DCS Accumulation & Data Logging Solution — Honeywell 8C-TDILA1 | TDC 3000 Series
Where This Product Is Used
The Honeywell 8C-TDILA1 (P/N 51307141-175) Accumulation Module is a core data-acquisition and totalization component deployed across high-reliability industrial environments. Typical application sites include:
- Oil & Gas Refineries — flow totalization for custody transfer and mass balance calculations across pipeline segments.
- Chemical & Petrochemical Plants — batch accumulation tracking for reactor feed, solvent consumption, and yield reporting.
- Power Generation Facilities — steam and fuel consumption logging integrated with TDC 3000 supervisory control loops.
- Pulp & Paper Mills — continuous process variable accumulation for production reporting and regulatory compliance.
- Pharmaceutical Manufacturing — validated data accumulation for FDA 21 CFR Part 11 audit-trail requirements.
- Water & Wastewater Treatment — flow and dosing accumulation for environmental discharge monitoring.
Technical Specifications
| Manufacturer | Honeywell Process Solutions |
| Part Number | 8C-TDILA1 |
| Reference Number | 51307141-175 |
| Series / Platform | TDC 3000 / TotalPlant Solution (TPS) |
| Module Type | Accumulation Module (Data Logging & Totalization) |
| Form Factor | Card / Plug-in Module |
| Weight | 360 g (approx.) |
| Origin | USA |
| Condition | New / Refurbished / Tested (specify on inquiry) |
| Warranty | 12 months from shipment date |
Why Engineers Specify This Model
- Seamless TDC 3000 Integration — designed natively for Honeywell’s TotalPlant Solution architecture; no gateway or protocol conversion required.
- High-Precision Totalization — accumulates process variables with minimal drift, critical for custody-transfer and mass-balance accuracy.
- Proven Long-Term Reliability — widely deployed in brownfield DCS installations with 20+ year operational track records.
- Drop-In Replacement — direct form-fit-function substitute for aging modules; minimizes downtime during planned maintenance windows.
- Backward Compatibility — compatible with existing TDC 3000 backplane wiring and configuration databases, reducing re-engineering costs.
Complete System Bill of Materials
For a fully operational TDC 3000 accumulation subsystem, engineers typically specify the following alongside the 8C-TDILA1:
- Honeywell TDC 3000 Universal Control Network (UCN) Interface Card
- Honeywell 51304485-100 / 51304485-150 Power Supply Module
- Honeywell 51401642-150 Local Control Unit (LCU) Chassis
- Honeywell 51309276-175 Data Hiway Interface Module
- Appropriate field termination assemblies (FTAs) per I/O type
- Shielded twisted-pair cabling per Honeywell PM12-200 specification
Contact Konmask.com for complete BOM sourcing and cross-reference support.
Compliance & Industry Standards
- Designed and tested to IEC 61511 functional safety guidelines for process industry SIS applications.
- Compatible with ISA-5.1 instrumentation symbology and loop documentation standards.
- Supports FDA 21 CFR Part 11 audit-trail data integrity requirements when integrated with Honeywell PHD historian.
- RoHS-compliant manufacturing (verify specific revision with Honeywell documentation).
- CE marking applicable for EU installations (confirm with Honeywell regional compliance documentation).
Quality Assurance & Sourcing
Every Honeywell 8C-TDILA1 unit shipped from Konmask.com undergoes the following quality process:
- Visual Inspection — PCB, connectors, and labeling checked against OEM reference standards.
- Functional Power-On Test — module energized and verified for correct initialization and communication handshake.
- ESD-Safe Packaging — shipped in anti-static bags with foam cushioning inside double-wall corrugated cartons.
- Traceable Documentation — each unit ships with a test report and serialized inspection record.
- Authorized & Surplus Channels — sourced from authorized distributors, OEM surplus, and verified industrial decommissions only.
How to Source This Part
- Add to Cart — click the purchase button above for immediate checkout.
- Request a Quote — email support@konmask.com for volume pricing, lead time confirmation, or alternate part revisions.
- Phone / WhatsApp — reach our engineering sales team at +0086 19859288691 for urgent requirements.
- Expedited Shipping — DHL Express, FedEx International Priority, and UPS Worldwide available; export documentation provided for all international shipments.
Application-Specific FAQ
Q: Is the 8C-TDILA1 compatible with Honeywell Experion PKS?
A: The 8C-TDILA1 is a TDC 3000 / TPS native module. Migration to Experion PKS typically requires Honeywell’s C300 controller platform. Contact us for migration pathway guidance.
Q: What is the difference between 51307141-175 and other 51307141-xxx revisions?
A: The -175 suffix denotes a specific firmware and hardware revision. Always verify compatibility with your existing backplane revision before ordering. Our team can assist with cross-referencing.
Q: Can this module be used in a Safety Instrumented System (SIS)?
A: The 8C-TDILA1 is a standard DCS module, not a certified SIL-rated safety module. For SIS applications, Honeywell’s Safety Manager platform should be specified.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock lead times vary from 2–8 weeks depending on sourcing. Contact us for real-time availability.
Q: Do you provide installation and commissioning support?
A: Yes. Konmask.com offers remote technical support for module installation, configuration, and loop checkout. Contact support@konmask.com to arrange a session.
