Honeywell CC-TAIX11 51308365-175 – Analog Input IOTA Redundant | Experion PKS Series
Engineering Background
The CC-TAIX11 (P/N 51308365-175) is a field-proven Analog Input IOTA (I/O Termination Assembly) module designed for Honeywell’s Experion PKS (Process Knowledge System) distributed control architecture. As a redundant-capable termination assembly, it serves as the critical interface layer between field instrumentation and the C300 controller subsystem, enabling high-integrity signal conditioning in continuous process environments.
Product Positioning
Engineered for mission-critical applications in refining, petrochemical, power generation, and advanced manufacturing, the CC-TAIX11 delivers deterministic analog signal acquisition with built-in redundancy support. Procurement engineers specifying this module gain a direct OEM-equivalent replacement with full backward compatibility across Experion R310–R520 platforms.
Complete Technical Specifications
- Part Number: CC-TAIX11 / 51308365-175
- Module Type: Analog Input IOTA (I/O Termination Assembly)
- Platform: Honeywell Experion PKS / Series C
- Redundancy: Supported (redundant IOTA configuration)
- Signal Type: Analog Input (AI)
- Input Range: 4–20 mA / 1–5 VDC (field configurable)
- Channel Count: 8 channels per IOTA
- Isolation: Channel-to-channel and channel-to-bus isolation
- Connector Type: Screw-terminal field wiring
- Backplane Interface: Series C FTA bus
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5–95% RH, non-condensing
- Power Consumption: Per Experion PKS system power budget
- Weight: Approx. 280 g
- Certifications: CE, UL (per OEM documentation)
- Firmware Compatibility: Experion PKS R310 and above
Proven Application Environments
- Petroleum refining and upstream oil & gas process control
- Petrochemical plant DCS migration and expansion projects
- Power generation (thermal, combined-cycle) turbine and boiler control
- Pulp & paper and specialty chemical continuous process lines
- Pharmaceutical manufacturing with validated control loops
- Water treatment and municipal utility SCADA integration
- Redundant control architectures requiring hot-standby I/O
Engineering Advantages
- Redundancy-Ready: Native support for redundant IOTA pairing eliminates single points of failure at the field termination layer.
- Direct OEM Replacement: Pin-compatible with installed Experion PKS Series C infrastructure — zero re-engineering required.
- High Signal Integrity: Isolated analog front-end minimizes ground loop interference in noisy industrial environments.
- Simplified Field Wiring: Screw-terminal design accommodates standard 2-wire and 4-wire transmitter configurations.
- Long Service Life: Industrial-grade components rated for continuous duty in Class I, Division 2 adjacent environments.
- Broad Firmware Compatibility: Supports Experion PKS R310 through R520 without configuration changes.
System Architecture & Signal Flow
The CC-TAIX11 IOTA mounts on the Series C FTA carrier rail and interfaces directly with the C300 Controller or AI FIM (Field Interface Module) via the backplane bus. Field transmitters connect to the screw-terminal block; the IOTA conditions and routes 4–20 mA signals through the isolation barrier to the digital acquisition layer. In redundant configurations, a secondary IOTA mirrors the primary, with automatic bumpless switchover managed by the Experion PKS controller logic. Signal flow: Field Transmitter → IOTA Screw Terminal → Isolation Stage → FTA Backplane Bus → C300/AI FIM → Experion Server.
Sourcing & Quality Verification
- All units sourced from authorized distribution channels or verified OEM surplus inventory.
- Each module undergoes visual inspection, label verification (P/N, revision, date code), and functional continuity check prior to dispatch.
- Serialization and firmware revision documented and provided with shipment.
- Packaging: ESD-safe anti-static bag + foam-lined carton; conforms to IEC 61340-5-1 handling standards.
- Certificate of conformance available upon request for regulated industries.
Procurement Process
- Step 1 — Inquiry: Submit your RFQ via email to support@konmask.com or WhatsApp +0086 19859288691 with quantity and required delivery date.
- Step 2 — Quotation: Receive itemized quotation with unit price (HKD/USD), lead time, and shipping options within 24 business hours.
- Step 3 — Order Confirmation: Confirm PO; proforma invoice issued for payment processing.
- Step 4 — Quality Check & Dispatch: Module inspected, serialized, and shipped with tracking via DHL / FedEx / SF Express.
- Step 5 — After-Sales Support: 12-month warranty on verified units; technical support available for integration queries.
Technical FAQ
- Q: Is the CC-TAIX11 compatible with Experion PKS R500 and R520?
- A: Yes. The CC-TAIX11 IOTA is compatible with Experion PKS R310 through R520. No hardware modification is required; firmware recognition is automatic upon backplane enumeration.
- Q: Can this IOTA be used in a non-redundant configuration?
- A: Yes. The CC-TAIX11 supports both simplex and redundant IOTA configurations. Redundancy is enabled via system configuration in Experion Control Builder, not hardware jumpers.
- Q: What transmitter wiring types are supported?
- A: The IOTA supports 2-wire loop-powered (4–20 mA) and 4-wire externally powered transmitters. Consult the Experion PKS Series C I/O Installation Guide for wiring diagrams.
- Q: Do you provide a test report or certificate of conformance?
- A: Yes. A certificate of conformance and inspection record are available upon request. Please specify at time of order.
- Q: What is the typical lead time?
- A: In-stock units ship within 3–5 business days. For large-quantity orders, lead time is confirmed at quotation stage.
