Honeywell 8C-PAIMA1 / 8C-TAIMA1 Analog Input Module – Experion PKS C300 Series
When a critical analog input module fails on a refinery distillation column or a power plant boiler control loop, the consequences are immediate: process blindness, unplanned shutdowns, and potentially catastrophic safety incidents. The Honeywell 8C-PAIMA1 and 8C-TAIMA1 are not interchangeable commodity cards — they are the precision sensing backbone of the Experion PKS C300 distributed control system, purpose-engineered to deliver uninterrupted, high-fidelity signal acquisition in the world’s most demanding industrial environments.
Within the Experion PKS C300 I/O architecture, the 8C-PAIMA1 serves as the standard 8-channel analog input module, while the 8C-TAIMA1 is its CHARM-compatible counterpart designed for Series C I/O termination assemblies. Together, they represent Honeywell’s commitment to modular, scalable DCS design — a platform trusted by over 10,000 installations across oil & gas, refining, chemicals, power generation, and pulp & paper industries worldwide.
Technical Specifications
- Part Numbers: 8C-PAIMA1 / 8C-TAIMA1
- Series: Honeywell Experion PKS C300
- Module Type: Analog Input (AI)
- Channels: 8 channels per module
- Signal Types: 4–20 mA, HART (Highway Addressable Remote Transducer)
- HART Support: Yes — per-channel HART pass-through for smart field device diagnostics
- Resolution: 16-bit A/D conversion
- Isolation: Channel-to-channel and channel-to-bus isolation
- Power Consumption: Per Honeywell Experion PKS C300 system specifications
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Mounting: C300 I/O Link chassis / Series C termination assembly
- Certifications: CE, UL, FM (refer to Honeywell product datasheet for full listing)
- Weight: Approx. 1,300 g
Note: All specifications are sourced from Honeywell’s official product documentation. Konmask.com does not fabricate or alter manufacturer specifications.
Key Features & Benefits
- 8-Channel Density: Maximizes I/O density per chassis slot, reducing hardware footprint and cabinet space.
- HART Integration: Native HART support enables remote diagnostics, calibration, and smart device management without additional hardware.
- High-Resolution A/D: 16-bit conversion ensures precise measurement accuracy for critical process variables such as flow, pressure, temperature, and level.
- Hot-Swap Capability: Supports online replacement without process interruption, minimizing maintenance downtime.
- Redundancy Ready: Compatible with Honeywell’s C300 redundancy architecture for fault-tolerant control loops.
- Seamless Experion Integration: Plug-and-play within the Experion PKS environment — no custom configuration required for standard deployments.
- Long Product Lifecycle: Honeywell’s commitment to long-term parts availability makes these modules a reliable investment for brownfield and greenfield projects alike.
Industry & Equipment Applications
- Oil & Gas: Upstream wellhead monitoring, midstream pipeline SCADA, downstream refinery process control
- Petrochemicals & Chemicals: Reactor temperature/pressure loop control, distillation column management
- Power Generation: Boiler drum level, turbine inlet pressure, feedwater flow measurement
- Pulp & Paper: Digester pressure control, bleach plant flow monitoring
- Pharmaceuticals: Batch process monitoring under FDA 21 CFR Part 11 environments
- Water & Wastewater: Pump station flow and pressure acquisition
System Integration & Compatible Parts
The 8C-PAIMA1 and 8C-TAIMA1 are designed to operate within the Honeywell Experion PKS C300 ecosystem. Compatible and commonly paired components include:
- C300 Controller Module (CC-PCNT01, CC-TCNT01)
- Series C I/O Link Extender (8C-PIOXA1, 8C-TIOXA1)
- Analog Output Modules (8C-PAOMA1, 8C-TAOMA1)
- Digital Input/Output Modules (8C-PDIDA1, 8C-PDODA1)
- C300 Power Supply Modules (CC-PWR001, CC-PWR002)
- Termination Assemblies for Series C I/O
Contact Konmask.com to verify compatibility with your specific Experion PKS revision and firmware version.
Our Quality Assurance Process
Every Honeywell module shipped from Konmask.com undergoes a rigorous multi-stage inspection process:
- Visual Inspection: Board-level examination for physical damage, corrosion, or component anomalies
- Authenticity Verification: Cross-referenced against Honeywell’s authorized part numbering and labeling standards
- Functional Pre-Check: Where applicable, modules are bench-tested prior to shipment
- Secure Packaging: ESD-safe anti-static packaging with moisture barrier protection for international transit
- Documentation: Certificate of conformance and traceability documentation available upon request
How to Order
- Submit your inquiry via the Contact / RFQ form on this page
- Provide your required quantity, delivery timeline, and destination country
- Our technical team will confirm availability, lead time, and provide a formal quotation within 24 business hours
- Upon PO confirmation, we arrange export documentation and international shipping
We accept T/T (bank transfer), L/C, and other B2B payment terms. Minimum order quantity: 1 unit.
Why Choose Konmask.com?
- Industrial Automation Specialists: Focused exclusively on DCS, PLC, and industrial control components — not a general electronics marketplace
- Global Export Experience: Serving clients in 40+ countries with compliant export documentation and reliable logistics partners
- Technical Pre-Sales Support: Our engineers can assist with compatibility verification, system architecture review, and spare parts planning
- Competitive Lead Times: Extensive supplier network enables fast sourcing for both common and obsolete Honeywell parts
- Transparent Communication: No hidden fees. Clear quotations, honest lead times, and responsive after-sales support
Frequently Asked Questions
Q: What is the difference between 8C-PAIMA1 and 8C-TAIMA1?
A: The 8C-PAIMA1 is the standard analog input module for the Experion PKS C300 I/O chassis, while the 8C-TAIMA1 is designed for use with Series C termination assemblies (CHARM-style I/O). Both provide 8-channel analog input with HART support but differ in their physical termination interface.
Q: Is this module compatible with Experion PKS R500 and later?
A: The 8C-PAIMA1 / 8C-TAIMA1 are part of the C300 I/O family and are generally compatible across multiple Experion PKS releases. We recommend confirming your specific firmware and hardware revision with our technical team before ordering.
Q: Can you supply both new and refurbished units?
A: Yes. Konmask.com can source both factory-new and professionally refurbished units depending on availability and your budget requirements. All refurbished units are tested and certified before shipment.
Q: What is the typical lead time?
A: Lead time varies by stock availability. In-stock items typically ship within 3–5 business days. For sourced items, lead time is 2–4 weeks. Contact us for a real-time availability check.
Q: Do you provide export documentation for customs clearance?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and other documents required for international customs clearance upon request.
