Analog Input Solution – Honeywell DC-TAID01 | Experion PKS Series
Where This Product Is Used
The Honeywell DC-TAID01 Analog Input IOTA (I/O Termination Assembly) is deployed across a wide range of process-critical industries where reliable analog signal acquisition is non-negotiable:
- Oil & Gas Refineries – Monitoring pressure transmitters, flow meters, and temperature sensors on distillation columns and pipeline SCADA systems.
- Chemical & Petrochemical Plants – Acquiring 4–20 mA signals from field instruments in hazardous-area control loops.
- Power Generation – Integrating turbine and boiler analog instrumentation into Experion PKS control strategies.
- Pulp & Paper / Water Treatment – Continuous process monitoring where signal integrity and uptime are paramount.
- Pharmaceutical Manufacturing – FDA-regulated batch processes requiring validated, traceable analog I/O.
Technical Specifications
- Part Number: DC-TAID01
- Module Type: Analog Input IOTA (I/O Termination Assembly)
- Compatible Platform: Honeywell Experion PKS / TDC 3000 Series
- Signal Type: Analog Input (4–20 mA / 1–5 V)
- Channels: 8 Analog Input Channels (typical per IOTA)
- Isolation: Channel-to-channel and channel-to-bus isolation
- Mounting: DIN rail / card cage compatible
- Weight: 1,060 g
- Operating Temperature: 0°C to 60°C
- Compliance: CE, UL, FM (refer to Honeywell datasheet for full certifications)
Why Engineers Specify This Model
- Plug-and-Play IOTA Design – Field wiring terminates directly on the IOTA, allowing the AI module to be swapped without disturbing field cables — minimizing maintenance downtime.
- Proven Experion PKS Compatibility – Engineered specifically for Honeywell’s Experion PKS architecture, ensuring seamless integration with existing control strategies and FDM asset management.
- High Signal Fidelity – Precision analog front-end with robust EMI filtering, critical for accurate readings in electrically noisy industrial environments.
- Long Service Life – Honeywell’s industrial-grade components are rated for decades of continuous operation, reducing total cost of ownership.
- Redundancy Support – Compatible with redundant controller configurations for high-availability process control.
Complete System Bill of Materials
For a fully operational Analog Input loop in Experion PKS, engineers typically specify:
- DC-TAID01 – Analog Input IOTA (this item)
- DC-MAIH01 / DC-MAIH02 – Analog Input Module (AI Module, pairs with IOTA)
- CC-TAIX01 – Analog Input IOTA (alternative series, verify compatibility)
- Experion PKS C300 / C200 Controller
- IOLIM / FIM – Field Interface Modules (as required by topology)
- 24 VDC Power Supply – Redundant power recommended
- Shielded Twisted-Pair Field Wiring – Per Honeywell installation guidelines
Compliance & Industry Standards
- IEC 61511 – Functional Safety for Process Industry Sectors
- IEC 61131-2 – Programmable Controllers Hardware Requirements
- NAMUR NE 43 – Signal Level for Fault Information from Field Devices
- CE Marking – European conformity for EMC and Low Voltage Directives
- UL Listed – Underwriters Laboratories industrial control equipment
- FM Approved – Factory Mutual for hazardous location use (verify specific approval class)
Quality Assurance & Sourcing
Konmask.com specializes in sourcing genuine, traceable industrial automation components for mission-critical applications. Every DC-TAID01 unit we supply undergoes:
- Authenticity Verification – Cross-referenced against Honeywell part databases and serialization records.
- Visual & Functional Inspection – Physical inspection for damage, corrosion, and connector integrity prior to dispatch.
- Traceability Documentation – Certificate of conformance and sourcing records available upon request.
- Secure Anti-Static Packaging – ESD-safe packaging to protect sensitive analog circuitry during transit.
How to Source This Part
Ready to procure the Honeywell DC-TAID01 for your plant or project?
- Request a Quote: Email [email protected] with your required quantity and delivery timeline.
- Urgent Requirement: Call or WhatsApp +0086 19859288691 for expedited sourcing.
- Bulk / Project Orders: We support BOM-based procurement — send your full parts list for a consolidated quote.
- Lead Time: Typically 3–10 business days depending on stock availability and destination.
Application-Specific FAQ
Q: Is the DC-TAID01 compatible with both Experion PKS and TDC 3000 systems?
A: The DC-TAID01 is designed for the Experion PKS platform. TDC 3000 uses a different I/O architecture (MC-TAIH02 series). Please confirm your controller model before ordering.
Q: Can I replace the IOTA without shutting down the field loop?
A: The IOTA termination assembly is designed to allow module hot-swap without disturbing field wiring. However, always follow your site’s Management of Change (MOC) and safety procedures before any live maintenance.
Q: What is the difference between an IOTA and an AI Module?
A: The IOTA (I/O Termination Assembly) is the passive wiring termination board. The AI Module (e.g., DC-MAIH01) is the active electronics card that plugs into the IOTA. Both are required for a complete analog input channel.
Q: Do you supply the matching AI Module (DC-MAIH01) as well?
A: Yes. Contact us with your full BOM and we will provide a consolidated quote for all required components.
Q: What warranty is provided?
A: We offer a 90-day functional warranty on all units. Extended warranty and exchange programs are available — contact us for details.
