Honeywell 900A16-0106 High Level Analog Input Module | Replacement, Equivalent & Selection Guide
The Honeywell 900A16-0106 is a High Level Analog Input Module designed for the HC900 Hybrid Controller platform. It provides 16 channels of high-level analog signal acquisition, supporting 4–20 mA and 0–10 V DC inputs, and is widely deployed in process control, energy management, and industrial automation systems. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Part Number: 900A16-0106
- Brand: Honeywell Process Solutions
- Series: HC900 Hybrid Controller
- Module Type: High Level Analog Input
- Number of Channels: 16
- Input Signal Types: 4–20 mA, 0–10 V DC, 0–5 V DC
- Resolution: 12-bit (typical)
- Isolation: Channel-to-bus isolated
- Power Consumption: Supplied via HC900 backplane
- Operating Temperature: 0°C to 60°C
- Mounting: HC900 I/O rack slot
- Communication: HC900 internal backplane bus
- Weight: Approx. 3.9 kg (packaged)
- Compliance: CE, UL listed
Compatible Replacement & Equivalent Models
If the 900A16-0106 is unavailable or you are evaluating alternatives, the following models offer compatible or equivalent functionality:
- Honeywell 900A16-0101 – Earlier revision of the same 16-ch high-level AI module; verify firmware compatibility
- Honeywell 900A08-0106 – 8-channel high-level analog input; use when fewer channels are required
- Honeywell 900A32-0106 – 32-channel variant for higher-density applications
- Honeywell 900ADC-0106 – Analog input with DC signal conditioning; confirm signal type match
- Third-party equivalents: Consult Konmask engineering team for validated cross-reference options from Emerson, ABB, or Siemens platforms
Note: Always verify hardware revision, firmware version, and rack slot compatibility before substitution.
Why Choose the Original Model
- Native HC900 Integration: Plug-and-play with HC900 controller racks — no additional configuration adapters required
- Proven Field Reliability: Widely deployed in refining, chemical, and utilities sectors with documented MTBF performance
- Honeywell Firmware Support: Fully supported by HC900 Designer software for diagnostics, calibration, and loop tuning
- Regulatory Compliance: CE and UL certifications simplify site acceptance testing and audits
- Long-term Availability: Konmask maintains stock of both new and refurbished units to support MRO and capital projects
Typical Applications
- Process temperature and pressure monitoring via 4–20 mA transmitters
- Flow measurement integration in oil & gas and water treatment plants
- Boiler and HVAC control loops in energy management systems
- Batch process control in pharmaceutical and food & beverage industries
- Multi-zone analog data acquisition in building automation
System Compatibility
- Controller Platform: Honeywell HC900 Hybrid Controller (all rack sizes)
- Software: HC900 Designer v4.x and above
- Rack Compatibility: HC900 4-slot, 8-slot, and 12-slot I/O racks
- Bus Interface: HC900 proprietary backplane — not compatible with Experion PKS or PlantScape racks without gateway
- Power Supply: Requires HC900 rack power supply (900P01-0001 or equivalent)
Selection Guide
Use the following criteria to confirm the 900A16-0106 is the right module for your application:
- Channel count needed: 9–16 channels → 900A16-0106 ✓ | ≤8 channels → consider 900A08-0106 | ≥17 channels → consider 900A32-0106
- Signal type: High-level (4–20 mA / 0–10 V) → 900A16-0106 ✓ | Thermocouple/RTD → select 900T16 or 900R08 series
- Revision suffix -0106: Indicates current production revision with enhanced EMI filtering — preferred for new installations
- Slot availability: Confirm available I/O slots in your HC900 rack before ordering
- Not sure? Contact Konmask at support@konmask.com with your HC900 project file or I/O list for a free selection review
Quality Assurance & Sourcing
- Source: Authorized distribution channels and verified surplus inventory
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check before shipment
- Condition options: New (factory sealed), Refurbished (tested to OEM spec), and As-Is (for parts/repair) — specify at time of inquiry
- Warranty: 12-month warranty on new units; 90-day warranty on refurbished units
- Traceability: Serial number and lot documentation available upon request for regulated industries
How to Order
- Confirm part number: 900A16-0106
- Specify quantity and required condition (New / Refurbished)
- Submit inquiry via support@konmask.com or add to cart directly
- Receive quotation with lead time and shipping options within 24 business hours
- Payment via T/T, PayPal, or credit card; export documentation available for international orders
Replacement & Compatibility FAQ
Q: Can the 900A16-0106 replace the 900A16-0101?
A: In most cases yes, as the -0106 is a later revision. However, verify HC900 Designer firmware compatibility and update if necessary before swapping in a live system.
Q: Is this module compatible with Honeywell Experion PKS?
A: No. The 900A16-0106 is designed exclusively for the HC900 backplane. Experion PKS uses a different I/O architecture (Series C or LEAP modules).
Q: Can I use a third-party analog input module as a drop-in replacement?
A: Not directly. Third-party modules require a gateway or protocol converter. Contact Konmask for validated integration solutions.
Q: What is the lead time for the 900A16-0106?
A: In-stock units ship within 1–3 business days. Out-of-stock units typically have a 2–6 week lead time depending on sourcing channel.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC and inspection reports are available upon request for new and refurbished units.
