Process Control Solution – Honeywell 51305341-100 | TDC 3000 / TotalPlant Series
Where This Product Is Used
The Honeywell 51305341-100 Analog Input Module is a field-proven component deployed across demanding process industries where precise signal acquisition is non-negotiable. Typical installation environments include:
- Oil & Gas Refineries – Monitoring pressure, temperature, and flow transmitters in upstream/downstream units
- Chemical & Petrochemical Plants – Continuous process variable acquisition in reactor and distillation control loops
- Power Generation Facilities – Turbine and boiler instrumentation signal conditioning within DCS architectures
- Pulp & Paper Mills – Multi-loop analog signal management for digester and recovery boiler control
- Pharmaceutical Manufacturing – GMP-compliant process monitoring in validated batch control systems
- Water & Wastewater Treatment – SCADA-integrated analog acquisition for pump stations and treatment processes
Technical Specifications
- Part Number: 51305341-100
- Manufacturer: Honeywell Process Solutions
- Series: TDC 3000 / TotalPlant Solution (TPS)
- Module Type: Analog Input Module (AIM)
- Signal Types: 4–20 mA, 1–5 V DC (field-configurable)
- Channels: Multi-channel analog input
- Communication: Honeywell UCN / LCN backplane bus
- Isolation: Channel-to-channel and channel-to-bus isolation
- Diagnostics: Built-in self-test and fault reporting
- Weight: 1,600 g (approx.)
- Compliance: CE, UL listed (verify with current datasheet)
Why Engineers Specify This Model
- Drop-in Replacement: Direct form-fit-function replacement for existing TDC 3000 / TPS installations — no firmware changes required
- High Signal Integrity: Precision A/D conversion with hardware filtering minimizes noise in electrically harsh plant environments
- Proven Reliability: Designed to Honeywell’s industrial-grade MTBF standards for continuous 24/7 process operation
- Simplified Maintenance: Hot-swap capable within TDC 3000 chassis; reduces planned downtime during module replacement
- Long Service Life: Compatible with legacy TDC 3000 systems still operating in brownfield plants worldwide
Complete System Bill of Materials
For a fully operational TDC 3000 analog input subsystem, engineers typically specify the following alongside the 51305341-100:
- Honeywell TDC 3000 / TPS Chassis / Card Cage
- Honeywell UCN / LCN Network Interface Module
- Honeywell Field Termination Assembly (FTA) – compatible model per channel count
- Shielded twisted-pair field wiring (per ISA-5.1 standard)
- Honeywell Universal Control Network (UCN) coaxial cable and terminators
- Redundant power supply module (recommended for critical loops)
Compliance & Industry Standards
- Designed and tested to IEC 61511 functional safety guidelines (SIL-capable architecture)
- Compatible with ISA-5.1 instrumentation signal standards
- Supports NAMUR NE 43 fault-state signal conventions (4–20 mA)
- CE marking for European market installations
- RoHS compliance status: verify with current Honeywell product documentation
Quality Assurance & Sourcing
Every Honeywell 51305341-100 unit sourced through Konmask.com undergoes a structured quality process:
- Visual Inspection: Board-level inspection for physical damage, corrosion, and component integrity
- Functional Verification: Power-on test and communication bus check prior to shipment
- Traceability: Serial number and revision level documented per order
- Packaging: ESD-safe anti-static packaging with moisture barrier for international transit
- Warranty: 90-day replacement warranty against DOA or functional defects
How to Source This Part
Konmask.com maintains stock of industrial automation components including the Honeywell 51305341-100. To place an order or request a quote:
- Online: Add to cart directly from this page
- Email RFQ: support@konmask.com — include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; ex-stock lead time quoted on request
- Export: We ship globally with full commercial invoice and packing list documentation
Application-Specific FAQ
Q: Is the 51305341-100 compatible with both TDC 3000 and TotalPlant Solution (TPS) systems?
A: Yes. The module is designed for the Honeywell TDC 3000 / TPS platform and is backward-compatible within the same chassis family. Always verify revision level against your system’s firmware version.
Q: Can this module accept HART-enabled field devices?
A: The 51305341-100 accepts standard 4–20 mA signals. HART pass-through capability depends on the specific FTA and system configuration — consult your Honeywell system documentation or contact us for clarification.
Q: What is the lead time for bulk orders (>5 units)?
A: Bulk pricing and lead times are available upon request. Email support@konmask.com with your BOM quantity and project timeline.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC documenting part number, serial number, and inspection results is available upon request for all orders.
Q: Is this a new, refurbished, or surplus unit?
A: Stock condition (new surplus, refurbished, or used-tested) is specified at time of quotation. Contact us to confirm current stock condition before ordering.
