Honeywell CC-PCF901 (51405047-175) – Power Conditioner Filter Module | Experion PKS C300 DCS Platform
Engineering Background
The Honeywell CC-PCF901 (part number 51405047-175) is a dedicated power conditioner and filter module engineered for the Experion PKS C300 Distributed Control System platform. Designed to operate within Honeywell’s Series C I/O architecture, this module ensures clean, regulated DC power delivery to field I/O modules and controller assemblies — a critical requirement in high-noise industrial environments where power quality directly impacts process reliability and signal integrity.
Product Positioning
The CC-PCF901 serves as the power backbone for C300 I/O enclosures, filtering transient spikes, suppressing EMI/RFI interference, and conditioning incoming DC bus voltage before distribution to downstream modules. It is an essential component for any engineer specifying or maintaining a Honeywell C300 DCS installation, particularly in industries where uptime and measurement accuracy are non-negotiable.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell Process Solutions |
| Part Number | CC-PCF901 |
| Revision / Sub-Part | 51405047-175 |
| Module Type | Power Conditioner / Filter Module |
| Compatible Platform | Honeywell Experion PKS – C300 DCS, Series C I/O |
| Input Voltage | 24 VDC nominal (from C300 power supply rail) |
| Output | Conditioned / filtered 24 VDC to I/O modules |
| Filtering | EMI/RFI suppression, transient spike filtering |
| Mounting | C300 I/O Carrier / Chassis rail mount |
| Form Factor | Standard C300 module form factor |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Certifications | CE, UL listed (per Honeywell platform certification) |
| Weight | Approx. 2.0 kg (packaged) |
| Condition Available | New surplus / Refurbished / Used tested |
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA, downstream refinery DCS panels
- Petrochemical & Chemical Processing: Reactor control loops, distillation column instrumentation
- Power Generation: Turbine control systems, boiler management, substation automation
- Pulp & Paper / Mining: High-vibration, high-EMI environments requiring robust power conditioning
- Pharmaceutical & Food & Beverage: FDA-regulated process control requiring stable, clean power rails
- Water & Wastewater Treatment: Remote I/O enclosures with variable load conditions
Engineering Advantages
- Signal Integrity Protection: Eliminates power-line noise that causes false I/O readings and spurious alarms in analog loops
- Hot-Swap Compatible: Designed for live insertion/removal within the C300 chassis without system shutdown (verify with site safety procedures)
- Redundancy Support: Compatible with redundant power supply configurations in high-availability C300 architectures
- Plug-and-Play Integration: No firmware configuration required — module is recognized automatically by the C300 controller upon insertion
- Long Service Life: Solid-state design with no moving parts; rated for continuous 24/7 industrial operation
- Compact Footprint: Standard C300 module width minimizes enclosure space consumption
System Architecture & Signal Flow
Within a C300 I/O enclosure, the CC-PCF901 is positioned between the C300 Power Supply Module (CC-PWR001/CC-PWR002) and the downstream Series C I/O modules (analog input, analog output, digital I/O, etc.). The power conditioner receives raw 24 VDC from the power supply rail, applies multi-stage EMI filtering and transient suppression, then delivers a clean, stable DC voltage to the I/O module backplane. This architecture ensures that switching transients from field devices, variable frequency drives (VFDs), or solenoid valves do not propagate back into the DCS I/O bus and corrupt measurement data.
Typical signal flow: Field Power Source → C300 PSU → CC-PCF901 (Power Conditioner) → C300 I/O Carrier Backplane → Series C I/O Modules → Field Instruments
Sourcing & Quality Verification
- Authentic Sourcing: All CC-PCF901 units sourced through verified industrial surplus channels, OEM distributors, and decommissioned plant inventories — never counterfeit or grey-market
- Pre-Shipment Testing: Each module undergoes power-on functional verification and visual inspection for connector integrity, PCB condition, and label authenticity
- Traceability: Units supplied with available documentation including original packaging, revision labels, and test records where applicable
- Packaging: ESD-safe anti-static bags, foam-padded cartons, and double-boxing for international freight
- Warranty: 90-day operational warranty on all tested units; extended warranty available on request
Procurement Process
- Inquiry: Contact support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options
- Order Confirmation: Submit PO or confirm via email; payment terms discussed per account type (T/T, LC, PayPal accepted)
- Quality Check & Dispatch: Module tested, photographed, and dispatched with tracking within 2–5 business days
- After-Sales Support: Technical support available for installation queries and compatibility verification
Technical FAQ
Q: Is the CC-PCF901 compatible with both C300 and C200/C200E controllers?
A: The CC-PCF901 is specifically designed for the C300 Series C I/O architecture. Compatibility with C200/C200E platforms should be verified against Honeywell’s platform compatibility matrix before ordering.
Q: Can this module be used in a redundant power configuration?
A: Yes. The CC-PCF901 supports redundant power supply architectures when paired with dual C300 PSU modules. Consult your C300 system design documentation for wiring details.
Q: What is the difference between CC-PCF901 and other Honeywell power filter modules?
A: The CC-PCF901 (51405047-175) is the standard power conditioner for C300 I/O enclosures. Other variants may differ in current rating or filtering characteristics. Always cross-reference the full part number including revision suffix.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes, a CoC is available upon request for all new surplus and refurbished units. Please specify at time of order.
Q: What is the lead time for urgent orders?
A: In-stock units can be dispatched within 24–48 hours. For out-of-stock items, typical sourcing lead time is 5–15 business days depending on global availability.
