substitution:
- 51304540-100 – Earlier revision of the same paddle board series; verify revision compatibility with your cabinet
- 51304540-150 – Intermediate revision; functionally similar, check connector pinout
- 51304540-250 – Later revision with potential enhanced signal integrity; confirm backward compatibility
- 51401288-100 / -200 – Alternative paddle board variants used in adjacent TPS subsystems
- 51309276-175 / -275 – Related interface boards for High-Performance Process Manager (HPPM) environments
Important: Konmask engineers can assist with cross-reference validation. Contact us before ordering a substitute part for mission-critical applications.
Why Choose the Original Model
- OEM-Certified Design: Engineered specifically for Honeywell TDC 3000 / TPS architecture — no firmware conflicts or signal mismatch risks
- Proven Field Reliability: Deployed in refineries, chemical plants, and power generation facilities worldwide
- Exact Fit: Mechanical and electrical form factor matches original cabinet slot specifications without modification
- Regulatory Compliance: Supports SIL-rated and safety-instrumented system (SIS) environments when used per OEM guidelines
- Long Service Life: Designed for continuous 24/7 industrial operation in harsh process environments
Typical Applications
- Petroleum refining and upstream oil & gas DCS control cabinets
- Chemical and petrochemical plant process control systems
- Power generation (coal, gas, nuclear) plant automation
- Pulp & paper and water treatment facility control systems
- Pharmaceutical manufacturing process automation
- Spare parts inventory for TDC 3000 / TPS system maintenance and lifecycle extension
System Compatibility
- Primary Platform: Honeywell TDC 3000 (Total Distributed Control)
- Extended Platform: Honeywell TotalPlant Solution (TPS)
- Subsystem: Process Manager (PM), High-Performance Process Manager (HPPM), Advanced Process Manager (APM)
- Cabinet Types: Standard and Enhanced Universal Control Network (UCN) cabinets
- Not Compatible With: Honeywell Experion PKS (C300 series) — different hardware architecture
If you are migrating from TDC 3000 to Experion PKS, Konmask can advise on migration-compatible interface solutions.
Selection Guide
Use the following criteria to confirm the correct part for your application:
- Step 1 – Identify your DCS platform: Confirm TDC 3000 or TPS system generation and cabinet revision
- Step 2 – Check the revision suffix: The -200 suffix denotes a specific hardware revision; match to your existing installed base
- Step 3 – Verify slot position: Confirm the paddle board slot number and backplane connector type in your cabinet layout drawing
- Step 4 – Assess condition requirement: Choose New OEM stock for greenfield/critical applications; Tested Surplus for budget-sensitive MRO replacements
- Step 5 – Confirm lead time: Contact Konmask for real-time stock availability and expedited shipping options
Quality Assurance & Sourcing
- Source: Authorized surplus channels, OEM-certified distributors, and factory-tested returns
- Testing: All units undergo functional bench testing and visual inspection prior to shipment
- Packaging: Anti-static ESD packaging with moisture barrier; original OEM packaging where available
- Documentation: Certificate of conformance and test report available upon request
- Warranty: 12-month Konmask warranty covering manufacturing defects and functional failure
- Traceability: Full supply chain traceability records maintained for each unit
How to Order
- Online: Add to cart directly on this page and proceed to checkout
- Email RFQ: Send your part number, quantity, and required condition to support@konmask.com
- Phone / WhatsApp: +0086 19859288691 (Monday–Saturday, 09:00–18:00 CST)
- Bulk / Project Orders: Request a formal quotation for volume pricing and scheduled delivery
- Lead Time: In-stock units ship within 1–3 business days; sourced units typically 5–15 business days
Replacement & Compatibility FAQ
Q: Can the 51304540-100 replace the 51304540-200?
A: In many cases yes, but the -200 revision may include hardware improvements. Verify with your system’s engineering documentation or contact Konmask for a compatibility check.
Q: Is this paddle board compatible with Experion PKS?
A: No. The 51304540-200 is designed for TDC 3000 / TPS architecture. Experion PKS uses a different hardware platform (C300 series controllers).
Q: Do you offer refurbished units?
A: Yes. Konmask offers new, refurbished, and tested surplus units. All refurbished units are fully tested and carry a 12-month warranty.
Q: Can I get a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com with your part number and application details and we will provide available technical documentation.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. If sourcing is required, lead time is typically 5–15 business days depending on availability.
Q: Do you ship internationally?
A: Yes. Konmask ships worldwide via DHL, FedEx, and UPS with full export documentation support.
