Honeywell 8C-PDODAI – Digital Output Module | Experion PKS / TDC 3000 Platform
In process-critical environments where a single missed output signal can halt an entire production line, engineers specify hardware that has been proven across decades of continuous operation. The Honeywell 8C-PDODAI is a high-density digital output module engineered for the Experion PKS and TDC 3000 Distributed Control System platforms — Honeywell’s flagship process automation architectures deployed in refineries, chemical plants, power generation facilities, and pharmaceutical manufacturing worldwide.
At Konmask.com, we source, inspect, and supply the 8C-PDODAI to procurement engineers who require verified, traceable components with fast lead times and reliable technical support.
Complete Technical Specifications
- Part Number: 8C-PDODAI
- Manufacturer: Honeywell Process Solutions
- Module Type: Digital Output (DO) Module
- Platform Compatibility: Experion PKS, TDC 3000, PlantScape
- Series: C300 / PMIO I/O Subsystem
- Output Channels: 8 channels (isolated digital outputs)
- Output Type: Discrete / Digital (DO)
- Signal Isolation: Channel-to-channel and channel-to-bus isolation
- Output Voltage Range: 24 VDC nominal (field-side)
- Load Current: Per channel rated current (refer to Honeywell PM I/O datasheet)
- Communication Bus: Honeywell proprietary I/O bus (FTE / C300 backplane)
- Mounting: DIN-rail / I/O chassis card slot
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% RH, non-condensing
- Weight: Approx. 2.0 kg (module + termination assembly)
- Country of Origin: United States
- Firmware: Compatible with Experion PKS R400 and above
Proven Application Environments
- Oil & Gas Refining: Valve actuator control, pump start/stop sequencing, emergency shutdown (ESD) output commands in FCCU and CDU units
- Chemical & Petrochemical: Reactor interlock outputs, agitator control, dosing pump enable signals in batch and continuous processes
- Power Generation: Turbine auxiliary control, boiler burner management system (BMS) output signals, switchgear control
- Pharmaceutical Manufacturing: CIP/SIP valve control, clean-room HVAC damper actuation, FDA 21 CFR Part 11 compliant DCS environments
- Pulp & Paper: Conveyor drive enable, press section control, steam valve sequencing
- Water & Wastewater Treatment: Pump station control, dosing system outputs, SCADA-integrated DCS output nodes
Engineering Advantages
- Hot-Swap Capable: Supports online replacement without process shutdown, minimizing maintenance windows in 24/7 operations
- High Channel Density: 8 isolated DO channels per module reduces chassis slot consumption and wiring complexity
- Full Galvanic Isolation: Protects the DCS backplane from field-side voltage transients and ground loops
- Seamless Experion Integration: Native recognition by Experion PKS Control Builder — no custom configuration drivers required
- Diagnostic Transparency: Per-channel fault detection reported to Experion operator station in real time
- Long Product Lifecycle: Honeywell’s extended support commitment for TDC 3000 and Experion PKS ensures long-term spare parts availability
System Architecture & Signal Flow
The 8C-PDODAI slots into the Honeywell PMIO I/O chassis and communicates with the C300 Controller or equivalent via the Fault-Tolerant Ethernet (FTE) backplane bus. Each of the 8 output channels drives a field device (solenoid valve, relay coil, motor starter, indicator lamp) through a dedicated termination assembly. The module’s onboard diagnostics continuously monitor output driver health and report status to the Experion PKS server, enabling predictive maintenance scheduling without process interruption.
Signal path: Experion PKS Server → C300 Controller → FTE Backplane → 8C-PDODAI → Termination Assembly → Field Device
Sourcing & Quality Verification
- All 8C-PDODAI units are sourced from authorized distributors or decommissioned plant inventories with documented maintenance history
- Each module undergoes visual inspection, firmware version verification, and functional bench testing prior to shipment
- Serialized traceability records available upon request for regulated industries (pharma, nuclear, defense)
- Packaging: anti-static ESD bag + foam-lined carton, compliant with IEC 61340-5-1
- Warranty: 12-month replacement warranty against manufacturing defects
Procurement Process
- Submit RFQ: Contact support@konmask.com with your required quantity and delivery timeline
- Receive Quote: Pricing and lead time confirmed within 24 business hours
- Order Confirmation: Purchase order accepted via email; proforma invoice issued
- Inspection & Dispatch: Module tested, serialized, and shipped via DHL / FedEx with full tracking
- After-Sales Support: Technical assistance available for installation and Experion PKS configuration
Technical FAQ
Q: Is the 8C-PDODAI compatible with Experion PKS R500 and later releases?
A: Yes. The module is backward-compatible with Experion PKS R400 through current releases. Confirm firmware revision with your Honeywell system integrator for R500+ deployments.
Q: Can this module replace an older TDC 3000 digital output card?
A: The 8C-PDODAI is designed for the PMIO chassis used in Experion PKS migrations from TDC 3000. Consult Honeywell’s migration guide (document EP-DS-8C-PMIO) for slot-for-slot compatibility mapping.
Q: What termination assembly is required?
A: The 8C-PDODAI pairs with Honeywell’s standard PMIO termination assemblies. Contact Konmask.com to source the matching TA as a bundle.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC and inspection report are available for all units upon request at time of order.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 5 units or more.
