Honeywell CC-PCNT01 / CC-PDIL01 / CC-PAON01 Controller Module | Replacement, Equivalent & Selection Guide
The Honeywell CC-PCNT01, CC-PDIL01, and CC-PAON01 are core controller and I/O modules within the Experion PKS (Process Knowledge System) DCS platform. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing these modules or evaluating equivalent alternatives.
Technical Specifications
| Parameter | CC-PCNT01 | CC-PDIL01 | CC-PAON01 |
|---|---|---|---|
| Type | Process Controller Node | Digital Input Module | Analog Output Module |
| Platform | Experion PKS / C300 | Experion PKS / C300 | Experion PKS / C300 |
| Communication | FTE (Fault Tolerant Ethernet) | FOUNDATION Fieldbus / HART | FOUNDATION Fieldbus / HART |
| Power Supply | 24 VDC | 24 VDC | 24 VDC |
| Operating Temp. | 0 – 60 °C | 0 – 60 °C | 0 – 60 °C |
| Mounting | DIN Rail / Chassis | DIN Rail / Chassis | DIN Rail / Chassis |
| Certifications | CE, UL, FM | CE, UL, FM | CE, UL, FM |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents. Always verify firmware compatibility and I/O channel counts before substitution.
| Replacement Model | Brand | Compatibility Notes |
|---|---|---|
| CC-PCNT02 | Honeywell | Upgraded revision; direct drop-in for most C300 applications |
| CC-PDIL02 | Honeywell | Enhanced DI module; same form factor |
| CC-PAON02 | Honeywell | Revised AO module; backward compatible |
| 51304485-150 | Honeywell | Legacy equivalent for CC-PCNT01 in older Experion R200 systems |
| PM803F | ABB | Cross-brand alternative for process controller function; requires engineering re-mapping |
| 6ES7 315-2EH14-0AB0 | Siemens S7-300 | Cross-platform; significant re-engineering required |
Note: Cross-brand replacements require full I/O re-mapping, loop re-configuration, and FAT/SAT re-testing. Consult your system integrator before proceeding.
Why Choose the Original Model
- Native Experion PKS integration – zero re-engineering; plug-and-play within existing C300 architecture
- Firmware continuity – seamless upgrade path from R200 through R501 without logic changes
- Redundancy support – built-in controller redundancy (1:1) for high-availability processes
- Honeywell lifecycle support – long-term spare parts availability and OEM technical support
- Certified for hazardous areas – FM/ATEX approvals available for relevant variants
Typical Applications
- Oil & gas upstream / downstream process control
- Petrochemical and refinery DCS migration and expansion
- Power generation plant automation
- Pharmaceutical batch process control (FDA 21 CFR Part 11 environments)
- Pulp & paper and water treatment facilities
- Chemical plant safety instrumented systems (SIS) integration
System Compatibility
- Honeywell Experion PKS R200 / R300 / R400 / R501 and above
- C300 Controller chassis and IOLINK architecture
- FTE (Fault Tolerant Ethernet) network topology
- Honeywell Safety Manager (via gateway configuration)
- FOUNDATION Fieldbus H1 and HART 5/6/7 field devices
Selection Guide
Use the decision matrix below to identify the correct module for your application:
| Requirement | Recommended Model |
|---|---|
| Primary process controller node (new installation) | CC-PCNT01 or CC-PCNT02 |
| Digital input expansion (24 VDC, 32-ch) | CC-PDIL01 or CC-PDIL02 |
| Analog output (4–20 mA, 8-ch HART) | CC-PAON01 or CC-PAON02 |
| Redundant controller pair | 2× CC-PCNT01 + redundancy cable kit |
| Legacy Experion R200 retrofit | CC-PCNT01 (confirm firmware R200 compatibility) |
| Budget-constrained replacement | Refurbished CC-PCNT01 (tested, with warranty) |
Quality Assurance & Sourcing
- All modules supplied by Konmask.com are sourced from authorized distributors or verified surplus channels
- Each unit undergoes functional power-on testing and visual inspection prior to shipment
- Original manufacturer packaging preserved where available
- Certificate of conformance (CoC) available upon request
- 12-month warranty on all stocked units; extended warranty available
- Anti-counterfeit verification: serial number cross-check with Honeywell authorized database
How to Order
- Confirm your Experion PKS revision (R200 / R300 / R400 / R501)
- Verify required module: CC-PCNT01 (controller), CC-PDIL01 (DI), or CC-PAON01 (AO)
- Specify quantity and preferred condition: New OEM / Refurbished / Surplus
- Contact us via email or phone for a formal quotation with lead time
- Submit PO — we support NET30 terms for qualified accounts
📧 [email protected] | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can CC-PCNT01 replace CC-PCNT02 directly?
A: In most cases yes, but verify firmware version compatibility with your Experion PKS revision. R400+ systems may require CC-PCNT02.
Q: Is CC-PDIL01 compatible with HART 7 devices?
A: CC-PDIL01 supports HART 5/6. For HART 7, upgrade to CC-PDIL02.
Q: Can I use a Siemens or ABB module as a drop-in replacement?
A: No. Cross-brand replacements require full system re-engineering. We recommend staying within the Honeywell Experion ecosystem for minimal downtime.
Q: Do you supply refurbished units with warranty?
A: Yes. All refurbished units carry a 12-month warranty and include a functional test report.
Q: What is the lead time for new OEM units?
A: Typically 2–8 weeks for new OEM. Surplus/refurbished units ship within 3–5 business days.
